Ropam elektronik BasicGSM 2 Installation Manual

Gsm notification and control module, gsm terminal

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

BasicGSM 2 - GSM notification and control module,

Ropam Elektronik

Tel. +48 12 272 39 71

Faks +48 12 379 34 10

GSM terminal.

Installation Manual (DTR).

Polanka 301

32-400 Myślenice, Polska

www.ropam.com.pl

biuro@ropam.com.pl

Wersja dokumentu : 1.0

2017-10-06

Table of Contents

Need help?

Do you have a question about the BasicGSM 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ropam elektronik BasicGSM 2

Page 1 BasicGSM 2 - GSM notification and control module, GSM terminal. Installation Manual (DTR). Ropam Elektronik Tel. +48 12 272 39 71 Polanka 301 www.ropam.com.pl Wersja dokumentu : 1.0 32-400 Myślenice, Polska Faks +48 12 379 34 10 biuro@ropam.com.pl 2017-10-06...
Page 2 - according to application. The device is a source of electromagnetic waves, so it may interfere with other radio devices in specific configurations. Ropam Elektronik is not responsible for any malfunction of the GSM network and any possible technical problems. WEEE LABELING Waste electrical and electronic equipment must not be disposed of with household waste.
Page 3: Table Of Contents
Tab: Phone numbers nad e-mail addresses................. 24 Tab: Inputs ............................ 24 Input settings - binary I1-I6......................24 Input settings - Analog I7, I8......................26 Inputs - Notifications........................28 Tab: Outputs ..........................29 Tab: Outputs - Notifications......................32 © 2017 Ropam Elektronik...
Page 4 RopamDroid application description................. 69 Installation and configuration of RopamDroid............71 View application windows..................73 Reset the device to factory settings..................75 System maintenance........................ 76 Technical parameters....................... 77 Version history.......................... 79 © 2017 Ropam Elektronik...
Page 5: Introduction
(service). Properties BasicGSM 2 / - PS terminals are the successors to the series of earlier BasicGSM modules. The first is BasicGSM 2 with 12VDC power supply and BasicGSM 2 - PS power supply with built-in buffer battery support and emergency power supply.
Page 6: Appliance
- Operation with PSR-ECO-2012-RS (only BasicGSM 2 modules). Appliance BasicGSM 2 / - PS terminals are designed for integration with other devices (eg visualization and control of the alarm system using the input / output), the effect is intuitive control of vigil by pictograms "arm", "disarm"...
Page 7: Requirements For Sms Control And Mobile Applications
- for controlling the GSM thermostat, it is necessary to start the function of temperature measurement and thermostat. Device version BasicGSM 2 is available in several versions, below is the name and options of the device. BasicGSM - BOX 2, module equipped with tamper cover: © 2017 Ropam Elektronik...
Page 9: System Description
System description Page 05 2. System description Description of connectors and components. © 2017 Ropam Elektronik...
Page 11 Page 07 Connector / Description / Function element Power terminals: DC or AC BasicGSM 2 = 10,5÷14,5V/DC + V - BasicGSM-PS 2 = 16÷20V/AC lub 20÷28V/DC I1÷I6 Configuration: NO, NC, second input terminal GND Binary / analog inputs, configuration: NO, NC, GND or + 12V (second input terminal GND or + 12V) I7÷I8...
Page 12: Optical Status Indication
GREEN • lit = for versions - PS basic power supply current AC/DC 17V / AC or 24V / DC • blinks = for versions - PS no power supply, battery power, for 12V DC power supply correct © 2017 Ropam Elektronik...
Page 13: Additional Modules And Extensions
The audio module allows you to listen to an audio object: during an alarm or after a voice call. The module is connected to the VSR input. PSR-2012 ECO: High-efficiency AC / DC pulse generator. P = 20 [W], Iout = 1.6A, U = 13.8 [V] © 2017 Ropam Elektronik...
Page 14: Installation And Commissioning
3. Installation and commissioning Basic requirements. The system is based on BasicGSM 2 and the other required components are for installation by a qualified installer with appropriate (required and required by country) permits and permissions to connect (interference) to 230V / AC systems and low voltage installations. The units should be installed indoors, with normal humidity (RH = 20% - 90% max non-condensing) and temperatures in the range -10 °...
Page 15 60h for the EPS of the stage 3 can be doubled to 30h. The PSR-ECO series power supplies allow for reporting on the RopamNET bus or through the technical outputs of the power supply. To meet the other requirements of the standard. Tamper protection system should be used Ropam. © 2017 Ropam Elektronik...
