Stinger™
SHDSL/HDSL2 32-Port Line Interface Module (LIM) Guide
For software version 9.1-142
April 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lucent Stinger Series and is the answer not in the manual?

Questions and answers

Summary of Contents for BELL LABS INNOVATIONS Lucent Stinger Series

  • Page 1 Stinger™ SHDSL/HDSL2 32-Port Line Interface Module (LIM) Guide For software version 9.1-142 April 2001...
  • Page 2 Copyright© 2000, 2001 Lucent Technologies Inc. All rights reserved. This material is protected by the copyright laws of the United States and other countries. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to Lucent Technologies), except in accordance with applicable agreements, contracts, or licensing, without the express written consent of Lucent Technologies.

  • Page 3: Customer Service

    Customer Service To obtain product and service information, software upgrades, and technical assistance, visit the eSight™ Service Center at http://www.esight.com. The center is open 24 hours a day, seven days a week. Finding information and software The eSight Service Center at http://www.esight.com provides technical information, product information, and descriptions of available services.

  • Page 5: Table Of Contents

    Contents Customer Service ........................iii About This Guide ................xi What is in this guide........................xi What you should know ......................xi Documentation conventions...................... xi Documentation set........................xii Chapter 1 Configuring the SHDSL/HDSL2 32-Port LIM......... 1-1 Installing the SHDSL/HDSL2 LIM ..................1-2 Module specifications ......................
  • Page 6 Contents Manual LIM port redundancy..................2-12 Automatic LIM port redundancy .................. 2-12 Checking the status of extended LIM port redundancy ..........2-13 SHDSL/HDSL2 32-Port Line Interface Module (LIM) Guide...
  • Page 7 Figures Figure 1-1 SHDSL/HDSL2 32-port LIM ............... 1-3 Figure 1-2 Data passes through a modem’s digital circuitry (digital loopback)..1-20 Figure 1-3 Data passes through a modem’s digital circuitry and analog circuitry (analog loopback)..................1-20 Figure 2-1 LIM redundancy on a Stinger FS..............2-2 Figure 2-2 LIM port redundancy on a Stinger FS ............
  • Page 9 Tables Table 1-2 SHDSL/HDSL2 32-port LIM status lights ........... 1-4 SHDSL/HDSL2 32-Port Line Interface Module (LIM) Guide...

  • Page 11: About This Guide

    About This Guide What is in this guide This guide describes how to configure and monitor the Stinger™ SHDSL/HDSL2 line interface module (LIM) and includes configuration examples and module specifications. This guide also describes how to configure LIM redundancy. Warning: Before installing your Stinger unit, be sure to read the safety instructions in the Edge Access Safety and Compliance Guide.

  • Page 12: Documentation Set

    About This Guide Documentation set Convention Meaning Separates command choices that are mutually exclusive. > Points to the next level in the path to a parameter or menu item. The item that follows the angle bracket is one of the options that appear when you select the item that precedes the angle bracket.
  • Page 13 About This Guide Documentation set • Configuration: – Stinger ATM Configuration Guide. Describes how to use the command-line interface to configure Asynchronous Transfer Mode (ATM) operations on a Stinger unit. The guide explains how to configure permanent virtual circuits (PVCs), and shows how to use standard ATM features such as quality of service (QoS), connection admission control (CAC), and subtending.

  • Page 15: Configuring The Shdsl/Hdsl2 32-Port Lim

    Configuring the SHDSL/HDSL2 32-Port Installing the SHDSL/HDSL2 LIM ........1-2 Module specifications .

  • Page 16: Installing The Shdsl/Hdsl2 Lim

    Configuring the SHDSL/HDSL2 32-Port LIM Installing the SHDSL/HDSL2 LIM Installing the SHDSL/HDSL2 LIM Install the SHDSL/HDSL2 32-port module in the same manner as for any other LIM module. For detail, see the Stinger Getting Started Guide for your unit. After installation, follow the instructions in this document to configure the module.

