- Page 1 PRESENTATION SCALER SWITCHER’S MANUAL Phone: 91-79-55310266 / 55124898 (M)0-98253-50221 www.interfaceproducts.info...
- Page 2 A unit whereby multiple VGA, COMPOSITE VIDEO & SVIDEO inputs along with their respective AUDIO can be switched to individual respective outputs along with their AUDIO with VGA as individual or scaled output. PRESENTATION SCALER SWITCHER by Milestone is available in three models as follows: Models Inputs...
- Page 3 Models: ML-440PS ML-444PS Technical Specifications Input Connecters VGA (D-15 Female VIDEO (RCA Standard) S-VIDEO (4 Pin mini din) Audio (3 pin Captive screw) Output Connecters VGA (D-15 Female VIDEO (RCA Standard) S-VIDEO (4 Pin mini din) Audio (3 pin Captive screw) LED Indication Power VGA Audio...
- Page 4 Remote Connectivity RF Remote connectivity with D9M x 2 D9M x 2 Cable through Remote/Keypad D9M x 2 D9M x 2 D9F × 1 D9F × 1 RS 232 Interface Optional Optional RS485 / RS422 Interface Operating distance from remote 50 M 50 M keypad.
- Page 5 Remote contact closure/ remote keypad Rear panel has two D9 male connector, operational at a distance of 50 meters. Milestone’s remote keypad or any other remote contact closure can be connected at this connector. The connector diagram for D9 male connector is as follows: D-9 Male –1...
- Page 6 CH11- S-Video, Audio 3 CH12- S-Video, Audio 4 Clear Note: 1. To select VGA Audio1, short 1and 9 through contact switch or use Milestone’s remote keypad. Remote RS232 interface D9 female connector from rear panel is used for selecting the switcher through RS232C Interface.
- Page 7 Channel / Input Decimal ASCII Channel 5 – Video Audio 1 35, 21 Channel 6 – Video Audio 2 36, 21 Channel 7 – Video Audio 1 37, 21 Channel 8 – Video Audio 2 38, 21 Channel 9 – S-Video Audio 1 39,21 Channel 9 –...