Page 16: Wiring System
(notch) must be pointing at the slot in the SIM card slot on the module board. Below is a view of the SIM card installation process in BasicGSM 2 / BasicGSM - PS 2 - Profile view. 4. Install the board and modules in the enclosure:...
Page 17: Connection Of Devices To The Inputs
- alarm outputs: relays (RELAY - potential-free contacts), - open collector (OC - BELL): control "negative" power, - high current (transistor: control + 12V) - Analog outputs 0-10 [V], 4-20 [mA] (I7 and I8 only) Configuration input: NC. Configuration input: NO. © 2017 Ropam Elektronik...
Page 18: Connecting Devices To The Outputs
Input I7 / I8 to connect a voltage or current source. FAC input for AC voltage control (on isolation transformer). Connecting devices to the outputs. The module has outputs allowing control and signaling. O1 - relay output - 1A @ 30VDC © 2017 Ropam Elektronik...
Page 19 - O2-O4 in the active state can supply (NO) or disconnect (NC) 0V power supply (GND). (open collector transistor output OC, control "supply ground", 700mA max.) O2-O4 output: connection of 12VDC / 700mA siren max. (acoustic and / or optical). © 2017 Ropam Elektronik...
Page 20: Connection Of Speech Synthesizer, Audio Module
The speech synthesizer allows you to record and transmit a voice message in the event of a system event. Playback occurs automatically when a voice call is made. The message is played back to the end of the call. The message is played back to the end of the call. © 2017 Ropam Elektronik...
Page 21 VSR, AUDIO-IN, DESCRIPTION GND - 0V, ground power and audio signal AUDIO IN audio input (microphone) T + synthesizer trigger (+ 5Vdc) AUDIO OUT audio input, (speaker) + 12V - power the speech synthesizer or audio module © 2017 Ropam Elektronik...
Page 22: System Configuration
5. Turn on the module power. 6. In BasicGSM Manager: - enter the PASSWORD in the COMMUNICATION OPTIONS (factory 111111), if no password or its incompatibility is possible, only SAVE to the module and update the firmware © 2017 Ropam Elektronik...
Page 23: Connection To The Module Via Gprs
RopamBridge server. To set up a remote connection to a module using BasicGSM Manager: - provide access to the internet for a computer that will make a remote connection to the BasicGSM 2 module - read the configuration (load the configuration file) of the module with which we want to connect...
Page 24: Functional Description
Restart modem every 24h: Modem restart function every 24 hours since the last restart of BasicGSM module 2. This function is useful in cases where there are problems with network login, unstable connection with BTS operator, virtual operators. The module resets only the GSM modem, the © 2017 Ropam Elektronik...
Page 25 BasicGSM 2. When there is a need to use the module as a stand-alone BasicGSM 2 control unit - then turn off the options for sending SMS and dzwonienia- module will not turn on GSM modem and thus the system will not appear on the failure of GSM / calling / sending SMS.
Page 26 Gmail account. ACCESS TO THE ROPAMBASIC MOBILE APPLICATION MODULE This option allows you to support BasicGSM 2 from RopamBasic using GPRS data. You must also correctly configure the APN of the SIM card operator installed in the module.
Page 27 Page 23 GPRS MONITORING SETTINGS BasicGSM 2 Module has the ability to connect to the monitoring station RopamRMS or other using KronosNET protocol.The system allows enabling GPRS monitoring with selected ARC monitoring stations or notification via SMTP server by e-mail.
Page 28: Tab: Phone Numbers Nad E-Mail Addresses
SMS and / or CLIP control, email. Numbers should be written in international format. Tab: Inputs Overview of BasicGSM 2 input settings. Input settings - binary I1-I6. • NAME: Name assigned to the input to identify the device or supervised room connected to it.
Page 29 - for a motion detector such as PIR, the parameter should be a loud alarm or a minimum of 1 minute. User can not block: The user can not block input from the application: RopamBasic, RopamDroid or SMS command. © 2017 Ropam Elektronik...
Page 30: Input Settings - Analog I7, I8
(Tab "Communications, Tests, Counters" option: Audio voice announcements). - Input hysteresis: set to delay the input to change input parameters. - Delay [ms]: delay in response to change of measured value. © 2017 Ropam Elektronik...
Page 31 System configuration Page 27 Sample setting of I7 input to which a liquid level sensor with output 4-20 [mA] is connected. Input principle: © 2017 Ropam Elektronik...
Page 32: Inputs - Notifications
