ST Audio DSP24 ADAT Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
About this manual:
The product described in this manual, has been developed and produced by ST
Audio / HOONTECH Co., Ltd.
•
DSP24 ADAT is a trademark of HOONTECH Co., Ltd.
•
ADAT is a registered trademark of Alesis.
•
Microsoft, Windows, Windows 98, Windows 2000 and Windows XP are
registered trademarks, or trademarks of Microsoft Corporation.
All other brands and product names are trademarks, or registered trademarks of
their respective holders.
January 2002
It is the policy of ST Audio to improve products as new technology and newer
components become available. ST Audio, therefore reserves the right to change
specifications without prior notice.
A/S Centre
ST Audio / HOONTECH Co., Ltd.
4th Flr., Minkyung Bldg.,
#332 Songne-1Dong, Sosa-Ku,
Bucheon City, Kyungki-Do, Korea
Tel.: +82-32-611-1994
Fax: +82-32-612-0079
Internet: www.STAUDIO.com
Copyright © 2002 HOONTECH Co., Ltd.
This documentation was created by HOONTECH Co., Ltd. (Korea), RIDI
multimedia (Germany) and Sound & Music Promotions Pty Ltd. (Australia).
Note: To avoid damage of your speakers, always turn down the volume,
or turn off the power of your amplifier connected to the ST Audio DSP24
ADAT when you are rebooting or shutting down your PC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSP24 ADAT and is the answer not in the manual?

Questions and answers

Summary of Contents for ST Audio DSP24 ADAT

  • Page 1 All other brands and product names are trademarks, or registered trademarks of their respective holders. January 2002 It is the policy of ST Audio to improve products as new technology and newer components become available. ST Audio, therefore reserves the right to change specifications without prior notice.

  • Page 2: Table Of Contents

    ST A DSP24 ADAT UDIO Contents Introduction............3 What’s in the box ? Functions Specifications ............4 III. In- and output connectors ........5 IV. Hardware installation ..........7 Using the ADAT I/O ports Using the WordClock in-/output Driver and software installation ......9...

  • Page 3: Introduction

    DAC unit. Digital editing with the DSP24 ADAT card from ST Audio makes many jobs in the studio effortless. For example, using the card with a linear digital tape recorder you...

  • Page 4: Specifications

    ST A DSP24 ADAT UDIO II. Specifications • PCI 2.1 compliant interface • Optical ADAT interface: 8 input channels (up to 24-bit, 48kHz) • Optical ADAT interface: 8 output channels (up to 24-bit, 48kHz) • Coaxial S/PDIF I/O (24-bit) •...

  • Page 5: In- And Output Connectors

    ST A DSP24 ADAT UDIO III. In- and output connectors PCI card connectors / options optical ADAT input optical ADAT output connects to the breakout cable (15pin D-SUB to RCA / TRS adapter) – check the next page BNC WordClock input BNC WordClock output analog CD input (routed to Internal Mixer) –...
  • Page 6 DSP24 ADAT UDIO Breakout cable 15pin D-SUB connector that connects to the DSP24 ADAT PCI-card analog monitoring outputs (1/4" TRS unbalanced –10dBv, left and right channels), this output sends out the same signal as channel 1,2 of the optical ADAT-output...

  • Page 7: Hardware Installation

    ADAT devices. Connect the ADAT output of the card with the ADAT input of your external ADAT compatible device. Connect the ADAT input of the card with the ADAT output of your external device. The DSP24 ADAT connects to any other device using the optical ADAT format.
  • Page 8 The HD5 jumper is now set to ON. The other jumpers (HD4, HD3 and HD2) are untouched. To sync the DSP24 ADAT card to an external WordClock source, External Links must be set to ADAT synchronisation. section in the E...

  • Page 9: Driver And Software Installation

    Windows 95 and Windows Me is very similar, although the displayed dialog boxes might look slightly different. After installation of the DSP24 ADAT in a PCI slot in the computer, boot up the system. Windows will detect the new hardware automatically and display the following screen.
  • Page 10 ST A DSP24 ADAT UDIO Select Search for the best driver for your device and click Next. D:\sound\adat Check Specify a location. Do not check CD-ROM drive or Floppy disk drives. Type in <drivename>:\sound\adat (where <drivename> equals the letter of your CD-ROM drive) in the window displayed above and click Next.
  • Page 11 ST A DSP24 ADAT UDIO After Windows finds the driver you should see the above screen naming the driver information file indicated in the screenshot. Click Next. At this window, complete the installation by clicking Finish. Windows will now install the driver for you through a series of installation screens. If you are prompted to do anything (this would be unusual), please follow the directions on screen.
  • Page 12 Properties. You should see the message This device is working properly. Click on the Resources tab, you should see the message No conflicts. If so, congratulations are in order. You have successfully installed the drivers for the DSP24 ADAT under Windows 9x/Me. - 12 -...

