Mobilate Roami User Manual

Progressive
Hide thumbs Also See for Roami:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
IMPORTANT:
Save this manual for
future reference
Roami Progressive Mobility Aid
REF
100.100 - Roami - Rose Gold
100.101 - Roami - Rose Gold 2 Wheel
100.102 - Roami - Urban Blue
100.103 - Roami - Urban Blue 2 wheel
100.106 - Roami - Charcoal
100-107 - Roami - Charcoal 2 wheel
100-108 - Roami - Red
100-109 - Roami - Red 2 wheel
Manufactured by:
Mobilate
2733 Kanasita Drive #121
Hixson, TN 37343 USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Roami and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobilate Roami

Summary of Contents for Mobilate Roami

  • Page 1 Save this manual for future reference Roami Progressive Mobility Aid 100.100 - Roami - Rose Gold 100.101 - Roami - Rose Gold 2 Wheel 100.102 - Roami - Urban Blue 100.103 - Roami - Urban Blue 2 wheel 100.106 - Roami - Charcoal...

  • Page 3: Table Of Contents

    6.2 Using the Roami PMA like a Walker ......PG 22 6.3 Using the Roami PMA like a Rollator ......PG 23 6.4 Using the Roami PMA like a Stair Assist Up Stairs ..PG 24 6.5 Using the Roami PMA like a Stair Assist Down Stairs ..PG 29 6.6 Using your Roami PMA to Align Gait ......PG 34...

  • Page 4: Introduction

    Before using the Roami PMA: • Talk to your health care professional and make sure the Roami PMA is the right mobility aid for you. • Review this User Manual carefully. Pay extra attention to the safety information on pages 6 and 7.

  • Page 5: Contents Of Box

    2 x legs with Grip Feet 1 x 2.5mm Allen Key 1 x Instruction Booklet 1 x 2.5mm Allen Key 2.5mm Allen Key needed for assembly of the Roami PMA. ©Copyright 2020 Mobilate LLC All rights reserved PG 4 P/N: 400.160 Rev 3...
  • Page 6 PG 5 ©Copyright 2020 Mobilate LLC All rights reserved P/N: 400.160 Rev 3...

  • Page 7: Safety

    • Contact Mobilate for any questions regarding assembly, set-up and maintenance of the product. Important safety rules when using the Roami PMA: • Be aware of the surrounding surfaces when using the Roami PMA - such as electrical cords, debris etc. ©Copyright 2020 Mobilate LLC All rights reserved PG 6 P/N: 400.160 Rev 3...
  • Page 8 • The legs must be adjusted to the same height when using as a walker or a rollator. • Do not hang anything on either side of the Roami PMA frame (this includes the levers/handles on either side). This may cause the Roami PMA to tip or be unstable.

  • Page 9: Features

    4. FEATURES ©Copyright 2020 Mobilate LLC All rights reserved PG 8 P/N: 400.160 Rev 3...
  • Page 10 13. Leg cuff 14. Lower leg a. Grip foot b. Telescoping spring pin 15. Lower leg with wheel assembly a. Foot pedal b. Telescoping spring pin c. Wheel PG 9 ©Copyright 2020 Mobilate LLC All rights reserved P/N: 400.160 Rev 3...

  • Page 11: Assembly

    ASSEMBLY For safety and stability, your Roami PMA must be properly assembled before any use. Do NOT use unless it is properly assembled. Your Roami PMA comes almost fully assembled. You will need to simply install (affix) the rear legs and adjust the height on front and back legs prior to first use.

  • Page 12: Fitting The Rear Lower Legs

    5.1 FITTING THE REAR LOWER LEGS 5.1.1 Lay the folded Roami PMA on a flat surface. 5.1.2 Slide the Lower Leg (15) assembly inside the Rear Leg Upper (11) making sure to keep the Spring Pin (14b) inside the leg facing to the inside of the Rear Leg Upper (11) to align with the adjustment holes when fitted.
  • Page 13 You should adjust so that Spring Pins are in the same hole number on all 4 legs. Don’t worry about adjusting the overall product height yet, that will be addressed later in the manual. ©Copyright 2019 Mobilate LLC All rights reserved PG 12 P/N: 400.160 Revised December 2019...