COMMENTS: In SMS "STAN" are displayed values from inputs I7 / I8 in units set in the program. Inputs - Notifications. BasicGSM 2 Module has the following options for notification of change in input / alarm from inputs: SMS Ringing E-mail •...
Page 33: Tab: Outputs
BI (bistable, two stable states) the output changes normal state after the event marked in the "Enclosed by" field to the opposite state and remains in it until the next event, eg, violation of the input. © 2017 Ropam Elektronik...
Page 34 "NUMERICALLY CONTROLLED NUMBERS FOR CLIP CONTROL" option by the numbers entered in the PHONE NUMBERS fields. DTMF allows you to control the output via DTMF during a voice call (DTMFOn * or DTMFOff *). © 2017 Ropam Elektronik...
Page 35 BasicGSM 2. FAILURE SUMMARY output is active when a failure occurs.
Page 36: Tab: Outputs - Notifications
'0' inactive. Tel / Email: Columns to mark recipients of SMS / CALL / E-MAIL messages. - no SMS content = no SMS transmission at the given event. © 2017 Ropam Elektronik...
Page 37: Tab: Timers
System configuration Page 33 Tab: Timers. Four independent timers for controlling system arming, output control, LogicProcessor functions. Each timer can have 20 independent on / off alerts. © 2017 Ropam Elektronik...
Page 38: Tab: Communication, Tests, Counters
It is possible to save a new configuration with a new password. - Encryption key for TCP / IP applications: - Encryption key between BasicGSM 2 and RopamBasic mobile application. The key is automatically generated each time you run BasicGSM Manager.
Page 39 You can also set up sending account status information to the first phone number from the list of numbers. The interval to send account information is 7 days. The 7-day period is counted from the last restart of the BasicGSM 2 module. Audio voice announcements: Option to implement the .amr files in the device memory as an audio notification for events on the...
Page 40: Tab: System Options
- send confirmation of SMS command execution: turn on if the system is supported by the application RopamDroid (needed for the visualization of system operations / module BasicGSM 2). Optionally disable if you do not use the module control from the RopamDroid application and / or SMS,...
Page 41: Tab: Temperature
BasicGSM 2 memory). Tab: Temperature. BasicGSM 2 allows you to measure temperature with the digital temperature sensor TSR-xx. The temperature is measured every 30 seconds. The accuracy of the measurement is 0.5 st. Based on the temperature measurement, LogicProcessor functions can be used to send a notification of changes in temperature parameters and failure of the temperature sensor.
Page 42 The application allows the module to switch on when the temperature rises above 28 ° C. It switches off when the temperature falls below 15 ° C. C. TSR-xx sensor is connected to T1 input, output O4 controls pump via RM85 relay. © 2017 Ropam Elektronik...
Page 44: Tab: Logicprocessor
- time-logic functions like programmable time relays, triggers and reset timers (blocks) identical as arguments in logic functions and results are written to outputs or markers, - four clock timers (annual format) with 20 entries each to the LogicProcessor time option. © 2017 Ropam Elektronik...
Page 45 LogicProcessor can`t be triggered by other events than the LP in the 'outputs' tab bacause they will be overwritten by logic functions. All logic and time functions for physical outputs must be implemented in LogicProcessor, the result of the function is not considered as output trigger. © 2017 Ropam Elektronik...
Page 46: Logical Functions
0 or 1 1 = basic voltage absent indicator of battery failure of emergency power 0 = no failure supply, status from the supervised power supply, 1 = battery failure takes a binary value 0 or 1 © 2017 Ropam Elektronik...
Page 47 0 = inactive output 1, object type Binary Output 1 = active output M1÷M16 markers value, takes a binary value 0 or 1, 0 = marker value 0 object type Binary Value 1 = marker value 1 © 2017 Ropam Elektronik...
Page 48 '1' then the output is '0' assignment; A1 is the circuit which rewrites the value of the input signal to the output addition: A1÷A2 function adds arguments and writes the result to the Lx counter © 2017 Ropam Elektronik...
Page 49 • I1 input - motion detector • O4 output - controls the RM85 output relay for lighting (Https://ropam.com.pl/pl/towar/174/rm8512v1p.html) • T1 calendar timer operating in day mode • time relay PONS Timer Settings (sets the hours when the detector's light is on). © 2017 Ropam Elektronik...