  • Page 17: Status Indicators

    Configuring the SHDSL/HDSL2 32-Port LIM Status indicators Status indicators Several status lights on the front panel of the SHDSL/HDSL2 32-port LIM indicate the status of the module and its ports. Figure 1-1 shows the front panel and status lights of the SHDSL/HDSL2 32-port LIM.

  • Page 18: Embedded Operations Channel (Eoc) Protocol Compliance

    Configuring the SHDSL/HDSL2 32-Port LIM Specifying HDSL2 or SHDSL mode operational, the ACTIVE light illuminates. It is the only light that is on during normal operation. Table 1-2 explains the SHDSL/HDSL2 32-port LIM status lights. Table 1-2. SHDSL/HDSL2 32-port LIM status lights Light Color Indication...

  • Page 19: Configuring Shdsl/Hdsl2 Interfaces

    Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces list admin > [in SLOT-STATIC-CONFIG/{ shelf-1 slot-3 0 }] set interface-type = g-shdsl admin> write admin> Parameter Specifies HDSL2 or SHDSL mode. Specify one of the following values: interface-type • g-shdsl ( default)—The LIM operates in SHDSL mode. Note: You must also set the g-shdsl , the rate-mode , min-rate , and max-rate parameters, which do not apply if you set one of the other modes.
  • Page 20 Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces physical-address* = { shelf-1 slot-2 1 } enabled = no sparing-mode = inactive line-config = { 0 51 15 static { any-shelf any-slot 0 } coe } admin> list line [in HDSL2/{ shelf-1 slot-2 1 }:line-config] trunk-group = 0 nailed-group = 51 vp-switching-vpi = 15...
  • Page 21 Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces Parameter Specifies Type of unit. Remote equipment must have opposite setting. unit-type Specify one of the following values: • coe (the default)—The unit is central office equipment (COE). • cpe —The unit is customer premises equipment (CPE). Enable/disable network time reference (NTR) capability.
  • Page 22 Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces Parameter Specifies Noise margin value (in decibels). Specifying a value that is less margin than 6 decibels causes modems to train at higher rates, but on noisy loops, also causes them to become unstable and retrain. If this parameter is set to a value that is less than 6 decibels, the modems train at lower rates, but are more stable and are less likely to retrain on noisy loops.
  • Page 23 Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces Parameter Specifies Minimum rate in kilobits per second at which a modem trains min-rate when the rate-mode parameter is set to auto . This parameter applies only if the interface-type parameter is set to g-shdsl .

  • Page 24: Sample Hdsl2 Mode Configuration

    Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces Parameter Specifies The G.991.2 standard network type for the network that is gshdsl-standard- network-type connected to the SHDSL port. This setting specifies the modem output characteristics for either a North American or European network.

  • Page 25: Sample Shdsl Mode Configuration

    Configuring the SHDSL/HDSL2 32-Port LIM Configuring SHDSL/HDSL2 interfaces unit-type = coe ntr-enable = no clock-source = not-eligible clock-priority = middle-priority loop-back = n Sample SHDSL mode configuration To configure the SHDSL/HDSL2 32-port line interface module for SHDSL operation, you must first set the interface-type parameter to g-shdsl as described in “Specifying HDSL2 or SHDSL mode”...

  • Page 26: Configuring Call Control

    Configuring the SHDSL/HDSL2 32-Port LIM Configuring call control show (a)ll HDSL2 lines show (d)isabled lines show all (f)ree lines show in-(u)se lines toggle debug flag The following example (which is truncated) shows status of the first 16 ports on an SHDSL/HDSL2 LIM in slot 4: admin>...
  • Page 27 Configuring the SHDSL/HDSL2 32-Port LIM Configuring call control [in SYSTEM] ignore-lineup = no [in SDSL/{ any-shelf any-slot 0 }] ignore-lineup = system-defined [in DS3-ATM/{ any-shelf any-slot 0 }] ignore-lineup = system-defined Parameter Specifies Enable/disable the Stinger ability to ignore line status when SYSTEM >...

  • Page 28: Checking The Status Of An Shdsl/Hdsl2 Interface

    Configuring the SHDSL/HDSL2 32-Port LIM Checking the status of an SHDSL/HDSL2 interface admin> write SDSL/{ shelf-1 slot-12 1 } written Checking the status of an SHDSL/HDSL2 interface A Stinger unit creates an hdsl2-stat profile for each SHDSL/HDSL2 interface in the system.

