Summary of Contents for CETAC M7500
- Page 1 __________Guide to Replacing the Power Supply Board M7500...
- Page 2 1) Power the unit off, unplug power cord from system. Remove the screws from the top cover and set aside. Figure 1 Fig. 1 2) Using a #2 stubby Phillips screwdriver remove the two screws that hold the bracket to the Power Supply board.
- Page 3 3) Grasp the board by the heatsink bracket and pull straight out. Figure 3 Fig. 3 (Note: When installing the new board, be aware that there are two different styles of connectors on the Power Supply board that will plug into the Interconnect board.
- Page 4 4) After installing the new board power the unit on to be sure that the system initializes. (Note: All the LED’s on the Power Supply board should be lit up when the system is initialized.) If they are not it is possible that a pin has gotten bent during the installation.