  • Page 13: Installation Under Windows 2000

    Administrator or with similar rights in order to install the DSP24 ADAT driver under Windows 2000. After installation of the DSP24 ADAT in a PCI slot in the computer, boot up the system. Windows will detect the new hardware automatically a few seconds after you have entered your password and display the following screen.
  • Page 14 ST A DSP24 ADAT UDIO Select Sound, video and game controllers on the next dialog and again click Next. Select Have Disk..D:\sound\adat\wdm Type in <drivename>:\sound\adat\wdm (where <drivename> equals the letter of your CD-ROM drive) in the window displayed above and click OK. Alternativly, you can click Browse and select the correct directory on the CD, then click OK.
  • Page 15 On this dialog (displayed on the previous page), make sure to select ST Audio DSP24 ADAT WDM Audio System. Do not select any of the other entries (very important!). Click Next. If you get a dialog box about a missing driver signature, you can ignore it and just select Continue.

  • Page 16: Installation Under Windows Xp

    Professional, you must be logged in as Administrator or with similar rights in order to install the DSP24 ADAT driver. After installation of the DSP24 ADAT in a PCI slot in the computer, boot up the system. Windows will detect the new hardware automatically a few seconds after you have entered your password and display the following screen.
  • Page 17 Highlight it and click on Properties. You should see the message This device is working properly. If so, congratulations are in order. You have successfully installed the drivers for the DSP24 ADAT under Windows XP. - 17 -...

  • Page 18: External Links

    UDIO VI. External Links External Links is the control center of the DSP24 ADAT card. It controls the monitoring of your PC based studio. Different studio envrionments (e.g. analog mixing desk vs. PC as digital mixer) require different monitoring setups.

  • Page 19: Monitoring

    ST A DSP24 ADAT UDIO The virtual cables for the outputs (which mainly control the monitoring) cannot be removed but replaced by other connections. These connections are displayed as straight lines between the white circles. The available output sources are: •...

  • Page 20: Clock Source Selection

    If you use an analog (or digital) mixer that is connected to both the inputs and the outputs of the DSP24 ADAT card, you can monitor via the mixer so that is no problem. The DSP24 hardware however has a built-in digital mixer so you do not really need an external mixing desk.
  • Page 21 ST A DSP24 ADAT UDIO ADAT Select this clock source when the device connected to the optical ADAT input should supply the clock / samplerate for the DSP24 ADAT card. S/PDIF Select this clock source when you want to record from the S/PDIF input with the clock supplied by the device connected to the coaxial digital input of the card.

  • Page 22: Mixer Controls

    These functions are represented by an AC-97 codec chip that is on your DSP24 ADAT card. AC-97 has been defined as standard by Intel for consumer audio applications on modern PCs. The AC-97 codec ST Audio is using works with a 18bit ADC, a 18bit DAC and an analog mixer.

  • Page 23: External Mixer

    ST A DSP24 ADAT UDIO External Mixer With the External Mixer you can control all incoming and outgoing signals (20 channels in total). Open it by clicking on Call External Mixer in the menu of External Links or by clicking the Ext. Mixer button.
  • Page 24 ST A DSP24 ADAT UDIO Wave (1/2 to 7/8) In the Wave section you can control the volume of the playback signal (for the devices ADSP24 Ext.(n) WaveOut x/x or the channels 1~8 of the ASIO and GSIF driver). Muting each channel is possible (M button). Also you can control the panning independant for the left and right channel of each stereo device.
  • Page 25 ST A DSP24 ADAT UDIO Input (1/2 to 7/8) These sections are controlling the volume of the different input channels from the optical ADAT input. Muting the left and right channels is possible independantly. Presets The External Mixer allows you to save four presets for quick access.

  • Page 26: Hardware Settings

    VIII. Hardware settings The H/W Setting dialog of the DSP24 ADAT is used to control the basic driver settings of the audiocard. You call it via External Links (H/W Setting button or via the menu). The H/W Setting dialog is also used when you open the ASIO control panel from an ASIO compatible sequencer such as Emagic Logic Audio or Steinberg Cubase VST.
  • Page 27 ST A DSP24 ADAT UDIO The Clock And Sample Rates (Hertz) section allows you to select the source of the clock for the DSP24 card. You can select between Internal Master Clock and External Master Clock. Make sure to select External Master Clock only if you are recording or monitoring from the ADAT or S/PDIF input of the card.
  • Page 28 ST A DSP24 ADAT UDIO latency of the ASIO driver will be (and the other way round). You might notice the latency when you perform some action inside your ASIO application (e.g. you are using a VST instrument in Cubase VST): the result of your action will be audible with a certain delay - the latency.
  • Page 29 ST A DSP24 ADAT UDIO These functions are not available under Windows NT 4.0, 2000 and XP (as GigaSampler-/Studio did not fully support these operating systems when this manual was created). The settings will not be available in that case.

