Sino Fx Tech HDV-C100IR Operation Manual

over single 100m/328ft Coaxial Cables with IR
Thank you for purchasing this product. For optimum performance and safety, please
read these instructions carefully before connecting, operating or adjusting this product.
Please keep this manual for future reference.
 Introduction
The HDMI Over Single Coax Extender sends HDMI signals Over just one 75Ohm Coaxial
cable -- up to100m away. The HDMI Over Single Coax Extender supports HDMI 1.3 and
HDCP 1.1 with features such as Deep Color and 1080p.By using standard and widely
available 75Ohm RG-6U cables, the HDMI Over Single Coax Extender makes HDMI signal
extensions to be easier than heavy and expensive copper cable and more robust than
optical fiber. The Extender includes two units: transmitter and receiver.
transmitting unit is used to capture the HDMI input with IR signals and carries the signals
via one coaxial cable. The receiving unit is responsible for equalizing the transmitted
HDMI signal and reconstructing IR and serial control signals. The Extender offers the
most convenient solution for HDMI extension over a single coaxial cable with long
distance capability, and is the perfect solution for any application.
 Features
1. Flexible extension of high-bandwidth HDMI 1.3 thanks to the performance and
reliability of 75Ohm RG-6U Coax cable.
2. Audio and video are transmitted digitally over the 75Ohm RG-6U Coax cable
with zero signal loss.
Operation Manual
HDMI Extender
Control
OperationManual