  • Page 29: Obtaining Statistics About Operations

    Configuring the SHDSL/HDSL2 32-Port LIM Checking the status of an SHDSL/HDSL2 interface Parameter Indicates • port-up— Connected to CPE and data can be transferred. • test— Line is in test mode. • start-up-handshake —Startup handshake is occurring. • start-up-training —Startup training is occurring. •...

  • Page 30: Internal And External Diagnostic Tests And Bert

    Configuring the SHDSL/HDSL2 32-Port LIM Internal and external diagnostic tests and BERT Parameter Indicates Number of times the link has transitioned from an up state to up-down-cntr a down state since the module was last reset. Outcome of modem chipset self-test. self-test Current transmission power that the transceiver is using, transmit-power...
  • Page 31 Configuring the SHDSL/HDSL2 32-Port LIM Internal and external diagnostic tests and BERT physical-address* = { shelf-1 slot-2 1 } bert-timer = 1 minute bert-enable = no idt-enable = no idt-num-of-msg = 1000 Parameter Specifies Duration of the bit error rate test (BERT). Specify one of the bert-timer following values: •...

  • Page 32: Configuring An Internal Diagnostic Test (Idt)

    Configuring the SHDSL/HDSL2 32-Port LIM Internal and external diagnostic tests and BERT Parameter Specifies State of the BERT when it is enabled and the BERT timer has not bert-operation- expired. This parameter reports one of the following states: state • waiting-for-511-sync —Waiting for remote synchronization before starting the BERT.

  • Page 33: Configuring A Bit-Error Rate Test (Bert)

    Configuring the SHDSL/HDSL2 32-Port LIM Internal and external diagnostic tests and BERT admin> list [in LINE-DIAG-STAT/{ shelf-1 slot-2 1 }] physical-address* = { shelf-1 slot-2 1 } bert-operation-state = stopped idt-operation-state = stopped bert-error-counter = 0 idt-send-count = 1000 idt-recv-count = 1000 idt-error-counter = 0 If you attempt to change the setting of the idt-enable parameter while an internal diagnostic test is active for a line, the system generates a warning message, as in the following...

  • Page 34: Figure 1-2 Data Passes Through A Modem's Digital Circuitry (Digital Loopback)

    Configuring the SHDSL/HDSL2 32-Port LIM Internal and external diagnostic tests and BERT You configure a line for external diagnostic testing by putting it loopback mode, as shown in the following example : admin> read hdsl2 {1 1 1} HDSL2/{ shelf-1 slot-1 1 } read admin>...

  • Page 35: Configuring Lim And Lim Port Redundancy

    Configuring LIM and LIM Port Redundancy Overview of LIM and LIM port redundancy ....... . . 2-1 Configuring LIM redundancy .

  • Page 36: Overview Of The Lim-Sparing-Config Profile

    Configuring LIM and LIM Port Redundancy Configuring LIM redundancy The resulting system has 13 active ADSL LIMs and one spare that can be substituted for any one of the 13 LIMs if a failure occurs. In the same way, a system can be set up with the following module pairs: •...
  • Page 37 Configuring LIM and LIM Port Redundancy Configuring LIM redundancy LIM redundancy by configuring the LIM-Sparing-Config profile on a spare LIM of the same type as the LIM to be backed up. Following is a listing of a LIM-Sparing-Config profile with all parameters set to their default values: [in LIM-SPARING-CONFIG/{ any-shelf any-slot 0 }] physical-address* = { any-shelf any-slot 0 }...

  • Page 38: Manual Lim Redundancy

    Configuring LIM and LIM Port Redundancy Configuring LIM redundancy The spare ADSL LIM has the following profile: admin> read lim-sparing-config { 1 14 0 } LIM-SPARING-CONFIG/{ shelf-1 slot-14 0 } read admin> list [in LIM-SPARING-CONFIG/{ shelf-1 slot-14 0 }] physical-address* = { shelf-1 slot-14 0 } spare-slot-type = al-dmtadsl-atm-card sparing-mode = inactive spare-slot-number = slot-14...

