Summary of Contents for Shenzhen Chitwan Plastic QW
- Page 1 QW Four-Axis Aircraft Operation Instruction Shenzhen Chitwan Plastic Co., Ltd. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
-
Page 2: Table Of Contents
Operation Instruction Content Disclaimer: ................................3 Precautions for Product Use ..........................4 Precautions for Battery Use and Charging ......................5 Product List: ................................ 6 Introduction ................................. 7 Aircraft and remote control instructions ......................7 Preparation Before Flight ..........................12 Test Flight ................................11 Loss of control and one key return ........................ -
Page 3: Disclaimer
QW aircraft is an excellent multiaxis aircraft, in the circumstance that the power supply is normal and the components are not broken, the aircraft can supply remarkable flight experience. Although... -
Page 4: Precautions For Product Use
15. Damage is caused by the battery, such as the misuse of the match between protective circuit, battery pack and the charger. 16. Other damages which do not belong to the range of responsibilities of Chitwan. Precautions for Product Use 1. -
Page 5: Precautions For Battery Use And Charging
Precautions for Battery Use and Charging 1. The battery should not be placed in water, the battery should be kept in cool and dry area if it will not be used for a long time. 2. Forbid the mixed use of the battery of other type and variety. 3. -
Page 6: Product List
Product List: Fuselage Paddle Foot stool 3S charger 3S lithium battery Remote control Viewing screen Wrench of the paddle Battery of the remote control 1×4 Charger of the remote control Bag of the materials PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn... -
Page 7: Introduction
Introduction Chitwan aircraft is a FPV (First Person View) four-axis aicraft which was developed by our company for the model aircraft enthusiasts, and it has a built-in camera and GPS and it integrates image transmission, real-time display and videorecording. All parameters have been set before delivery and users just need to conduct simple installations of the propellers and batteries before realizing the FPV flight and enjoying the real fun of flight. - Page 8 Front side of remote control screen clip video channel button button: photograph exit video menu transmission minus- antenna plus+ screen power on button switch button switch (right) (left) neutral shift self returning stabilization landing fixed height hovering rudder (right) rudder (left) pitch accelerator roll...
- Page 9 Back side of remote control 5.8G channel number 433M antenna indication lithium battery activation button battery compartment: 4 of 14500 (5#) 3.7V lithium batteries PDF 文件使用 "pdfFactory Pro" 试用版本创建 ÿ www.fineprint.com.cn...
-
Page 10: Preparation Before Flight
Preparation Before Flight 1. Remote control power on 1. Open up the battery compartment on the back of remote control. 2. Put into 4 standard lithium batteries of 14500 (5#) according to the positive and negative pole logo. 3. Close the battery compartment cover. 4. - Page 11 4. Open the remote control 1. Place the left and right button switches on the topmost gear shift (left side self-stabilization+ right side neutral shift). 2. Push the power switch upwards to start the remote control (indicator light is blue, working status).
- Page 12 5. Aircraft power on 1. Find an outdoor open space and put the aircraft horizontally. 2. Open up the battery compartment and put in batteries. 3. Connect the power line of the batteries to the aircraft and make sure the sound of electronic speed controller is normal (1---3---) 4.
-
Page 13: Test Flight
Precautions • In order to avoid accidents, every time before unlocking except for ensuring the two button switches in the topmost shift, check the screen to ensure it is in STAB mode and DISARMED status and the accelerator is in the lowest shift. •... - Page 14 1. Find an outdoor open space, horizontally place the aircraft more than 3 m from you, especially the children to avoid accidental injury. 2. Starting sequence: (1) Check and make sure the two button switches on remote controllers in the topmost shift, the left rocker accelerator in the lowest position and the right rocker in the middle position.
- Page 15 • The built-in compass of the aircraft has a comparatively high sensitivity and is the sensor easy to get interference; therefore, please keep it flying away from the position with much ferromagnetic materials, otherwise the internal magnetoresistive sensor will be affected by the ferromagnetic materials and work abnormally.
- Page 16 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn...
-
Page 17: Loss Of Control And One Key Return
Loss of control and one key return The aircraft has built-in compass and GPS, and for every flight mission, the unlocking position is the returning location. Loss of control protection mechanism: 1. If remote control signal loss is more than 5 seconds, the aircraft will automatically enter into the automatic landing mode. -
Page 18: Low Voltage Protection
Low voltage protection Aircraft three-level voltage alarm protection mechanism: 1. When the aircraft voltage is lower than 11.1V, the remote control screen will give warning “Battery Low!”, and it is necessary to return and land the aircraft as soon as possible to replace the batteries. -
Page 19: Intellectual Property Rights
Intellectual Property Rights The intellectual property rights of this product and manual belongs to Chitwan, and without the written authorization any organization or individual shall not make any form of reprint, copy or publication. In case of reference and publication, the source of Chitwan shall be indicated and no reference, abridgement or modification which is contrary to the Operation Manual shall be made.
