Schnadig Adela C013-016-102H Assembly Instructions

ASSEMBLY INSTRUCTIONS
TWO (2) PEOPLE AND PHILIP's SCREW DRIVER REQUIRED
PLEASE UNPACK ALL PARTS AND CHECK THEM AGAINST PARTS LIST ON THIS INSTRUCTION SHEET BEFORE DISCARDING
PACKING AND CARTON!!
1) Connect the side rail and headboard/footboard by bolt (F).
2) Assemble the side rail and headboard/footboard using the curved washer (A),
flat washer (B), lock washer (C), and nut (D) tighten by wrench (E), as shown in Diagram A.
3) Assemble the support leg on the slat, as shown in Diagram B.
4) Mount the assembled support slats (done in step 3) onto the cleat of side rails with screws (G).
Use a Phillips Head Screwdriver to tighten screws, as shown in Diagram C.
*** NOTE KEEP THIS SHEET!!! ***
In the unlikely event that you would need a replacement part for your table,
please contact your local authorized Schnadig International dealer. If you
need replacement hardware quickly, it could be purchased from your local
hardware store.
C013-016-102H/102F/102R
Queen Bed
Part Description Part No.
Headboard (1) C013-016-102H
Footboard (2) C013-016-102F
Side rail (3)
C013-016-102R
Slat (4) C013-016-102F-3067
Support leg(5)
C013-016-102F-30305
RTA Hardware(6)
C013-016-102F-3001
RTA Hardware(7) C013-016-102R-3001
C013-016-122H/122F/102R C013-016-122H/122F/142R
King bed
QTY Part No. QTY Part No.
C013-016-122H C013-016-122H
1 1
1 C013-016-122F 1 C013-016-122F
C013-016-142R
C013-016-102R
2 2
C013-016-122F-3067 C013-016-122F-3067
3 4
C013-016-122F-30305 C013-016-122F-30305
3 8
C013-016-122F-3001
C013-016-122F-3001
1 1
C013-016-102R-3001 C013-016-142R-3001
1 1
RTA Hardware(7)
NO. Hardware List
Curved Washer(5/16"Dia)
A
Cal King bed
Flat Washer(5/16"Dia)
B
QTY
C
1
D
1
E
2
F
4
8
1 NO. Hardware List
1 G
Q'ty
8
8
8
Lock Washer
Nut 8
Wrench
1
8
Bolt
RTA Hardware(6)
Screw(4.2x32) 12 16
