TKS AGRI Conveyor TR Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TKS
Operator's manual -
Spare parts list
Conveyor TR
IT_06
Conveyor TR - EN Issue 1, 05-2016
988784
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGRI Conveyor TR and is the answer not in the manual?

Questions and answers

Summary of Contents for TKS AGRI Conveyor TR

  • Page 1 Operator’s manual - Spare parts list Conveyor TR IT_06 Conveyor TR - EN Issue 1, 05-2016 988784...

  • Page 2: Table Of Contents

    Content 1 GENERAL SAFETY INSTRUCTIONS........4 2 PREPARING A NEW MACHINE .
  • Page 3 2 Preparing a new machine ......... 20 2.1 Installing the power supply .

  • Page 4: General Safety Instructions

    T. Kverneland & Sønner AS, Kvernelandsvegen 100 N-4355 Kverneland Norge declare that the product: TKS - Conveyor TR has been built in conformity with the Machine Directive (2006/42/EC) and meets the relevant fundamental health and safety requirements. Kverneland, 03-2013 Tønnes Helge Kverneland...

  • Page 5: Guarantee

    Claims must be reported within the guarantee period. The dealer must complete a claims form for each case covered by a guarantee and send it to TKS or TKS’s distributor/importer within the 10th of the month following the one in which the defect was reported.

  • Page 6: Introduction

    A network of helpful dealers will be able to advise you on its use, as well as provide servicing and spare parts. All TKS products are designed, tested and built in close cooperation with farmers and machine workshops to ensure optimal effi ciency and reliability.

  • Page 7: Technical Data - Conveyor Tr

    1.4 Technical data - Conveyor TR 1.4.1 Model description and area of use The universal Conveyor TR with a length of 3–9 metres is a lightweight, fl exible structure for the practical handling of materials, which can be easily adapted to all medium-weight materials such as: wood, chippings, timber waste, potatoes, onions, root vegetables, pellets, silo feed, ice, fi...

  • Page 8: Machine Identifi Cation

    1.4.2 Machine identifi cation The machine’s serial number and the manufacturer’s address are written on a plate on the machine. See the illustration on this page. The machine‘s serial number and the delivery year should be written below. Please use this information when making any enquiries about spare parts or servicing. This product is CE marked.

  • Page 9: Main Dimensions - Conveyor Tr

    1.4.3 Main dimensions - Conveyor TR All measurements are in mm. IT_01 IT_02 IT_12...
  • Page 10 The refi lling funnel (A) should be used on slopes exceeding 35 . Max slope is 45 See extra equipment. Example: Conveyor TR length of 6 m. Slope 30 Height to top end 2,85 m Length from rear end 5,40 m IT_04 Height in metres Slope 40...

  • Page 12: Safety

    Please pay particular attention to this symbol. Safety It designates a safety risk, and describes precautions that must be taken to avoid accidents Before operating, adjusting or repairing the machine, the user, technician or owner should familiarise himself with the safety instructions contained in this installation manual.
  • Page 13 Maintenance Make sure that the machine is maintained satis- factorily and kept in good condition. Never make alterations to the machine’s struc- tures. The machine’s working area This must be physically cordoned off or locked in order to prevent hazards for people and animals.

  • Page 14: Additional Safety Instruction

    1.5.2 Additional safety- The machine is marked with a warning signs. If these signs are damaged, they must instructions be replaced. The order number is shown on the illustrations in this section. Fig. 4 for their location on the machine. Warning sign UH220532 (Fig.

  • Page 15: Overview Of Safety Risks

    1.5.3 Overview of safety risks UH220532 UH220539 988010 IT_15 Fig. 4 IT_07...

  • Page 16: Lifting The Machine With A Crane

    Be particularly careful when starting a new machine for the fi rst time. Installation faults, incorrect operation, etc. may lead to expensive repairs and loss of earnings. The TKS product guarantee does not cover damage resulting from failure to follow the recommendations contained in the instruction manual.

  • Page 17: Lifting Point

    1.5.6 Lifting point The indicated lifting point must be used when lifting. IT_15 Fig. 5...

  • Page 18: Recycling - Waste To Resource

    - waste to resource - TKS’s products rely on electrical and electronic components in order to work. These fall under the generic term of EE products. TKS’s products use typical components such as cables, switches, motors, control units, etc. When TKS products are thrown away those components containing contaminants should be treated and sorted in such a way that they do not pollute the environment.

  • Page 20: Preparing A New Machine

    2 Preparing a new machine IT_08 Fig. 6...
  • Page 21 The Conveyor TR is packed and delivered as per the illustration. See Fig. 6 When assembling the TR Conveyor TR, remember to dispose of any cardboard, straps and plastic inan environmentally friendly man- ner. Fitting of new Conveyor TR: • Fit a 1 m return section (A) together with one or more mid-sections (B), depending on the required length.

  • Page 22: Maintenance And Care

    2.1 Installing the power supply All electrical installations must be carried out by an authorised electrician. Use a supply cable with the correct cross section (2,5 mm Adjust the motor protection to a suitable current draw: 230V = 9A 400V = 6A 3 Maintenance and care Checklist for maintenance and care...
  • Page 23 750 Nm Storing the Conveyor TR If the Conveyor TR is to be left unused for some time, do the following: TKS recommends using compressed air when cleaning. Obs! TKS does not recommend high-pressure washers when cleaning equipment. Water may seep through the seals! •...