Page 50 Relay as output has indicated O4 (gives GND at startup) which controls relay will turn on the light. The relay coil of RM85 must be connected to the output AUX and O4 output. Relay timer settings witch generates a pulse of a predetermined time (PONS one shot program). © 2017 Ropam Elektronik...
Page 51 System configuration Page 47 Output setting: Listing logic script: int I1; int M1; int O4; int tk1; main(){ gbenv(); while(1){ gbenv(); I1=geti(1); O4=geto(4); M1=tk1&I1; O4=pons(0,M1,0,30); seto(4,O4); © 2017 Ropam Elektronik...
Page 52: Time / Counter Functions
Symbol Parameter Description Trigger triggering signal Time time of timer, function Reset reset signal Output function output TIMER Typ timera type of function temporarily / counting TimeOnDelay © 2017 Ropam Elektronik...
Page 55: Tab: Events Memory
The Online View tab allows you to fully control the state of the module and its functions. The online preview mode does not disable the full functionality of BasicGSM 2. The system works just like in standard mode (sends SMS from inputs, controls outputs, etc.).
Page 56 In order to trigger a given output (according to the polarity set in the OUTPUT tab), click on the icon with the mouse . Clicking on the icon ends the activation of the output. © 2017 Ropam Elektronik...
Page 57 DC voltage: DC supply voltage of the module, AC voltage: AC voltage indicator connected to: FAC input for BasicGSM 2 (works when AC detection enabled) connected to the module's power terminals for BasicGSM - PS 2, GPRS: is, none. Indicator of presence of GPRS module, Temperature: The temperature indicator from the TSR-xx sensor connected to the T1 connector.
Page 58 SIM CARD PIN. This option allows you to test the SIM card of different operators without having to change and save the configuration. The configuration stored in BasicGSM 2 must have marked PIN CODE IS NOT REQUIRED to block automatic PIN code entry by module procedure.
Page 59 "Phone Numbers" tab, e-mail addresses. If there is no e-mail address in the first field, the module will not attempt to send the message to the recipients in the next entries in the list. WARNING: Correctness of sended e-mail is not checked. © 2017 Ropam Elektronik...
Page 60: Netmonitor Gsm (Bts)
This option opens a window where data downloaded from the modem is refreshed. They provide advanced GSM network parameters. They provide advanced GSM network parameters. There are given parameters of the selected current cell and the operator cube of other available cells (x {0-6}). View in BasicGSMManager © 2017 Ropam Elektronik...
Page 61: Upgrade To A Newer Version
WARNING: - The device software is constantly updated and upgraded with new features, it can be upgraded from BasicGSM Manager. Firmware update application window in BasicGSM 2 module: FIRMWARE UPDATE: To change the firmware version on your device: 1. Start BasicGSM Manager.
Page 62: System Configuration: Sms Commands
Error: BasicGSM was not found, Run the bootloader, then repeat the procedure in point 2 and follow the prompts in the BasicGSM Manager. Ropam Elektronik devices are constantly being developed and expanded with their capabilities and functionality. With the new versions of devices, a new version of the configuration program is also created.
Page 63: Remote Configuration: Telephone Numbers / Sms Center
Remote on / off 1111 tempmonit 1 Only TSR-xx series sensors can be used with the SMS / VOICE alert function when exceeding BasicGSM 2 module temperature thresholds a, b. X = 1 function enabled x = 0 function disabled yyyy - current access code Set value of 22ºC as "a"...
Page 64: Remote Configuration: Other Settings
(Yy, mm, dd, hh, mm = year, month, day, 01, 12, 05 hour, minute) yyyy restart Restart of BasicGSM 2 1111 restart yyyy status System status inquiry 1111 status The device sends a message containing data according to...
Page 65: Ropam Basic Mobile Application
MultiGSM2 Ropam Basic mobile Application. RopamBasic Mobile Application is software that facilitates the user to control the BasicGSM 2 module. It can be installed on basic mobile platforms: iOS, Android. The RopamBasic application is based on GPRS communication, which enables the transmission of small data and saves and controls the costs of operating the system.
Page 66: Description Of Application Windows
System configuration Page 62 There are 2 ways to connect an application to a BasicGSM 2 module: - Always after reboot (module) - the module sends to RopamBridge server data that is ready to connect to the mobile application, the server stores that data until the connection is established between the user and the module.
Page 67: Descriptions And Features Of Application Icons
