HS-3644 Installation and Operating Manual 1.0 Introduction 1.1 General Features The HS-3644 is a remote annunciator for use with Harrington’s HS-3400, HS-3100/HS-3200, and HS-3030 Fire Alarm Control Panels with the following features: • Designed to meet the requirements of NFPA 72, 2002 Edition, and UL864, Control Units for Fire Protective Systems, 1996 Edition •... -
Page 10: Specifications
HS-3644 Installation and Operating Manual 3.0 Specifications 3.1 Environmental Specifications Operating Temperature 0ºC – 49ºC / 32ºF – 120ºF Humidity 85% RH non-condensing (maximum) 3.2 Electrical Specifications Operating voltage (min – max) 16 to 28 V , power limited Maximum input voltage ripple 3.0V... -
Page 11: Physical Dimensions
HS-3644 Installation and Operating Manual 3.5 Physical Dimensions Trim Plate Figure 1:Trim Plate Dimensions Display Plate ALARM SUPERVISORY SILENCE TROUBLE MONITOR RESET AC ON LAMP HS-3644 GROUND FAULT TEST Figure 2: Control Panel Dimensions... -
Page 12: Figure 3: Surface Mount Backbox Dimensions
HS-3644 Installation and Operating Manual Surface Mount Backbox Figure 3: Surface Mount Backbox Dimensions... -
Page 13: Installing The Hs-3644
HS-3400 Control Unit The HS-3400 Control Unit is connected to the HS-3644 Annunciator by four (4) wires, two (2) for communications and two (2) for power. The communications wiring is polarity sensitive. Refer to... -
Page 14: Figure 6: Hs-3644 Connected To Hs-3100/3200 Facp, Using Hs-3100/3200 Aux Power
HS-3644 Installation and Operating Manual The HS-3100/3200 Control Unit is connected to the HS-3644 Annunciator by four (4) wires, two (2) for communications and two (2) for power. The communications wiring is polarity sensitive. Refer to the following diagram: HS-3100/3200... -
Page 15: Figure 8: Hs-3644 Connected To Hs-3030 Facp, Using Hs-3030 Aux Power
MR-2644 Installation and Operating Manual HS-3030 Control Unit The HS-3030 control unit is connected to the HS-3644 Annunciator by four (4) wires, two (2) for power and two (2) for communications. The wiring is polarity sensitive. The HS-3030 panel requires that the HS-3109-3 communications board be installed. -
Page 16: Connecting Multiple Hs-3644 Annunciators
J3. These are used to select one of eight (8) possible addresses on the fire alarm control panel's annunciator port. The HS-3644 addresses appear as 9-16 on the fire panel, as 1-8 are used for HS-2802 (LED) annunciators. The default value is 9, and will need to be changed only if there is more than one HS-3644 connected to the panel. -
Page 17: Mounting
7. Mount the trim-ring using the four painted screws included in the Hardware Pack. 5.2 Surface Mounting These instructions apply specifically to the HS-3644 when used in conjunction with the HS- 3644SMB or HS3644SM surface mount backbox. Please refer to Section 1.3 for further details regarding the available ordering options. -
Page 18: Operating The Hs-3644
HS-3644 Installation and Operating Manual 6.0 Operating the HS-3644 ALARM SUPERVISORY SILENCE TROUBLE MONITOR RESET AC ON LAMP HS-3644 GROUND FAULT TEST 6.1 Displays • When the system is normal and AC power is present, the AC ON light is on and all other lights are off. -
Page 19: Appendix
Damage arising out of any other abuse, mishandling or improper application of the products. Harrington Signals’ liability for failure to repair the product under this warranty after a reasonable number of attempts will be limited to a replacement of the product, as the exclusive remedy for breach of warranty. -
Page 20: Fcc Compliance Statement
HS-3644 Installation and Operating Manual 7.2 FCC Compliance Statement CAUTION: Changes or modifications not expressly approved by the manufacturer could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 24 HARRINGTON SIGNAL INC. FIRE ALARM Harrington Signal Inc. 2519 4th Avenue Moline, IL 61265...
