Installation Manual
IP HANDSET
Model FB-8001
SAFETY INSTRUCTIONS ................................................................................................ i
SYSTEM CONFIGURATION ........................................................................................... ii
1. MOUNTING................................................................................................................. 1
1.1 IP Handset ............................................................................................................................1
1.2 LAN Cable Fabrication..........................................................................................................3
2. SETTING UP THE EQUIPMENT ................................................................................ 4
PACKING LIST ............................................................................................................ A-1
OUTLINE DRAWINGS ................................................................................................ D-1
www.furuno.com
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Advertisement
Summary of Contents for Furuno FB-8001
-
Page 1: Table Of Contents
Installation Manual IP HANDSET Model FB-8001 SAFETY INSTRUCTIONS ....................i SYSTEM CONFIGURATION ................... ii 1. MOUNTING......................... 1 1.1 IP Handset ..........................1 1.2 LAN Cable Fabrication......................3 2. SETTING UP THE EQUIPMENT ................4 PACKING LIST ......................A-1 OUTLINE DRAWINGS ....................D-1 www.furuno.com... -
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Read these safety instructions before you operate the equipment. Indicates a condition that can cause death or serious injury if WARNING not avoided. Indicates a condition that can cause minor or moderate injury if CAUTION not avoided. Mandatory Action Warning, Caution Prohibitive Action WARNING... -
Page 3: System Configuration
(Up to 4 connections) Communication Unit FB-2001 12-24V DC Relay AC/DC Power External Alarm AY34001 Supply Unit 406080A-FUR-001 IP Handset Cradle FB-8001 Alarm Panel FB-3101 100-240V AC USB-RS232C Converter FB-3003 Network Equipment, IP Handset Network Equipment, IP Handset Environmental category Units Category... -
Page 4: Mounting
MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. IP Handset The IP Handset functions as a display and it may also be used for normal voice com- munication. - Page 5 1. MOUNTING 5. Connect the LAN cable from the Communication Unit (MOD-Z072-050 (5 m), sup- plied as installation materials) to the open RJ-45 port in the cradle. If the bottom cable entry is used, secure the LAN cable with a cable tie (supplied). Note: For how to fabricate the LAN cable, see section 1.2.
-
Page 6: Lan Cable Fabrication
1. MOUNTING LAN Cable Fabrication Fabricate the LAN cable (MOD-Z072-050 (5 m), supplied as installation materials) be- tween the communication unit and cradle (IP handset) as follows. The optional FR- FTPC-CY cable (10, 20, 30 or 50 m) is available for the IP handset. Note: This equipment can use either straight or crossover cables. -
Page 7: Setting Up The Equipment
SETTING UP THE EQUIPMENT Set up the FELCOM251/501 from the Web interface and IP handset user menu after the installation. For details of the Web interface and IP handset user menu, see the operator’s manual (OME-57050). -
Page 8: Packing List
ＰＡＣＫＩＮＧ ＬＩＳＴ 16AZ-X-9859 -0 FB-8001-J/-E N A M E DESCRIPTION/CODE № O U T L I N E Q'TY ユニット UNIT ﾊﾝﾄﾞｾｯﾄ FB-8001-* IP HANDSET 000-036-303-00 付属品 ACCESSORIES ﾌｨﾙﾀｰｸﾘｰﾅｰ 19-028-3125-6 LCD CLEANING CLOTH 100-360-676-10 工事材料 INSTALLATION MATERIALS 工事材料 CP16-06801 INSTALLATION MATERIALS 001-537-170-00 図書... - Page 9 001-537-170-00 16AZ-X-9401 CODE NO. TYPE CP16-06801 工事材料表 INSTALLATION MATERIALS 番 号 名 称 型名／規格 数量 略 図 用途／備考 Q'TY OUTLINE NAME DESCRIPTIONS REMARKS (組)CHASSIS-CRADLE CP16-06802 CHASSIS-CRADLE ASSEMBLY CODE 001-546-060-00 +ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ 3X20 SUS304 SELF TAPPING SCREW CODE 000-167-940-10 +ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ 4X40 SUS304 SELF-TAPPING SCREW CODE 000-162-606-10 ｺﾝﾍﾞｯｸｽ...
- Page 12 The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : MAR 2019 Printed in Japan All rights reserved. Pub. No. IME-57050-A (GREG ) FB-8001 0 0 0 1 9 5 8 8 4 1 0...
