-N3

ORAYA

ATACUBE

User Manual

Version: 1.1 / March 2020

Table of Contents

Need help?

Do you have a question about the XORAYA DATACUBE-N3 and is the answer not in the manual?

Questions and answers

Summary of Contents for X2E XORAYA DATACUBE-N3

Page 1 ORAYA ATACUBE User Manual Version: 1.1 / March 2020...
Page 2 This user manual is protected by copyright; all usual rights reserved. Reproduction of this user manual, even in part, is only permitted with the approval of X2E GmbH. Any infringement will result in liability for damages and may result in criminal prosecution.
Page 3: Table Of Contents
User Manual ORAYA ATACUBE Table of contents Introduction ..................... 4 Intended use .................... 4 Delivery contents ..................4 Safety ...................... 5 Safety labels on the device ..............5 General safety instructions ..............5 Connections and controls ................ 6 Installation ....................9 Mounting ....................
Page 4: Introduction
 optionally: X RSU(s) ORAYA Check to ensure that the delivery is complete and all parts are in sound condition. If the deliv- ery is incomplete or supplied components are damaged, contact X2E immediately. Do not use damaged components.
Page 5: Safety
User Manual ORAYA ATACUBE Safety Safety labels on the device You find the following two safety labels on the X RSU front side. ORAYA Warning: Hot surface Please note the safety instruction Burning hazard due to hot surfaces (see chapter Connecting). Read this user manual completely before using the device for the first time.
Page 6: Connections And Controls
User Manual ORAYA ATACUBE Connections and controls Front view Back view...
Page 7 Input: 100 – 240 V AC, 50 – 60 Hz, 8 – 4 A Service LAN port (G) In case of errors, this port is used as a debugging interface by the X2E support team. USB 2.0 (H) and USB 3.0 ports (I)
Page 8 User Manual ORAYA ATACUBE 10GbE (J) and 40GbE LAN ports (K) Use these ports to connect the D -N3 to a switch or directly to your PC. ATACUBE Compatibility of Ethernet standards 1GbE and 10GbE are principally compatible to each other. Use a switch in between if there are connection problems.
Page 9: Installation
User Manual ORAYA ATACUBE Installation Mounting CAUTION Device damage due to overheating Overheating may result in malfunction or destruction of the D -N3. ATACUBE  Do not operate the D -N3 in the vicinity of heat sources. ATACUBE  Ensure adequate air circulation. ...
Page 10 User Manual ORAYA ATACUBE CAUTION Risk of injury due to sharp edges or falling down Sharp edges can cause cuts. Due to the weight of the X RSU, foot in- ORAYA juries are likely to occur when it falls down. ...
Page 11: Xoraya Suite
User Manual ORAYA ATACUBE Suite ORAYA The graphical user interface X Suite is available to configure and to control the ORAYA -N3. ATACUBE Supported operating systems:  Microsoft® Windows® 7 (32 Bit or 64 Bit)  Microsoft® Windows® 8 (32 Bit or 64 Bit) ...
Page 12: Network Settings
User Manual ORAYA ATACUBE Network settings The X Suite extra tool HWFinder enables access to a web interface to change the con- ORAYA figuration of the 10GbE (J) and 40GbE (K) LAN ports.  Start the X Suite. ORAYA  Click in the Windows notification area.
Page 13 User Manual ORAYA ATACUBE  In the menu on the left side, select the category Network configuration.  Click the desired port in the graphic.  Click one of the tabs Port A to Port D.  Activate the Editmode. ...
Page 14: Download
User Manual ORAYA ATACUBE Download The X Suite offers tools to download log data from connected X RSUs. ORAYA ORAYA Hdd-Download  Start the X Suite. ORAYA  Click Hdd-Download. Connect D ATACUBE  Connect the D -N3 to power source and PC and put one or more X ATACUBE ORAYA RSUs in (see chapter Connecting).
Page 15 User Manual ORAYA ATACUBE Select X ORAYA  Click on the check mark of the desired storage unit. Change RSU To eject a X RSU or to activate another device, click Change disk (5). ORAYA Select log data  Specify start date (a) and start time (b) of the desired time range. ...
Page 16 User Manual ORAYA ATACUBE Download selected log data  Specify the path.  Click Start download (4). The log data within the selected time range are transmitted to the PC. Statistical data Click the arrow behind Show download statistics (8) to switch between dif- ferent statistics.
Page 17: Automatic Download Service
User Manual ORAYA ATACUBE Automatic download service This X Suite extra tool is a server, which automatically downloads log data from se- ORAYA lected D s (and dataloggers). ATACUBE  Start the X Suite. ORAYA  Click in the Windows notification area. ...
Page 18 User Manual ORAYA ATACUBE In the category White list, select the devices for the automatic download service.  Click Refresh the device list (a) to search for D s and dataloggers in the net- ATACUBE work again.  Select the check boxes (b) for all devices that you want to add to the white list. For a selected device, the symbol (c) changes from if it is currently not reachable.
Page 19: Update Firmware
User Manual ORAYA ATACUBE Update firmware  Start the D -N3 web interface (see chapter Network settings). ATACUBE  In the menu on the left side, select the category Firmware-Update.  Click Browse… (1) and select a suitable XSWU file. ...
Page 20: Cleaning
Never open the D -N3. ATACUBE  Maintenance and repair must be carried out by X2E personnel only.  In case of malfunctions or damages, please contact X2E via e-mail to get information about returning the D -N3: xoraya-return@x2e.de ATACUBE Transport ...
Page 22 X2E GmbH Jahnstrasse 2b 76870 Kandel GERMANY Phone +49 7275 9143 100 +49 7275 9143 109 E-Mail info@x2e.de Internet http://www.x2e.de...
