Summary of Contents for RackSolutions 2UKIT-101
- Page 1 Patent(s) Pending 2U Adapter Bracket Set Installation Instructions Kit P/N: 2UKIT-101...
-
Page 2: Kit Contents
Kit Contents Brackets: 059 – 2 Bend Bracket Rack Mount Hardware Kit: 100 – 2 Bend Bracket (12) 12-24 x 3/8” Screws 290 – 2 Bend Bracket 10-32 x 3/8” Screws 200 – 4 Bend Bracket 12-24 Square Nuts 270 – 4 Bend Bracket 12-24 Cage Nuts 350 –... - Page 3 Bracket Installation Instructions (continued) Step 3. This chart determines which adapter brackets you will need and where they should be 100, 290, 200, 270, and 350. Bracket 059 = 0.59” wide with 2-bends Bracket 290 = 2.90” wide with 2-bends Bracket 200 = 2.00”...
- Page 4 Bracket Installation Instructions (continued) Step 4. Adapter Location on Rail: All adapters in this kit occupy “2U” of rack space. Be sure all six holes in the adapter line up with holes in the rack rail. Page 4...
- Page 5 Bracket Installation Instructions (continued) Step 5. Install the brackets determined by Step 3. (2) Front Adapters Type 059, 100 or 290 Mount with (2) 12-24 Screws per Bracket (2) 12-24 Screws per Bracket Mount Depth (1) Rear Adapter See Note 3 if holes are not threaded Refer to Slide Installation Instructions on Page 6 Assembly Notes:...
-
Page 6: Appendix A - Double 2Post Front-Adapters
Slide Installation Instructions Installing the Dell Slides and Cable Management Arm per Dell instructions. Align the back of the slide as shown below. Align the front of the slide so the Blue Button is in the top hole of the bracket. Blue Button Threaded Hole Appendix A - Double 2Post Front-Adapters... -
Page 7: Appendix B - Dual Rear-Adapters
Appendix B - Dual Rear-Adapters This step is only necessary for Mounting Depths from 24” to 26” Attach the two brackets (indicated in step 2) together as shown below using (2) Cage Nuts and (2) 12-24 screws. Be sure the longer bracket is at the rear. Install the bracket pairs to the Rear Rack Rail as shown below using (2) 12-24 screws. - Page 8 Warranty Statement Innovation First, Inc. warrants our products against defects in material and workmanship for a period of one (1) year from the date of purchase. Innovation First, Inc. liability shall be limited to repairing or replacing, at our option, any defective product.
