- Page 1 OPERATOR’S AND PARTS MANUAL ECLIPSE 2220/SE SERIES FLASHING ARROWBOARD ALLMAND BROS. INC P.O. BOX 888 HOLDREGE, NE 68949 PHONE: 308/995-4495, 1-800/562-1373 ALLMAND FAX: 308/995-5887 ALLMAND PARTS FAX: 308/995-4883 ECLIPSE 2220/SE For Parts and Updates visit Allmand on the Web at www.allmand.com...
-
Page 3: Table Of Contents
Controller (illustration) Page 13 Controller Features and Operation Page 14 APF Flashing Array Display Sequence Illustrations Page 15 Allmand Eclipse 2220/SE Halogen Lamp Descriptions Page 16 Allmand Eclipse 2220/SE LED Lamp Descriptions Page 16 Wiring Diagrams Page 17 Serial Number Plate Location... -
Page 4: Description And Features
ALLMAND ECLIPSE 2220/SE SERIES SOLAR ASSIST ARROWBOARD DESCRIPTION AND FEATURES The ALLMAND ECLIPSE 2220/SE SERIES solar assist arrowboard uses two, three or four 12V DC 8D deep cycle batteries, providing a nominal 12V DC to the operating system. The battery enclosure is lockable, ventilated and designed to protect the batteries from theft or vandalism. -
Page 5: Safety And Precautions
A safe environment around the ALLMAND ECLIPSE 2220/SE SERIES SOLAR ASSIST AROWBOARD is encouraged. The following recommendations should be noted since the ALLMAND ECLIPSE 2220/SE SERIES is typically used in construction areas with greater traffic congestion, thereby increasing the risk of accidents or injuries. -
Page 6: Set-Up/Operating Instructions
ALLMAND product. It is the user’s responsibility to ensure that the manner in which the ALLMAND ECLIPSE 2220/SE SERIES is used is consistent with safe practices and the user is to understand that he/she is the only liable party. -
Page 7: Trailer Alignment Illustration
TRAILER ALIGNMENT ILLUSTRATION 1 MILE CAUTION: For safe operation and maximum visibility, sight through the eyelets midway up the right frame uprights to align the unit relative to the roadway and the horizon as illustrated above. Observe the operation of the machine from varying vantage points down the roadway to ensure that maximum visibility is maintained throughout the controlled area. -
Page 8: Safety And Warning Decals
ALWAYS REPLACE ANY SAFETY AND INSTRUCTIONS DECALS THAT BECOME DAMAGED, PAINTED OVER, OR OTHERWISE ILLEGIBLE! Refer to the following representations of the safety warning decals used on the ALLMAND ECLIPSE 2220/SE Series trailer to insure correct ordering if replacement becomes neces-... -
Page 9: Winch Operating Instructions
WINCH OPERATING INSTRUCTIONS The winch is designed to lift load (“reel in”) when the crank is turned in a clockwise direction. This action will produce a clicking sound. To lock load at any desired position, simply release the hand crank. To lower load (“reel out”), turn the hand crank in a counter-clockwise direction. To lock load in any desired position, turn handle crank clockwise until at least two clicks are heard before releasing handle. -
Page 10: Periodic Maintenance
PERIODIC MAINTENANCE The ALLMAND ECLIPSE 2220/SE SERIES SOLAR ASSIST ARROWBOARD has been designed to minimize maintenance. However it will be necessary to inspect or test the follow- ing areas on a periodic basis. ARRAY MAINTENANCE 1. Clean solar panels. 2. Check solar panels and wiring. -
Page 11: Battery Maintenance
NOTE: Batteries must be recharged periodically using an AC battery charger to avoid over- sulfating plates and impairment of battery performance. If ALLMAND ECLIPSE 2220/SE Series supplied BATTERY CHARGER is not used, a charge current of at least 50 amps must be provided to sufficiently charge batteries. Use extreme cau- tion when using other than ALLMAND ECLIPSE 2220/SE Seriescharger to observe correct battery polarity and also to avoid over-charging (“boiling”) of batteries. -
Page 12: Troubleshooting
TROUBLESHOOTING The ALLMAND ECLIPSE 2220/SE SERIES SOLAR ASSIST ARROWBOARD is a highly reliable and trouble free piece of equipment. However, should a rare problem occur, the following list of trouble- shooting procedures will assist the operator in locating and correcting the source of the problem. -
Page 13: Controller Illustration
CONTROLLER ILLUSTRATION ALLMAND BROS., INC. MODEL 2220/SE... -
Page 14: Controller Features And Operation
**CIRCUIT BREAKER: 6 amp auto-reset breaker protects controller from shorts in wiring or lamps. ** PHOTOCELL: Located inside bottom frame channel of sign panel directly below controller. ALLMAND ECLIPSE SUNTRAK system automatically varies lamp intensity relative to ambient sunlight. Photocell location prevents false brightening of lamps by oncoming vehicle lights. -
Page 15: Apf Flashing Array Display Sequence Illustrations
APF FLASHING ARROW DISPLAY SEQUENCES RIGHT FLASHING ARROW LEFT FLASHING ARROW DOUBLE FLASHING ARROW RIGHT SEQUENTIAL ARROW LEFT SEQUENTIAL ARROW FLASHING WARNING BAR DOUBLE SEQUENTIAL ARROW DOUBLE DIAMOND WARNING SEQUENTIAL WARNING BAR 4-CORNER WARNING DISPLAY RIGHT SEQUENTIAL CHEVRON LEFT SEQUENTIAL CHEVRON... -
