Summary of Contents for Aseptico COMMAND-AIR ALU-29CF
- Page 1 ALU-29CF Portable Light NSN: 6520-01-446-4170 COMMAND AIR OPERATION / MAINTENANCE MANUAL & PARTS LIST...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..............3 Purpose . -
Page 3: Introduction
PURPOSE: The Aseptico ALU-29CF Command Air Portable Light contains a halogen operating light which provides brilliant white light ensuring excellent visibility for field dentistry. The dual-voltage ALU-29CF features a compact lamp head, flexible gooseneck, telescoping tripod stand and padded carrying case. This light is highly portable and will fit in the mil-spec hard shell case included with the ADC-01CS Command Air Portable Dental Chair for easy deployment. -
Page 4: Lamp Controls
LAMP CONTROLS: 1. POWER SWITCH - On/Off control of ALU-29CF Light. Lamp should illuminate when turned on. 2. BRIGHTNESS KNOB - Provides variable intensity control of lamp. Turn clockwise to increase lamp intensity, or counterclockwise to decrease intensity. 3. DUAL VOLTAGE SWITCH - Allows this light to be used with either 110 or 220 VAC power sources. Rotate switch to the proper voltage-source position. -
Page 5: Changing The Fuse
WARNING: Do not turn the halogen Lamp ‘On’ Step 5 - Cover Lamp without the Guard/Lens Assembly installed. The Lamp emits harmful UV radiation and damage to eyes and skin could result if Assembly Lens (UV HEAT SHIELD LAMP Filter) is not in place. DISK WARNING: Halogen bulb is HOT ! Operating the Lamp without the Guard installed can cause burns! -
Page 6: Parts Diagram
Aseptico ALU-29CF Command Air Portable Light Figure 3 - Parts Diagram PCB Assembly Page 6... -
Page 7: Parts List
PARTS LIST Item Part Number Quantity Lamp Head, Guard & Lens Assy w/Clips 820002 FTB 20watt/12volt 10° Lamp, 820001 Heat Shield Tube 461355-08 Heat Shield Disk 461356-08 SMS Stnls PhdPhl 10x3/4 510305 O-Ring, 2.0 OD x 0.093 520045 Socket, Porcelain 820025 Adapter, Goose-neck/Lamp 460257-08... - Page 8 Aseptico shall be the sole arbiter of such action. In the event of alleged defect under warranty, the purchaser is to notify Aseptico's Customer Service Department promptly. Customer Service will provide instructions, usually directing that the product be returned for service.