  • Page 14: Unfolding The Roami Pma For Use

    If the Fold Lock (5) is in the vertical position, press the Safety Button (4), squeeze the Lever (3) and while holding the Lever (3) turn the Fold Lock (5) 90° to the horizontal position. Repeat for the other handle. The Roami PMA is now free to unfold.
  • Page 15 5.2.3 To unfold the Roami PMA, push the Rigidizer (12) away from you as shown. 5.2.4 All 4 legs will be touching the ground. ©Copyright 2019 Mobilate LLC All rights reserved PG 14 P/N: 400.160 Revised December 2019...
  • Page 16 7.6.1 for instructions on adjusting the Cam-Lok angle.) For safety and stability, you MUST turn the Fold Lock (5) 90º back to locked (vertical) position prior to using the Roami PMA as a walking aid. 5.2.6 Now turn the Fold Lock (5) 90º to the locked (vertical) position shown.

  • Page 17: Adjusting The Height To Suit The User

    Adjust the Lower Leg (15) heights by depressing the spring pins and sliding the Leg up or down. 5.3.3 Make sure all legs are set to the same height. The Roami PMA is now ready for use. ©Copyright 2019 Mobilate LLC All rights reserved PG 16 P/N: 400.160...
  • Page 18 Ensure all 4 Lower Legs are adjusted to the same height position and the Spring Pins (14b and 15b) are fully engaged in their holes after adjustment. PG 17 ©Copyright 2020 Mobilate LLC All rights reserved P/N: 400.160 Rev 3...

  • Page 19: Folding Up The Roami Pma For Storage

    With the Fold Lock (5) is in the vertical position, press the Safety Button (4), squeeze the Lever (3) and while holding the Lever (3) turn the Fold Dial (5) 90° to the horizontal position. Repeat for the other handle. The Roami PMA is now free to fold.
  • Page 20 5.4.2 To fold up the Roami PMA, pull the Rigidizer (12) up toward you when the product is standing up. 5.4.3 Unit is now folded and ready to transport. (Refer to 6.2 to unfold the Roami PMA for use.) PG 19 ©Copyright 2020 Mobilate LLC All rights reserved...

  • Page 21: Instructions For Use

    INSTRUCTIONS FOR USE The Roami PMA can be used in a number of different ways. The abilities of the user must match the capabilities of the Roami PMA. Pay close attention to highlighted safety information. ©Copyright 2019 Mobilate LLC All rights reserved PG 20 P/N: 400.160...

  • Page 22: Deploying And Retracting The Wheels

    Use the wheel option with care. There are no brakes. 6.1.1 Some models of the Roami PMA come with retractable wheels on the front legs. To engage the Wheel (15c), simply pushdown on the Foot Pedal (15a) until you feel it lock down and the wheel with the ground.

  • Page 23: Using The Roami Pma Like A Walker

    6.2.2 Step forward with your weaker leg first, putting weight on the palms. Keep within the boundaries of the Roami frame. Lift Roami with each step, then set back down. ©Copyright 2020 Mobilate LLC All rights reserved PG 22 P/N: 400.160 Rev 3...

  • Page 24: Using The Roami Pma Like A Rollator

    6.3 USING THE ROAMI PMA LIKE A ROLLATOR This option is intended for use on only flat surfaces! Never us the rollator option on stairs or sloping surfaces. Always raise the wheels before going up or down stairs and on sloping surfaces.

