2 WIRE HOME Wi-Fi SYSTEM

DPM-D277TMW

7" COLOR TFT Wi-Fi MONITOR

• Please read this manual carefully before using the product you purchase,and keep it well for future use.

• Please note that images and sketch maps in this manual may be different from the actual product.

Table of Contents

Need help?

Do you have a question about the DPM-D277TMW and is the answer not in the manual?

Questions and answers

Summary of Contents for ASM DPM-D277TMW

Page 1 ENG-DPM-D277TMW / 201811 2 WIRE HOME Wi-Fi SYSTEM DPM-D277TMW 7" COLOR TFT Wi-Fi MONITOR • Please read this manual carefully before using the product you purchase,and keep it well for future use. • Please note that images and sketch maps in this manual may be different from the actual product.
Page 2: Table Of Contents
Contents 1.Parts and Functions ..........1 2.Mounting ..............2 3.Main Menu ..............3 4. Answering a Call ............5 5.Panview & Zoom ............6 6.Monitoring ..............6 7.Call Another Rooom or Apartment(Intercom) .... 8 8.View Call Record ............10 9.Open Staircase Light ..........11 10.No Disturb Function ..........
Page 3: Parts And Functions
1. Parts and Functions LCD Screen Power/No Disturb Indicator Speaker Microphone Talk/Mon Button Unlock Button RING 1 2 3 4 5 6 Connection port Key functions Speaker Send out vioce from the visitor. Press to communicate hands free with visitor; Talk/Mon button Press to view the outdoor condition in standby mode.
Page 4: Mounting
Terminal description SW+,SW-: Extra door bell call button connection port. RING Ring,GND: Extra buzzer 1 2 3 4 5 6 connection port. POW,GND: 12~16V extra power connection port. USB-Wi-Fi adaptor DIP switches: Total 6 bits can be configured. Bit1~Bit5: User Code setting •...
Page 5: Main Menu
3. Main Menu The Main menu is your starting point for using all the applications on your monitor. Touch Unlock button, or touch anywhere of the screen on monitor in standby mode, the Main menu will appear as follow: Monitor Intercom Touch it to view outdoor condition.
Page 6 Icon Meaning Description Wi-Fi connection active and not connected Wi-Fi connection disabled Touch it to enter Wi-Fi setting interface in shortcut. Wi-Fi connection active and configured While talking with a door station Shows status of talking, unlocking Displays which door station ect.
Page 7: Answering A Call
4. Answering a Call 1. Touch it to answer the call. To end the call touch it again. 00:10 Door Station1 2. If necessary, during the call touch it to display the audio/ video adjustment icons. 3. Touch it to record image/ video.
Page 8: Panview & Zoom
5. Panview & Zoom If wants to see greater detail about visitors,move to the desired position by touching on the screen to view the image in pantilt & zoom mode. 1. Touch it to activate the panview 00:10 Door Station1 and zoom function.
Page 9 2. Touch it to activate the desired camera on Monitor interface. 3. It is possible to “>” (display in sequence) the other cameras. 4. Touch it to return the previous menu. 5. Touch it to activate the specified camera in shortcut. The display shows the images recorded by the active camera. 6.
Page 10: Call Another Rooom Or Apartment(Intercom)
7. Call Another Room or Apartment (Intercom) It is possible to communicate with another device installed in another room of the apartment or with a device of another apartment. 1. Touch it to display the available intercoms. 2. Touch it to display the available namelist calls.
Page 11 4. Touch it to activate the communication with another room. Intercom Intercom Namelist Inner Call Guard Station Input Numbers 5. Touch it to activate the communication with guard station. Intercom Intercom Namelist Inner Call Guard Station Input Numbers 6. If the system does not have the room number you want, you can enter Intercom other room number.
Page 12: View Call Record
7. Input the room numbers you want. 123_ Note: when a call is received from the Door Station while the internal unit is in “intercom” mode, the system follows the priority rules and ends the active call. 8. View Call Record When there are one or more unread call records in the answering machine, clicking the icon shows them.