  • Page 24: Lubrication

    3.1 Lubrication Component / location Quantity Action Operating 1 Lubricating nipple - bearings operating Lubrication 10 h 2 Lubrication nipple - bearings return side Lubrication 10 h Oil change, worm Amount 0,14 litre AGIP KLUBER SHELL MOBIL Telium VSF 320 Syntheso D220 EP Tivela Oil WB Glygoil 30 SHC 630...

  • Page 25: Tightening The Belt

    3.2 Tightening the belt It is important that the belt is taut. This should be checked at regular intervals. • Before tightening the belt, the bearing must be loosened at the two locking screws (A) on both sides. • The actual tightening is carried out by turning the tightening screw (B) on both sides of the return side.

  • Page 26: Circuit Diagram - Conveyor Tr

    4 Circuit diagram - Conveyor TR...

  • Page 29: Notes

    Notes...

  • Page 30: Spare Parts List

    5 Reservedelsliste / Spare parts list Conveyor TR Gyldig fra serienr.:/Valid from serial no. Ved bestilling av deler må en merke seg følgende: Oppgi alltid serienummer. Dette står på identifi seringsskiltet. Oppgi delenummer og benevnelse. Referansenummeret brukes bare for å sammenholde deletegning av betegnelse i lista og skal derfor oppgis.
  • Page 31 Innhold Content Fig. Side/Page TRANSPORTØR TR CONVEYOR TR FOT STATIV 3-6M 20-40 SUPPORTING FOOT 3-6M 20-40 FOT STATIV 5-9M 20-40 SUPPORTING FOOT 5-9M 20-40 STYRESKAP CONTROL CABINET...
  • Page 32 Fig. 1 T2_01...
  • Page 33 CONVEYOR TR Utgave: Redskap: Issue: Implement: Dato: Enhet: 12-05 Date: Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: 273646 KLEMLIST TRAKT CLAMP 910306 PLATESKRUE 4,2X16 PLATE SCREW 4,2X16 Valid up to R045 273627 SIDEPLATE RETUR H. SIDE PLATE RETURN RH.

  • Page 34: Spare Parts List

    Fig. 1 T2_01...
  • Page 35 CONVEYOR TR Utgave: Redskap: Issue: Implement: Dato: Enhet: 12-05 Date: Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: GJELDER OPP TIL SERIENR. R014 VALID UP TO SERIALNR. R014 Galv skjøt 187 273672 BELTE M/MEDBRINGER FOR 3M CONVEYOR BELT 3M 273661 BELTE M/MEDBRINGER FOR 4M...
  • Page 36 Fig. 2 T2_02...
  • Page 37 Utgave: CONVEYOR TR Redskap: Issue: Implement: Dato: Enhet: 12-05 Date: Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: Serialno.: Valid up to R045 273603 SIDEPLATE DRIFT V. SIDE PLATE DRIVE LH. Valid from 046 R 273688 SIDEPLATE RETT DRIFT V.
  • Page 38 Fig. 2 T2_02...
  • Page 39 CONVEYOR TR Utgave: Redskap: Issue: Implement: Dato: Enhet: 12-05 Date: Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: Serialno.: 911005 6KT. SKRUE M10X20 HEX. BOLT M10X20 910795 6KT. SKRUE M8X45 HEX. BOLT M8X45 910823 6KT. SKRUE M8X25 HEX.
  • Page 40 Fig. 3 T2_03...
  • Page 41 CONVEYOR TR Utgave: Redskap: Issue: Implement: FOT STATIV 3-6M 20-40 Dato: Enhet: 16-05 Date: SUPPORTING FOOT 3-6M 20-40 Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: 274081 NEDRE KANAL LOWER CANAL 274082 ØVRE KANAL UPPER CANAL 274083 KRYSSTAG LANG CROSS STAY LONG...
  • Page 42 Fig. 4 T2_05...
  • Page 43 CONVEYOR TR Utgave: Redskap: Issue: Implement: FOT STATIV 5-9M 20-40 Dato: Enhet: 16-05 Date: SUPPORTING FOOT 5-9M 20-40 Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: 27392 FOT STATIV 5-9m 20-40 SUPPORTING FOOT 5-9m 20-40 273470 NEDRE KANAL LOWER CANAL 273471...
  • Page 44 Fig. 5...
  • Page 45 CONVEYOR TR Utgave: Redskap: Issue: Implement: STYRESKAP Dato: Enhet: 13-09 Date: CONTROL CABINET Unit: Fig: Ref. Delenr. Ant. Anmerkning: Gjenstand: Description: Part nr. Qty. Note: 27718 STYRESKAP CONTROL CABINET 951516 NØDSTOPPKNAPP TRYKK/VRI EMERGENCY STOP BUTTON 951517 BRYTER NO M GRØNT LYS, 8 SWITCH GREEN LIGHT 955014 PAKKN.
  • Page 46 TKS is a family owned company with a strong brand name. We are providing our customers with a unique and complete range of high quality products. www.tks-as.no T. Kverneland & Sønner AS, Kvernelandsvegen 100 N-4355 Kvernaland Norway e-post : post@tks-as.no...
