Hup Solar-One User Manual

Battery system
Hide thumbs

Advertisement

Quick Links

USERS MANUAL

Table of Contents

Precautions and receiving the battery
Installation and initial charge
Maintenance Guidelines
Warranty
Water Warning
®
Solar-One
Battery System
Copyright Northwest Energy Storage Inc. 2011-2012 Revised 09/13/12
Tech support 941-474-0110 M-F 9am-5pm central time.
1
Page 2
Pages 3 & 4
Page 5 -7
Page 8
Page 9
Page 10
Pages 11 & 12
Page 13
Page 14
Page 15
Page 16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Solar-One and is the answer not in the manual?

Questions and answers

Summary of Contents for Hup Solar-One

  • Page 1: Table Of Contents

    USERS MANUAL ® Solar-One Battery System Table of Contents Precautions and receiving the battery Page 2 Installation and initial charge Pages 3 & 4 General Maintenance Page 5 –7 Charts and Graphs Page 8 Specifications Page 9 Recharge Settings Page 10 Diagrams Pages 11 &...
  • Page 2 Your Solar-One Battery is packaged by professionals using quality materials to DOT specifications. If the condition of your shipment is not received reasonably close to the above photo, contact your Solar-One Dealer or call 941-474-0110. Tech support 941-474-0110 M-F 9am-5pm central time.
  • Page 3 Installation Step 1 Acquire the following safety items: safety glasses or face shield, acid resistant apron, insulated 1/2” wrench, insulated ratchet with 1/2” socket, 1 gal neutralizing agent, ( 1 lb baking soda to 1 gal. water, mix this solution thoroughly) rubber gloves Step 2 Inspect the battery tray (steel case) for evidence of damage, if damage has occurred file a claim with the carrier immediately.
  • Page 4 Installation cont. Warning: Never allow tools or other conductive objects to make contact with two or more battery terminals. Step 6 Neutralize the sides of the cells and the steel tray. Rinse and dry thoroughly. Step 7 Move the steel tray to the desired location. Step 8 Install the cells back into the tray using the diagram on page 12 to ensure the cells are correctly installed.

  • Page 5: General Maintenance

    General Maintenance Warning: Always wear protective clothing and eye/face protection when working around batteries. If you should get acid in your eyes or on your skin, flush with clear water for 15 minutes and seek medical help. Do Not use neutralizing agent to flush your eyes! Adding Water Fill to: 1/4"...
  • Page 6 We recommend the MISCO Hand-Held Refractometer 7084VP. Specific Gravity: The standard fully charged specific gravity for the Solar-One is 1.275-1.285 @ 77° F the 100% discharged gravity is 1.140 @ 77° F. Since the acid content of the electrolyte decreases linearly as the cell is discharged, the decrease in gravity is directly proportionate to the amount in ampere-hrs taken out.
  • Page 7 General Maintenance Voltage There is a definite relationship between the cell voltage and the specific gravity of a cell that is open circuit (no charging or discharging for at least 24 hours). These open circuit voltage readings are useful in determining uniformity.

  • Page 8: Charts And Graphs

    Charts and Graphs Specific Gravity Cell Voltage Freezing points of Specific Gravity Vs. Temperature Correction Temperature Correction battery Electrolyte Percent Discharged 1.280 Electrolyte Hydrometer Electrolyte Cell Voltage Electrolyte Specific Temperature Correction Temperature Correction Temperature Gravity 1.260 49-51 °F -.009 49-51 °F -.09 32 °F 1.000...
  • Page 9 Solar-One Specifications Model # Rated Rated Usable Rated Usable *Min. *Max. L x W x H Approx Short Circuit Watt/hrs Watt/hrs Charging Charging in Inches Weight Ratings in Amps 12 Volts (20 hr) (6 hr) (20 hr) (20 hr) (20 hr)

  • Page 10: Specifications

    Solar-One® Specifications 24 hr. Open Circuit Volts vs. Depth of Discharge (DOD) 12 volts 24 volts 48 volts Specific Gravity 12.75 25.50 51.00 1.275-1.285 (Full Charged) 12.36 24.72 49.44 1.236 50% (Half Discharged) 12.12 24.24 48.48 1.205 11.88 23.76 47.52 1.181...

  • Page 11: Diagrams

    12 V Pos. Note: Each tray of Solar-One® batteries comes with an extra lead coated copper buss bar. This bar is to be used for making a parallel connection as shown above, or a series connection as seen on the next page. This bar is bent on site and can be a “horse shoe” (above) or a “Z”...
  • Page 12 Diagrams 24 Volt All Models 48 Volt All Models 4/0 Series Cable 48 Volt Positive Tech support 941-474-0110 M-F 9am-5pm central time.

  • Page 13: Troubleshooting

    Troubleshooting Problem Probable Cause Remedy Battery not performing as Battery is undersized. Replace with a larger battery. expected Battery not fully charged Check charger and controller. Weak or defective cells. Perform a load test Grounds or shorts. Clean battery and all connections in the system Phantom loads in system Find and eliminate loads.
  • Page 14 (The Heart of the system) the better service life you can expect from your investment. The Solar-One® warranty as it pertains to records, only requires that "reasonable records be kept". Use your best judgement.
  • Page 15 Serial Number___________________________________________ ® ® EnerSys® Delaware Inc. (“EnerSys”) warrants all General Battery™ Hup Solar-One batteries to be free from defects in workmanship and materials for the period stated in the following table, from the date of installation or no more than three (3) months from date of shipment, whichever comes first.
  • Page 16 Do Not add water to ® your new Solar-One battery until you have completed the initial charge. See page 4. Tech support 941-474-0110 M-F 9am-5pm central time.
