Bush Baby Stealth Garage
Manual
SKU: BBSGarage
1
Version 2.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BBSGarage and is the answer not in the manual?

Questions and answers

Summary of Contents for Bush Baby BBSGarage

  • Page 1 Bush Baby Stealth Garage Manual SKU: BBSGarage Version 2.1...
  • Page 2 THANK YOU FOR PURCHASING THE BBSGARAGE Please read this manual before operating the device and keep it handy. Your purchase should include: 1 x BBSGarage 1 x Remote Control 1 x USB-B Cable 1 x Wall AC Adapter 1 x MicroSD Card Reader...
  • Page 3 GET FAMILIAR WITH YOUR BBSGARAGE Version 2.1...
  • Page 4 Version 2.1...
  • Page 5 OPERATING THE BBSGARAGE Note: If you are not located in the US, or if you intend to use this product anywhere other than the US, you will need to purchase a converter in order to use the AC wall plug in and avoid damaging the product.
  • Page 6 2. Plug the other end of the USB cable into the AC wall adapter. 3. Wait 6 to 8 hours. a. The larger the battery capacity, the longer it takes to charge. HOW TO TURN ON THE BUSHBABY STEALTH CAMERA 1.
  • Page 7 a. Videos will be recorded continuously and saved in 20 minute intervals. HOW TO SET UP MOTION DETECTION 1. In Standby mode, press the Motion Detection button one time (see page 4). The indicator light will flash three times and then turn off. 2.
  • Page 8 b. If you pressed the Motion button, press the Motion button once more. 2. The device will reenter Standby mode (solid light). HOW TO TAKE A PICTURE 1. While in Standby mode, press the Picture Button one time (see page 4). When the indicator light flashes one time, 1 picture will be taken accordingly.
  • Page 9 spring resistance before the card clicks in to place. a. Never force the card into the Card Slot under any circumstances. Otherwise, the Bird House unit or the MicroSD card itself will be damaged. 4. To remove the SD card, gently push the card in so that it clicks.
  • Page 10 IMPORTANT NOTICE: Ensure that the device is off before inserting the MicroSD card. Otherwise, potential corruption of the card file(s) may occur. RETRIEVE THE FILES TO YOUR PC 1. Remove the MicroSD card from your device and connect it to your computer. See page 3 to locate the MicroSD card slot on your device.
  • Page 11 Or… Go to Start > Computer > Removable Disk Version 2.1...
  • Page 12 3. Open the Removable Disk drive. 4. Open the DCIM folder. 5. Open the folder featuring a sequence of numbers. 6. Double click the file you want to view.  VLC Player is recommended for watching videos. If you are having video playback issues such as a completely black video recording or “squiggly lines”, we recommend you use VLC media player to play back the videos.
  • Page 13 Next, go the location you want the save the file to. Right click your mouse, and then chose “Paste.” This will copy the file to your computer.  To delete a file, right click your mouse on the file name and choose “Delete” from the menu.
  • Page 14 2. Choose “All Bush Baby Stealth” and your time zone in the dropdowns and click download. 3. Right click and “cut” the downloaded time file. 4. Locate “Removable Disk” inside the (My) Computer folder. a. Go to Start > Computer >...
  • Page 15 Alternatively, if you cannot get the above method to work, do the following: 7. Right click anywhere in the blank white space. 8. Scroll down to “New”. 9. Click “Text Document”. 10. Rename “New Text Document” as “time”. The title must be in all lowercase letters! Before Step 8 Version 2.1...

  • Page 16: Troubleshooting

    After Step 8 11. Open the text document. 12. Enter the date/time in the following format: a. Example: 2016/08/08 15:00:00 13. Save the text document. 14. Safely eject the MicroSD card from your computer and reinsert it into your device. Power on the device and begin a test recording to confirm date/time setting succeeded.
  • Page 17 THE DEVICE WON’T TURN ON  Charge the device for at least 6-8 hours before the first use.  Make all charging cables are securely connected when charging. THE DEVICE ISN’T CHARGING  Replace the battery or charging cable.  If you are charging via a wall power source, you may need to charge via your PC.
  • Page 18  You may have a 64GB+ card and need to format it properly. Visit www.mgidownloads.com/Software and download the “guiformat.zip” file. Extract the files and follow the instructions in the “64GB SD Card Formatting.pdf” document. THE INDICATOR LIGHT IS FLASHING RED/BLUE ...
  • Page 19 SPECIFICATIONS Video Resolution 1920x1080 Video Format Frames per Second Vision Angle 75° Motion Detection Lux Rating 1LUX Water Resistant Battery Life 30 Hours Type of Memory External MicroSD Card Memory Capacity 4GB – 128GB USB Interface 2.0 USB Player Software VLC recommended Operating Systems Windows XP &...
  • Page 20 Version 2.1...
  • Page 21 QUALITY CONTROL CHECKLIST ☐ Remote ☐ Wall AC Adapter ☐ USB-B Cable ☐ MicroSD Card ____GB ☐ MicroSD Card Reader ☐ User Manual ☐ BBSGarage QC Tech: _________________________________________ Date: ______________________________ Version 2.1...
