themo
INSTALLATION AND OPERATION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the themo and is the answer not in the manual?

Questions and answers

Summary of Contents for SLS themo

  • Page 1 INSTALLATION AND OPERATION MANUAL...

  • Page 2: Table Of Contents

    Table of contents 1. Technical Specifications ..........2. Safety Instructions ............3. Mounting Instructions ............ 8-17 4. Configuring ............... 5. Warranty ................6. Disposal Instructions ............
  • Page 3 Manufacturer: Smart Load Solutions OÜ, Masti 17, 11911, Tallinn, Estonia EU Declaration of Conformity The product is in conformity with the provisions of the following EC Directives, including all amendments, and with national legislation implementing these directives: Low Voltage Directive 2014/35/EC EMC Directive 2014/35/EC The following harmonized standards were applied: EMC EN 55024:2011...

  • Page 4: Technical Specifications

    1. Technical Specifications Operation voltage Temperature range 220-240 V, 50 Hz Offline manual mode: 13-41°C Online automatic mode: 5-45°C Standby power consumption Max. 1,8 W Dimensions W70 x L70 x H48 mm Relay Max. 16 A / 3000 W @ 230 V Weight 120 g Supported sensors...
  • Page 5 Colour Humidity White Max 85% relative humidity Mounting STORAGE CONDITIONS In-wall mounted IP class Ambient Temperature -10°C to +50°C Protection class Rel. Humidity Class II 5% to 85% (non-condensing) OPERATING RESTRICTIONS Altitude 2000m above sea level Ambient Temperature 0-40°C Level of pollution...

  • Page 6: Safety Instructions

    2. Safety instructions Make sure the main supply to the thermostat is turned off before installation! Important: When the thermostat is used to control the floor heating element in connection with a wooden floor or similar material, always use a floor sensor and never set the floor temperature to more than 35°C.
  • Page 7 • Children should be supervised to ensure that they do not play with the thermostat; • Cleaning and user maintenance should not be made by children without supervision; NB! THEMO requires working Wi-Fi in order to perform full functionality.

  • Page 8: Mounting Instructions

    3. Mounting Instructions 1. Switch off power. Switch off power to your heating equipment at your circuit breaker box. Verify that your existing thermostat should not be able to display any indication of operation.
  • Page 9 2. Remove cover. • Note: If you don’t have an existing thermostat, skip to step 3. Remove the cover of your old thermostat to reveal the wiring. Most covers snap off easily but some may be attached by screws. Screws are most commonly hidden behind the adjustment button.
  • Page 10 __________________________________________________ __________________________________________________ Use the stickers provided in this guide to label the wires for connection to Themo thermostat. If your old thermostat has more than one wire coming out from each connector, or you need additional help, contact service support.
  • Page 12 4.1Disconnect1and1trim1wires Disconnect the labeled wires from the old thermostat base and remove the base from the wall using a screwdriver. Pull the thermostat wires out as far as possible. • Note: Do not disconnect any capped wires which connect the screen of the heating cable and the earth conductor of the power supply cable.
  • Page 13 LO�D LO�D � �...
  • Page 14 5. Reconnect wires. Connect the Themo thermostat according to the connection diagram. • Tip: If you are replacing an existing thermostat, use the stickers as a guide when inserting the wires into the Themo terminal blocks. The wires from the wall should plug easily into the terminal blocks.
  • Page 15 Carefully fit the thermostat to the in-wall socket and tighten the screws.
  • Page 16 6. Attach front panel. Add the frame before assembling the front panel to the base. Push the front panel in place. When connecting the front panel to the base, make sure that the female header will not bend the connectors. Press carefully until the front panel is fixed against the frame.
  • Page 17 7. Switch on power. Switch on the power to your heating equipment at your circuit breaker box. Watch Themo come alive!

  • Page 18: Configuring

    4. Configuring Download Themo mobile app to create a free account and follow the step-by-step instructions on screen to set up your device. Or go to webpage: app.themo.io/setup...

  • Page 19: Warranty

    5. Warranty According to Consumer Protection Act all products purchased from www.themo.io or from respective reseller will have 2-year limited warranty. When using, or installing the product, it is required to follow instructions in this guide. Only manufacturing defects which can be traced back to the manufacturer will be under warranty.

  • Page 20: Disposal Instructions

    6. Disposal Instructions Please consider the environment and recycle your old thermostat.