Page 16: Allmand Eclipse 2220/Se Halogen Lamp Descriptions
•LED lamp display is more defined, resulting in greater legibility distances (greater than ONE MILE, which exceeds MUTCD requirements.) •The LED lamp carries a 5-year limited warranty from the manufacturer against defects in materials and workmanship. LAMP VISOR ALLMAND LED LAMP ALLMAND ECLIPSE 2220/SE SERIES LED LAMP ASSEMBLY... -
Page 17: Wiring Diagrams
ALLMAND ECLIPSE 2220/SE SERIES ARROWBOARD SIGN PANEL WIRING DIAGRAM APF (25-LAMP) SIGN ASSEMBLY MOLEX CONNECTOR #1 MOLEX CONNECTOR #2 PIN# WIRE COLOR LAMP# PIN# WIRE COLOR LAMP# BROWN YELLOW BLACK PURPLE GRAY YELLOW BLUE GREEN BLACK BLUE GREEN GRAY BLACK... -
Page 18: Serial Number Plate Location
MODEL SERIAL NUMBER PLATE LOCATION ALLMAND SERIAL NUMBER PLATE LOCATED HERE ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... -
Page 19: Parts And Accessories
For Serial Number 0458AB02 and up ALLMAND BROS. INC P.O. BOX 888 HOLDREGE, NE 68949 PHONE: 308/995-4495, 1-800/562-1373 ALLMAND FAX: 308/995-5887 ALLMAND PARTS FAX: 308/995-4883 ECLIPSE 2220/SE ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 20 ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
- Page 21 45, 50, 75, 80, 90, 100, 150, AND 160 WATT SOLAR PANEL WIRING..36-37 DECAL PLACEMENT DETAIL ..............38 WIRING SCHEMATICS ................40 ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 22: Trailer Assembly Parts And Accessories
TRAILER ASSEMBLY PARTS AND ACCESSORIES ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 23 044031 5/16-18 KEPS NUT 041050 1/4-20 X 3/4 TRUSS HEAD BOLT 047025 1/2" FLAT WASHER 714153 LATCH, HOOD 711037 BUSHING, NYLON STEP ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
- Page 24 TRAILER ASSEMBLY PARTS AND ACCESSORIES ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
- Page 25 FENDER, METAL (15" ONLY) NOT SHOWN 680124 ASSY, WHEEL & TIRE, 15" NOT SHOWN 352157 WHEEL, 15" - NOT SHOWN 712116 WHEEL, 13" - NOT SHOWN ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 26: Swing Arm Assembly And Parts
SWING ARM ASSEMBLY AND PARTS ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 27 Hinged panel bracket left for 75 or 80 watt 041050 1/4-20 x .75 Truss head bolt 044021 1/4-20 Keps nut 044015 1/4 Flat washer 046115 3/8-16 x 1.25 Hex bolt ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 28: Hood Assembly And Parts
HOOD ASSEMBLY AND PARTS ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 29 714150-05 Lid rear 041050 1/4-20 X .75 Truss head bolt 714168 Spacer hinge plate 714154 Hinge metal hood 712395 Handle 711029 Plug Ø.875 ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 30: Sign Frame Assembly And Parts
SIGN FRAME ASSEMBLY AND PARTS ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 31 Low voltage disconnect warning lamp (RED) 711042 Rear indicator lamp (AMBER) 711038 Blind rivets (PKG/100) LEGEND:NS NOT SHOWN ALT: 15 LIGHT DISPLAY APF: 25 LIGHT DISPLAY ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 32: Sign Assembly And Parts
SIGN ASSEMBLY AND PARTS ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 33 Halogen lamp assembly 711413 LED lamp 711041 Lamp Visor Visor Screw 041015 LEGEND:NS NOT SHOWN ALT: 15 LIGHT DISPLAY APF: 25 LIGHT DISPLAY ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 34: Battery Compartment And Accessories
BATTERY COMPARTMENT AND ACCESSORIES ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 35 Battery charger cable Positive (Red, 6 gauge, 20") 713531 Battery charger cable Negative (Black, 6 gauge, 20") LEGEND:NS NOT SHOWN ALT: 15 LIGHT DISPLAY APF: 25 LIGHT DISPLAY ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
- Page 36 DESCRIPTION 711468 Power cable 12 Ft. 711467 Power cable 4 Ft. LEGEND:NS NOT SHOWN ALT: 15 LIGHT DISPLAY APF: 25 LIGHT DISPLAY ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
- Page 37 Solar panel 50 watts New SW50 20” x 40” 711301 Solar panel 45 watts (Optional) 711304 Solar panel 75 watts (Not Shown) 711305 Solar panel 80 watts (Not Shown) ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E...
-
Page 38: Decal Placement Detail
DECAL PLACEMENT DETAIL ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 39 DECAL PLACEMENT PARTS LIST REQ’D PART NO DESCRIPTION 090279 Decal Allmand (Also on back) 090125 Decal Warning - Corner stand 090147 Decal No Step 090148 Decal Warning - Do not operate 090091 Decal Warning - Trailer alignment 090322 Decal Allmand Assurance 3"...
-
Page 40: Wiring Schematics
WIRING SCHEMATICS TAILLIGHT WIRING SCHEMATIC ALLMAND ECLIPSE 2220/SE SERIES P A R T S R E F E R E N C E... - Page 41 Subject to the foregoing, the manufacturer, Allmand Bros. Inc., hereby warrants all equipment manu- factured by Allmand Bros. Inc. to be free from defects in material and workmanship for a period of (3) years after delivery to the original purchaser. Additionally, Allmand Bros. Inc. hereby warrants all replacement parts supplied by Allmand Bros.