  • Page 30: Usage With Software Applications

    UDIO IX. Usage with software applications For each application you are using with the DSP24 ADAT you have to follow some configuration steps. Basically, every stereo input or output channel of the card can be used like a normal soundcard using the corresponding devices. Normally every program will have a configuration function where you can select the devices.
  • Page 31 ST A DSP24 ADAT UDIO • ADSP24 Multiple PCM Out (n) – this is an interleaved driver for playback of several channels at the same time. Some older audio applications are using this driver to access multiple channels on soundcards. Please note: this device is not available (and not needed) under Windows 2000/XP.

  • Page 32: Setting Up Emagic Logic Soundtrack24

    ASIO. Please note that most applications will need special settings to ensure that the DSP24 ADAT is working properly. We are continuously testing the card with various popular applications. In the following sections we have provided examples of a few applications.

  • Page 33: Setting Up Steinberg Cubase Vst/24 3.72

    VST plugins and instruments. Please note, that other Steinberg programs (like Nuendo, Cubasis VST or Cubase VST 5.x) have a very similar setup when using the ASIO driver. To setup the DSP24 ADAT in Cubase VST, please follow these steps: •...
  • Page 34 ST A DSP24 ADAT UDIO • click on the ASIO button under Device Mixing. • Start Cubase VST and select the option Audio>System. • In the section Audio Performance, set Number of Channels to 16 (recommended). • In the Monitoring section, select Global Disable (recommended). If you want to monitor signals in realtime and adding VST plugin effects at the same time, select Tape Type instead.

  • Page 35: Setting Up Emagic Logic Audio Platinum 4.7

    Setting up Emagic Logic Audio Platinum 4.7 The powerful Audio-/MIDI-Sequencer Logic Audio Platinum 4.7 (and higher) from Emagic also uses ASIO drivers. Follow these steps to setup the application for the DSP24 ADAT. • call the H/W setting dialog inside External Links.

  • Page 36: Setting Up Cakewalk Pro Audio 9.X

    Setting up Cakewalk Pro Audio 9.x Cakewalk Pro Audio is a famous Audio-/MIDI-Sequencer and recordingsoftware. It uses the MME drivers of the DSP24 ADAT. We recommend to use it under Windows 9x/Me. If you use Windows 2000/XP, the newer Cakewalk SONAR might be a better choice.
  • Page 37 ST A DSP24 ADAT UDIO • Click on Drivers. You will see a list of MME devices for Input and Output. Select the entries you want to use (check the section A VAILABLE IN earlier in this chapter for reference). Usually you should OUTPUT DEVICES select at least ADSP24 Ext.

  • Page 38: Setting Up Nemesys Gigasampler 1.64

    Setting up Nemesys GigaSampler 1.64 GigaSampler from Nemesys is a powerful and very popular software sampler. The DSP24 ADAT provides a special GSIF-driver (GigaSampler-InterFace) that allows you to use the separate outputs of the card with GigaSampler. We do not recommend to use older versions than GigaSampler 1.64.
  • Page 39 ST A DSP24 ADAT UDIO • Under Wave Out Driver, select Audio DSP24 MultiChannel Driver. • Select the Output channels you want to use on the right side under Outputs Enabled. • Now assign the Midi Channels mapped to Outputs in the lower area.

  • Page 40: Troubleshooting / Faq

    ST A DSP24 ADAT UDIO X. Troubleshooting / FAQ This chapter addresses common questions to solve possible problems and avoid conflict with other PC hardware or specific system configurations. Q: Can I use the card with an AMD Athlon / Duron / Thunderbird CPU? Will it work with a VIA Cyrix CPU? A: Yes, of course! There are no compatibility issues with microprocessors.
  • Page 41 ST A DSP24 ADAT UDIO Q: I have read that the card is full duplex, but I can't do simultaneous record and playback with Cakewalk! A: Simultaneous record and playback needs to be enabled in Cakewalk Pro Audio. In the software, go to Settings >...
  • Page 42 ST A DSP24 ADAT UDIO A: In most cases this problem can be solved by changing the interrupt which has been assigned to your hardware. Check in Control Panel > System > Device Manager > Computer > Properties if there is another hardware component using the same interrupt as the DSP24 PCI-card (it should have its own interrupt, especially on mainboards using the VIA chipset).

  • Page 43: Support / Contact

    DSP24 ADAT UDIO XI. Support / Contact ST Audio offers various resources to provide customer support. Please visit our website www.STAUDIO.com to access our customer service area. The extensive Knowledge Base and FAQ sections of our website, deal with common issues and are updated frequently by us. Please check this resource from time to time to get the latest updates on your DSP24 card.
