- Page 1 BY ZINWELL Model No: KMS-F1 Multistacker Input Frequency: Range 950~2350 MHz Output Frequency: Range 950~2350 MHz I N S T R U C T I O N M A N U A L...
-
Page 2: Main Features
INTRODUCTION Thank you for purchasing the Kingray KMS-F1 Multistacker. Please read this manual carefully prior to installation as it contains information which will ensure you achieve the best performance from your KMS-F1. The satellite multistacker is a standalone device that can be installed directly after a twin or quad universal vertical - horizontal LNBF. -
Page 3: Installation Reference Guide
IN THE BOX * Note: for indoor use only INSTALLATION REFERENCE GUIDE Coaxial Cable Dish with twin output LNBF Note: All unused ports are to be terminated with the F-Terminators supplied. SPECIFICATIONS Input Port Output Port System Input Frequency 950-2350 Output Frequency Range 950-2350 Power Supply From External... - Page 4 SATELLITE PLANS LIST OF OPTUS D3 & C1 NON STACKED & STACKED I.F. Trans- NAT 01 NSW 02 VIC 03 QLD 04 SA 05 WA 06 TAS 07 NT 08 ponder Stacked D3T4 1145.0 2153.5 2070.5 2029.0 1618.0 979.0 1527.5 2070.5 2070.5 D3T8...
- Page 5 STACKER SWITCH POSITION - TABLE 1 Switch Number Setting NAT 01 NSW + ACT NSW 02 VIC 03 QLD 04 SA 05 WA 06 TAS 07 NT 08 Table 1: Shows Multistacker Dip Switch settings and STB State Settings The following tables shows the vertical stacked transponders for each state throughout Australia. The multistacker is shipped with all dip switched set to the off position which is set for the national plan.
-
Page 6: Safety Warning
The stacker has been fitted with a 5 position dip switch which is switched to match the State installed. This allows Foxtel to make better use of Transponder space in the event that the total 32 transponders are used. Dip Switches on the multistacker are switched to match up to the state/territory it is installed in. -
Page 7: Standard Communications Warranty Against Defects
STANDARD COMMUNICATIONS WARRANTY AGAINST DEFECTS This warranty against defects is given by Standard Communications 2.5 We warrant that we will perform services with reasonable Pty Ltd ACN 000 346 814 (We, us, our or GME). Our contact details care and skill and agree to investigate any complaint are set out in clause 2.7. - Page 8 1300 463 463 kingray.net.au A division of Standard Communications Pty Ltd. Head Office: PO Box 96, Winston Hills, NSW 2153, Australia. New Zealand: PO Box 58446 Botany, Auckland, 2163, NZ. T: (09) 274 0955. All international enquiries email: export@gme.net.au K M S - F 1 I N S T R U C T I O N M A N U A L DN: 49563-1 PN: 311056...
