Contents Front / Right Side View and Controls Rear View and Sockets Remote Control Installing Batteries in the Remote Control Remote Control Operation Range Installation Guide Main Menu 7-23 7-15 . Channel Menu 2. Picture Menu 3. Sound Menu 4. Time Menu 5.
EARPHONE HDMI1 PC AUDIO HDMI2 SCART COAX Connecting to the PC output jack a personal computer. Digital output to AV receiver. COAX To connect the Satellite signal. DVB-S2...
Remote Control Definition of the buttons on remote control: 1. POWER: Enter or quit the standby mode. 2. COLOR BUTTONS Red/green/yellow/blue key navigation link. Fast reverse (in USB mode) Fast forward (in USB mode) Previous (in USB mode) Next (in USB mode) ♥...
Page 7
Remote Control Definition of the buttons on remote control: Teletext Function: 2. COLOR BUTTONS: Teletext Button. 3. TEXT : Switch between teletext on, mix and teletext off. 4. HOLD : Retain the current teletext page and again to cancel the function. 5.
blue 1.Press the Menu button on the remote control on your LED TV to select the Setup menu. 2.Press the buttons to select the Reset. Use the Left/Right/Down keys to select your Language, Country,Energy Model and Auto Standby. Tuning Setup Tune Type <...
Channel Setting Antenna 1.Press the Menu button on the remote control on your LED TV to select the Channel menu. 2.Press the buttons to select the Antenna menu.Press OK to select it. 3.Press the buttons to select DVB-T or DVB-C. Auto Tuning Tuning Setup Tuning Setup...
Page 11
ATV Manual Tuning ATV Manual Tuning < - Current CH +> Colour System Sound System Fine-Tune 48.25 MHz Search You can manually tune ATV Manual Tuning in the CHANNEL Menu. 1.Current CH:Dispaly the current channel number,press the buttons to choose the channel you wish to modify.
Programme Edit Programme Edit Use up/down keys to select program edit.Press OK or Rght button to enter the menu.Use up/down buttons to navigate through the menu. 1.Delete: Press the RED button to delete the highlighted channel,a red circle will appear next to the channel name. Press the RED button again to confirm delete.
Page 13
Software Update{USB} 1.Download the software to the usb device,then insert the usb device to the unit. 2.Press the Menu button to select the CHANNEL menu. 3.Press the buttons to select Software Update{USB} and then press the OK button to update software. 4.when the updating is completed,the unit will be reset to standby mode.
Page 14
Satellite Tuning Select “Dish Setup” item to enter the satellite system setting menu and the user operation interface as following: Satellite List Operations in Satellite List Menu are shown in the following table: Action Stroke KEY_UP use cursor to up KEY_DOW use cursor to down switch operation to satellite system parameters setting...
Page 15
Satellite edit menu Operations in satellite edit menu are shown in the following table: Option Value Satellite Enter Satellite Rename edit menu Longitude East ,West Direct ion Longitude Press num key to set the Angle Angle Band C,Ku band choose satellite Seach menu Operations in satellite scan menu are shown in the following table: Option...
Page 16
Transponder List Operations Transponder List Menu are shown in the following table: Key Stroke Action KEY_UP use cursor to up KEY_DOWN use cursor to down KEY_LEFT switch operation to Satellite list KEY_RIGHT switch operation to satellite system parameters setting list KEY_ENTER Select/unselect cursor item Transponder.
Page 17
Transponder Edit menu Operations in Transponder Edit menu are shown in the following table: Option Value Transponder Current edit item.Auto select Frequency Press num key to edit Symbol(ks/s) Press num key to edit Polarity Setting Operations in Setting Menu are shown in the following table: Action Stroke KEY_UP...
Page 18
Operations in Setting item menu are shown in the following table: Option Value LNB Type 9750/10600,9750/10750,05150,05750, 5150/5750,09750,10600,10750,11300,1 1475,User Single,User Dual LNB Power On,Off 22KHz Auto,off,on DisEqC Mode Off,LNB1,LNB2,LNB3,LNB4,Burst A,Burst Motor None,DisEqC1.2,DisEqC1.3...
Menu Settings Picture menu PICTURE Picture Mode < Standard > Contrast Brightness Colour Tint Sharpness Colour Temp < Normal > Picture Mode: Choose from Standard,Dynamic,Personal and Mild. Note: Contrast,Brightness,Colour and sharpness are only available and can be adjusted in the User mode option in the Picture Mode Settings. Contrst: Controls the difference between the brightest and darkest regions of the picture.
SOUND menu SOUND SOUND Sound Mode < Standard > AD Switch > Bluetooth > Treble Bass Balance < > Auto Volume < > Surround Sound < > SPDIF Mode Auto Sound Mode: Allows you to select among: Standard,Music,Movie,Sports and Personal. Treble(Can be adjusted when the sound mode is set to User): Controls the relative intensity of higher piched sounds.
Time menu TIME Clock 02/Jan 07:26 > Time Zone < Berlin GMT+1 > Off Timer > On Timer > Sleep Timer < > Auto Standby < > OSD Timer < > Clock: Press the up/down buttons to select the clock menu,then press the OK button to set date and time.
Setup menu Language: Allows you to select the on screen display menu language. TT Language: Press left/right buttons to select West,East,Russian,Arabic or Farsi. Audio Language(can only be selected in DTV mode): Select the audio language. The availability of this function depends on the tuned-in channel. Subtitle Language(can only be selected in DTV mode): Select the subtitle language.
LOCK menu LOCK System Lock < > Set Password > Channel Lock Parental Guidance Key Lock Hotel Mode BackLight The password must be entered to access the Lock Menu.The default password is 0000.Once inside the menu you can change the password to your own choice. System Lock: Enables or disables the system lock.After selecting ON,the settings made under “...
Page 24
Hotel Mode Hotel Mode Export Database > Hotel Mode < > Source Lock > Clear Lock > Default Source < > Default Prog 2 BBC TWO NI Default Volume < > Max Volume < > Import Datebase > Restricts access to tuning menu,limitation of maximum volume setting.Locks picture and signal menus.
Media Player In the option of Media Player on MainMenu,Press OK to enter the Media Player menu see the picture as follows: Press left / right toselect Movie,Music,photo or text. Take Movie function for example,when there is focus point on Movie function, press OK button to enter into File Selector menu MOVIE Delete...
Page 26
1.Movie Press OK button to enter into FileSelector menu.Select the file you want to play, press PLAY/PAUSE to enter into full screen play.Press left/right button to move cursor,and operate according to different hint. 2.Music In the same way,on Media Player menu,move cursor to music,Press OK button to enter into FileSelector menu.Select the file you want to play,press PLAY/PAUSE to enter into full screen play.Press left/right button to move cursor, and operate according to different hint.
Specification Specifications LED TV 1. Model No LED65UHD Number Of Pixels 3840(H)x2160(V) Viewing Angle 89/89 Degree Typ. (H/V) Lamp Life Time 50,000 hours Display Colors 16.7m colors 2. Power Input Voltage 100-240V~,50/60Hz Operation Mode 240W Standbypowerconsumption <0.5W 3.Connector PAL.SECAM.BG.DK, I...