Page 13: Open Staircase Light
The infomations you select is played back automatically. 3. Touch it to scroll interface. 1/223 4. Touch it to delete the image. [2017/09/16 09:50] Door Station 1 9. Opening Staircase Light Note: The staircase light should be connected on the system, and this function should be supported by RLC.
Page 14: No Disturb Function
10. No Disturb Function If you don’t want to be disturbed, for example, at night. Activating the mute function is necessary for you. 1. Touch it to enter call scene interface. 2. Touch it to set the no disturb mode: No Disturb 8H and No Disturb Always.
Page 15: Divert Call
11. Divert Call The calling from door station can be diverted to your phone. please note that this function should be supported by Wi-Fi or SIP network. 1. Touch it to enter call scene interface. 2. Touch it to set the divert call mode: Divert Call If No Answer and Divert Call CallScene Always.
Page 16: Setting
12. Setting Enter setting interface 1. Touch it to enter setting interface. Setting Call Tune Ring volume [04] General Door1 calling tune [01] Installer Door2 calling tune [01] Wireless Door3 calling tune [01] About Door4 calling tune [01] 2. Touch the icon for the desired customisation, choosing among: Ring volume -Door1 calling tune -Door2 calling tune -Door3 calling tune -Door4 calling tune Call Tune -Doorbell calling tune -Intercom calling tune -InnerCall calling tune -GuardCall calling tune...
Page 17: Ring Tone Setting
Ring tone setting The ring call tone can be set individually to distinguish different calling sources. Total 22 tones can be selected. Scroll to next interface 1. Touch it to enter call tune setting Setting interface. Call Tune Ring volume [04] General Door1 calling tune [01] 2. Touch the setting item to select the Installer Door2 calling tune [01]...
Page 18 Date and time setting The current date and time can be modified at any time. Setting Date time set Call Tune Date and time General Date mode: MM_DD_YYYY General Language Time mode: HOUR_12 Installer Monitor time Date: xxxx_xx_xx Wireless Shortcut setting Time: xx:xx About SD card 1. Touch it to enter the date time set interface. 2.
Page 19 Setting monitor time The monitor time can be changed at any time. It’s available to set 30s, 60s, 90s, 120s, 150s, 180s, 210s, 240s, 270s, 300s. * 30s is the default monitor time. Setting Monitor time select Call Tune Date and time General 30(s) General...
Page 20 SD card If the device insert an SD card, the SD card info can be reviewed on the device. Setting SD Card Call Tune Date and time General SD information General Language Copy image Installer Monitor time Firmware Update Wireless Shortcut setting About SD card...
Page 21: Installer Setting
Installer setting This section contains the device address setting and system settings. 1. Touch it to enter installer setting Setting interface. Call Tune Current addtess [01] General Intercom enable Enable Installer IPC Setting Wireless Monitor list manage About System settings DIP Switcher Set Address The DIP switches are used to set the user code for each monitor.Total 6 bits can be configured.
Page 22 Enabling/Disabling intercom function It’s available to forbid or activate the intercom function. Setting Intercom enable Call Tune Current addtess [01] Installer Disable General Intercom enable Enable Enable Installer IPC Setting Wireless Monitor list manage About System settings *In default setting, intercom function is enable for the monitor. IPC Setting It’s available to set the related function of IP camera.
Page 23 Add IPC by manual: Add the IP camera by manual. IPC Setting IPC login Installer Add IPC by searching Installer IPC IP: Add IPC by manual User name: admin IPC list User pwd: admin IPC DHCP [Enable] Channel: Login IPC list: IP camera list. IPC Setting IPC monitor Installer...
Page 24 It’s available to forbid or activate the IPC DHCP. IPC DHCP: IPC Setting IPC DHCP Installer Add IPC by searching Playlist Disable Add IPC by manual Enable IPC list IPC DHCP [Enable] Monitor list manage It’s available to manage the monitor list. Setting Mon select Call Tune...