Viewing of input states (violation, tamper, OK). Possible (set in BasicGSM Manager): - list of displayed inputs, - descriptions of entrances, - operating mode, - operating time, Application settings menu. View event history in the system. © 2017 Ropam Elektronik...
Page 68 Output control of the module. (1-4). 1 = white bulb icon 0 = dark bulb icon Possible (set in BasicGSM Manager): - No. of output, - state indication acc. Entry, - Require code to be included, © 2017 Ropam Elektronik...
Page 69 Output control of the module (1-4). eg garage gate. Possible (set in BasicGSM Manager) - No. of output, - state indication acc. Entry, - Require code to be included, Enabling the output group. Possible (set in BasicGSM Manager): - no output / outputs, © 2017 Ropam Elektronik...
Page 70: Pre-Set The Application
Data needed to configure the correct connection to the module: - SMS / application code - TCP / IP password - User telephone number (first on the list) - phone number - device number (disc ID) © 2017 Ropam Elektronik...
Page 71 User code and TCP / IP Password: - tab: "Communication, tests, counters" - SMS code / application log: Phone number: - tab: "Phone numbers and email addresses": Device phone number: - tab: "GSM modem options/Simcard options": © 2017 Ropam Elektronik...
Page 72: Ropamdroid Mobile Application
RopamDroid mobile application is software that facilitates user control of series modules: BasicGSM, BasicGSM 2, MultiGSM, NEO, NeoGSM, OptimaGSM. It can be installed on the Android platform. The RopamDroid application is based on SMS communication, which allows the transmission of small amounts of data and thus saves and controls the costs of operating the system.
Page 73: Ropamdroid Application Description
RopamDroid application description. Application main window: Description of the buttons and functions of the main window: PIKTOGRAM FUNKTION Disarming the module Arming of the module View status of zones (detectors) and the possibility of block grouping © 2017 Ropam Elektronik...
Page 74 A, B, (Hi and Lo) Cumulative text of system status, button for querying account status, setting time and date Request for current system status (refresh status) Function key, eg user command Application settings System event log (last 7 events) © 2017 Ropam Elektronik...
Page 75: Installation And Configuration Of Ropamdroid
Power status indication (basic or battery) Standby indication Alarm signaling on the system Failure log on the system Installation and configuration of RopamDroid. After installing the application, you need to configure it properly. Application settings window. © 2017 Ropam Elektronik...
Page 76 Temp. ground floor., Temp. DHW. Zone names: zone names in the system, may be the same as in TPR-xx panels eg Ground floor, Garage. Require the password for the program: the option enables access to the application after authorization (recommended). © 2017 Ropam Elektronik...
Page 77: View Application Windows
Import: function to import settings into a file, after import, you have to complete the settings with SMS codes. View application windows. To control the outputs of the modules from application RopamDroid, select the utility appropriate for the device during setup that they will be controlled via SMS! Inputs Outputs © 2017 Ropam Elektronik...
Page 79: Reset The Device To Factory Settings
- turn off the module power, - insert the jumper RESET: - turn on the module power - User Interface LED blink quickly 3 times - remove the RESET jumper - the module settings have been restored to factory settings © 2017 Ropam Elektronik...
Page 80: System Maintenance
No special maintenance is required. During periodical technical inspections, check the condition of the screw connections, emergency power supply, clean the PCB with compressed air. The system should be periodically tested for proper operation and communication. © 2017 Ropam Elektronik...
Page 81: Technical Parameters
700mA @30Vdc max. (no short-circuit protection) Current consumption by module circuits 40mA/50mA/300mA min/mid/max (without outputs) Battery compatible with BasicGSM 2 -PS, 12V, 1,2Ah - 12Ah (VRL/SLA) Battery charging current BasicGSM-PS 2, Ibat= 0,3A max. (Charging constant: voltage and current) MultiGSM-PS 2 Output protection +BAT- BasicGSM 2-PS, undervoltage: Ubat<10,0V (+/-5%)
Page 82 RH: 20%...90%, non-condensing Connectors AWG: 24-12 trundle Dimensions of the electronics board 68 x 87 x 32 [-/+1] [mm] Waga: BasicGSM 2, 65gr. BasicGSM 2-PS , 90gr. BasicGSM 2-D4M, 115gr. BasicGSM 2-PS-D4M 150gr. BasicGSM - BOX 2 160gr. © 2017 Ropam Elektronik...
Page 83: Version History
Version history. Page 79 8. Version history. BasicGSM 2 Date Description 2017.03.27 - first version © 2017 Ropam Elektronik...