  • Page 25: Using The Roami Pma Like A Stair Assist Up Stairs

    Do not use on long flights of stairs such as between floors of a home or building. • Make sure the Roami PMA is working properly, and that parts are locked into place.
  • Page 26 Note: The safety buttons should stay depressed until the levers are squeezed and released. PG 25 ©Copyright 2020 Mobilate LLC All rights reserved P/N: 400.160 Rev 3...
  • Page 27 Once the rear feet hit the lower ground, release the Levers (3). The Safety Buttons (4) will spring out and re-engage. Listen and feel for the “click” sound of Roami automatically locking into place at the proper angle of the stairs or slope.
  • Page 28 6.4.6. Once at the top, keep feet on step below. Position the Roami PMA on the top step, press both Safety Buttons (4) inwards until they both engage. 6.4.7 Squeeze both Levers (3) simultaneously and the front legs of the device will automatically drop down to the surface.
  • Page 29 6.4.8. Note: The Roami PMA is designed to automatically adjust to terrain, however users can cross-check the relative position of the Cam-Lok at any time using the indicators shown. 6.4.9 Once the legs have dropped to the floor surface, release the Levers (3) and listen and feel for the Roami to “click”...

  • Page 30: Using The Roami Pma Like A Stair Assist Down Stairs

    Do not use on long flights of stairs such as between floors of a home or building. • Make sure the Roami PMA is working properly, and that parts are locked into place.
  • Page 31 6.5.3 Grasping the Handles (2), squeeze both Levers (3) simultaneously. The product will drop to the height of the stairs automatically when levers are engaged. ©Copyright 2019 Mobilate LLC All rights reserved PG 30 P/N: 400.160 Revised December 2019...
  • Page 32 Do not proceed down stairs or slope without insuring Roami PMA is locked. 6.5.4 Once the legs have dropped to the stair surface, release the Levers (3) listen and feel for the “click” into locked position. With both hands on handles, ensure that Roami is locked into place.
  • Page 33 6.5.6 Press both Safety Buttons (4) inwards and squeeze the levers simultaneously. 6.5.7 Once at the bottom, place the front feet on the lowest surface. ©Copyright 2019 Mobilate LLC All rights reserved PG 32 P/N: 400.160 Revised December 2019...
  • Page 34 Squeeze both Levers (3) simultaneously and the rear legs of the device will automatically drop down to the surface. Note: Continue walking forward with weaker leg first. PG 33 ©Copyright 2020 Mobilate LLC All rights reserved P/N: 400.160 Rev 3...

  • Page 35: Using Your Roami Pma To Align Gait

    6.6 USING YOUR ROAMI PMA TO ALIGN GAIT 6.6.1 For users that need help with posture positioning, the Roami PMA can be set to specific angles for improved gait and stability. Use the side indicators on the Cam-Lok to confirm settings. Each marker represents a 6º shift in angle forward or backward.

  • Page 36: Maintenance

    1. Always inspect the product for damage before use. If any damage is found, DO NOT use the Roami PMA until it is repaired. 2. Weekly, wipe Roami surfaces with a damp cloth and mild detergent (the use of bleach is not recommended). Allow to dry before use. Check all joints and brackets for debris and clean if necessary.

  • Page 37: Technical Specifications

    86 cm 92 cm 78 cm 10. SUPPORT For product questions, warranty repairs or replacement, contact: technicalsupport@mobilateus.com +1.210.284.1312 The Roami PMA Instruction Video can be found at: https://youtu.be/VDnL81EZKXY ©Copyright 2020 Mobilate LLC All rights reserved PG 36 P/N: 400.160 Rev 3...

  • Page 38: Replacement Parts

    100.203 Roami 2 wheel assembly - Urban Blue Back Leg Grip Feet: 100.300 Roami back grip foot assembly 2x - Rose Gold 100.301 Roami back grip foot assembly 2x - Charcoal Gray 100.302 Roami back grip foot assembly 2x - Red 100.303 Roami back grip foot assembly 2x - Urban Blue...
  • Page 40 Manufactured by: EU Authorized Representative: Mobilate Emergo Europe 2733 Kanasita Drive #121 Prinsessegracht 20, 2514 Hixson, TN 37343 USA AP Den Haag, Netherlands...