Page 25 Software upgrade It’s available to upgrade the device software via SD card. Setting Setting Call Tune Current addtess [01] Call Tune FW upgrade General Intercom enable Enable General Reboot Installer IPC Setting Installer Wireless Monitor list manage Wireless About System settings About FW update Installer...
Page 26: Wireless Setting
Wireless setting SD card WIFI adaptor 3P-USB cable for Wi-Fi monitor FW updating 1. Touch it to enter wireless setting Setting interface. Call Tune Wifi switch [ON] General Wlan setting 2. Touch it to activate the function, make Installer Wireless device regist [00] sure the switch is ON.
Page 27 7. Enter the password (if required). PWD: vtk_ 8. Touch it to activate the connection, and return to Wi-Fi information interface. 9. Go to Connect/Disconnect item. Wireless SSID: VTKAP03 PWD: vtk@123 Connect/Disconnect Make slave Wi-Fi monitor to be registered with master Wi-Fi monitor On master Wi-Fi monitor and slave Wi-Fi monitor, go into wireless setting interface.
Page 28 2. Touch it to enter the master / slave register interface. master Wi-Fi monitor slave Wi-Fi monitor Device manage Device manage Wireless Register new slave Wireless Register new master Master register Slave register Wireless My ID: 040019b93fa9/201 Wireless My ID: 040019b83ea9/201 Receive slave: Registered to: Slave ID:------------ / ---...
Page 29 2. Touch it to manage the phone. Phone manage Wireless Register phone 3. Touch it to add phone address. Add slave Wireless Phone Addr: Add Ip/Smart phone 4. Input the phone IP address(this address 192.168.169.199 is received from your phone). Make sure your mobile phone is connected to Home WIFI. After finish, press “OK” to save and return to last interface.
Page 30 SIP config It’s available to divert the call to smart phone while out of home via SIP server. On the call scene interface CallScene CallScene Normal Use 1. Touch it to select the divert call mode: No Disturb 8H Divert Call If No Answer or Divert Call No Disturb Always Always.
Page 31: About
2Easy APP is not able to get push notification. DX monitor has connect with Wi-Fi, but “Server” icon with “!” or “x” beside. About 1. Touch it to enter about interface. Setting Call Tune Device Type: DPM-D277TMW General S/W Ver: V1.0.0.171110111114 Installer Serial No: 040019b93333 Wireless...
Page 32: Download Setup 2Easy App
13. Download Setup 2Easy APP 1. Scan and download 2Easy APP, or search “2Easy” on APP store. Android version is temporary test version, and is not available on Google play yet. Android 2. Permit “2Easy” with internet access and camera, on DX monitor, press “SIP Server” icon on main menu, and keep in “SIP config”, on 2Easy APP, press on top-right, to scan QR code on DX monitor, and press “Save”.
Page 33 3. Disable “IPV6” on 2Easy APP Most of internet provide doesn’t support IPV6 feature, please manually disable it with follow steps: Press here to disable -31-...
Page 34: Surveillance Door Station Via 2Easy App
4. After login SIP account on 2Easy APP, check on status bar, or press on the “Registered” area to manually register, until 2Easy APP display: 14. Surveillance door station via 2Easy APP On 2Easy APP, press on “Monitor” and wait for a few second (Due to 2-Wire communication will take around 12 second to get video), blue screen is normally due to the DX monitor is verifying the password and monitor code.
Page 35 Local mode--at home with same Wi-Fi network • No need SIP sever and account log in • Both Wi-Fi sub Monitor and Phone in Local mode work as wireless slave • monitors Home router 2-wire System RF CARD PC6A Wi-Fi master Wi-Fi sub Wireless terminal montior...
Page 36: Specification
16. Specification ● Power supply: DC 20~28V ● Power consumption: Standby 1.8W; Working 8.16W ● Monitor screen: 7 Inch digital color TFT ● Display Resolutions: 800*3(R, G, B) x 480 pixels ● Video signal: 1Vp-p, 75Ω, CCIR standard ● Wiring: 2 wires, non-polarity ● Dimension: 161(H)×174(W)×22(D)mm 17.