  • Page 39: Automatic Lim Redundancy

    Configuring LIM and LIM Port Redundancy Configuring LIM redundancy Automatic LIM redundancy Automatic LIM redundancy detects a LIM failure and automatically sets up all the virtual channels of that LIM on the spare. When automatic LIM redundancy is activated, the primary LIM is monitored.
  • Page 40 Configuring LIM and LIM Port Redundancy Configuring LIM redundancy Parameter Specifies Number of times during the specified up-down-threshold error-averaging-period interval that the line is connected and disconnected by the modem before the modem is considered nonfunctional. The default value is 3. modem-failure-threshold Number of modems on this LIM that are considered nonfunctional before this LIM is considered nonfunctional.

  • Page 41: Lim Redundancy With Irms And Lpm-Rs

    Configuring LIM and LIM Port Redundancy Configuring LIM redundancy Assuming that the active parameters in the LIM-Sparing-Config subprofiles for slots 2 through 7 are also set to the default, LIM redundancy is now activated for the SDSL LIMs in slots 1 through 7. LIM redundancy with IRMs and LPM-Rs When you upgrade the software to TAOS 7.11.4 or later, a previously existing LIM-Sparing-Config profile is automatically converted to a redundancy profile indexed to the...

  • Page 42: Checking Lim Redundancy Status

    Configuring LIM and LIM Port Redundancy Configuring LIM redundancy spare-slot-number = slot-16 manually-spared-slot-number = any-slot if-sparing-config = [ any-slot any-slot any-slot any-slot any-slot any-slot any+ auto-lim-sparing-config = { [ { yes 10 100 3 12 } { yes 10 100 3 12 } { yes 10 + Suppose the SDSL LIM in slot 4 fails.

  • Page 43: Checking Status With The Rearslot Command

    Configuring LIM and LIM Port Redundancy Configuring LIM redundancy Parameter Indicates How redundancy is activated. Valid values are sparing-change-reason inactive, automatic, and manual. Time that the last change in redundancy state occurred. sparing-change-time sparing-change-counter Number of redundancy changes (for example, primary to secondary or secondary to primary).

  • Page 44: Configuring Lim Port Redundancy

    Configuring LIM and LIM Port Redundancy Configuring LIM port redundancy Midplane sparing bus usage : 8765 4321 0987 6543 2109 8765 4321 0987 6543 2109 8765 4321 ......XXXX XXXX XXXX XXXX XXXX XXXX Configuring LIM port redundancy LIM port redundancy allows an individual port of a LIM to be backed up by the corresponding port of a spare LIM.

  • Page 45: Enabling Lim Port Redundancy

    Configuring LIM and LIM Port Redundancy Configuring LIM port redundancy Figure 2-2. LIM port redundancy on a Stinger FS When a port on a LIM that is being backed up is replaced, the virtual channels for that port are terminated and set up on the spare. All other line parameters are also transferred to the spare port.
  • Page 46 Configuring LIM and LIM Port Redundancy Configuring LIM port redundancy Parameter Specifies Enables or disables port redundancy and specifies the mode. You can sparing-mode enable two port-redundancy modes. The default value, inactive, disables LIM port redundancy. The manual setting deactivates the LIM port and then reestablishes the connection on the same port of the spare LIM.
  • Page 47 Configuring LIM and LIM Port Redundancy Configuring LIM port redundancy stops. You can restart the process by resetting the system or by setting the sparing-mode parameter to inactive and then back to automatic. The parameters used for automatic LIM port redundancy are found in the Auto-LIM-Sparing-Config subprofile of the LIM-Sparing-Config profile for the spare LIM of the same type.
  • Page 48 Configuring LIM and LIM Port Redundancy Configuring LIM port redundancy Parameter Indicates State of the redundancy function. If redundancy is not sparing-state enabled, sparing-none is the value. If redundancy is enabled and the LIM slot is a primary LIM, the value can be primary-active or primary-inactive.
