user documentation
TFT/PxxxxPU-A101E LVDS Monitors
TFT/PxxxxPU-A102E DVI Monitors
Document Ordercode: DOC_PROTOUCH_M-E
Revision
Date
0.1
10.10.2013
0.2
08.11.2013
1.0
24.11.2015
1.1
18.02.2016
DOC_PROTOUCH_M-E.docx
© 2016 Syslogic Datentechnik AG | All rights reserved
Author
Modification
F. Liechti
First release
F. Liechti
TFT/PxxxxPU-A101E added
F. Liechti
Release
F. Liechti
Added details on power connector
Page 1 of 27
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for syslogic TFT/P PU-A101E Series
- Page 1 Revision Date Author Modification 10.10.2013 F. Liechti First release 08.11.2013 F. Liechti TFT/PxxxxPU-A101E added 24.11.2015 F. Liechti Release 18.02.2016 F. Liechti Added details on power connector DOC_PROTOUCH_M-E.docx Page 1 of 27 © 2016 Syslogic Datentechnik AG | All rights reserved...
-
Page 2: Table Of Contents
LVDS Monitor TFT/PxxxxPU-A101E DVI Monitor TFT/PxxxxPU-A102E Mounting 3.3.1 TFT/PBxxxPU-A102E Mounting procedure TFT/PBxxxPU-A102E 3.3.2 Mounting procedure TFT/PVxxxPU-A102E 4 Hardware Description Features 4.1.1 HBxxxPU7F16-A101E 4.1.2 HBxxxPU7F16-A102E 4.1.3 HVxxxPU71x16-A102E DOC_PROTOUCH_M-E.docx Seite 2 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... - Page 3 Projected capacitive touch monitor versions Tab. 3 Projected capacitive touch monitor accessories Tab. 4 TFT/PBxxxPU-A102E Mounting dimensions Tab. 5 PVxxxPU-A102E VESA dimensions Tab. 6 PBxxxPU71-A102E dimensions DOC_PROTOUCH_M-E.docx Seite 3 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved...
-
Page 4: General Remarks
Documentation, as well as any distribution to third parties can only be made with the express permission of Syslogic Datentechnik AG. Syslogic Datentechnik AG does not accept any liability for damages arising from the use of any incorrect or incomplete information contained in this documentation or any information missing. -
Page 5: Contents Of This Documentation
Electronic boards are sensitive to Electro-Static Discharge (ESD). Please ensure that the product is handled with care and only in a ESD protected environment. Otherwise a proper operation is not guaranteed. DOC_PROTOUCH_M-E.docx Seite 5 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 6: Life Cycle Information
The main functionality of the product is defined by the application programs running. The application programs are not part of the delivery by Syslogic but are defined, developed and tested by the customer or a system-integrator for each specific application. Refer to the respective documentation for more information. -
Page 7: Rohs
Important information about the product or the relevant section of the document, requiring the particular attention of the reader. The “Information” pictogram has the following meaning: Indicates important and instructional information. DOC_PROTOUCH_M-E.docx Seite 7 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 8: Product Description
Please read the safety instructions of the power supply before installing/connecting the device. 2.2.1 Variants Syslogic provides two interface variants within the PROTOUCH Monitor Series. LVDS Monitors The LVDS Interface uses an FPD2 Link interface. In addition USB is transmitted on the same cable. This variant is intended for minimal system wiring effort. -
Page 9: Device Versions
Additional Brightness sensor to automatically adjust the Brightness of the backlight and a Motion Sensor to disable the display if nobody is watching. Tab. 3 Projected capacitive touch monitor accessories DOC_PROTOUCH_M-E.docx Seite 9 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 10: Installation Guide
Connect any peripheral device to the USB Hub if required. Power the host computer and the monitor. DVI Cable Host Monitor USB Cable Power supply Fig. 2 LVDS Monitor System Setup DOC_PROTOUCH_M-E.docx Seite 10 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 11: Mounting
Tab. 4 TFT/PBxxxPU-A102E Mounting dimensions Mounting Angle: Mounting Angle must be 90° Cooling Space: To ensure cooling leave at least 10cm of free space around product. DOC_PROTOUCH_M-E.docx Seite 11 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 12: Mounting Procedure Tft/Pbxxxpu-A102E
Reattach the mounting frame and fix it into place by reattaching the screws highlighted in red. The product is now installed properly. Wall Projected capacitive touch panel DOC_PROTOUCH_M-E.docx Seite 12 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 13: Mounting Procedure Tft/Pvxxxpu-A102E
PVxxxPU-A102E VESA dimensions Mounting Angle: Mounting Angle must be 90° ± 15° Cooling Space: To ensure cooling leave at least 10cm of free space around product. DOC_PROTOUCH_M-E.docx Seite 13 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 14: Hardware Description
USB Port (Upstream) Fig. 4 HBxxxPU71x16-A102E 4.1.3 HVxxxPU71x16-A102E Display with Touch Sensor DISPLAY Shield Contact connector Power connector USB Port (Upstream) 4 USB Ports (Downstream) Fig. 5 HVxxxPU7F16-A102E DOC_PROTOUCH_M-E.docx Seite 14 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 15: Dimensions
Device # [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] TFT/PB104PU-A102E 71.5 52.5 TFT/PB121PU-A102E 52.6 53.6 52.5 TFT/PB150PU-A102E 84.7 83.7 150.7 54.5 Tab. 6 PBxxxPU71-A102E dimensions DOC_PROTOUCH_M-E.docx Seite 15 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 16: Hvxxxpu71X16-Xxx
[mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] TFT/PV104PU-A102E 39,5 24.5 TFT/PV121PU-A102E 26.5 26.5 67.5 24.5 TFT/PV150PU-A102Eb 57.5 57.5 104.5 27.5 Tab. 7 HVxxxPU71x16-xxx dimensions DOC_PROTOUCH_M-E.docx Seite 16 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 17: Interface Description
compliant with EN 60950-1 PSU/DR24V60W Syslogic recommends the use of the Syslogic DIN Rail power supply (input voltage: 230Vac, output voltage: 24Vdc, power: 60W) Please make sure that the input voltage does not exceed 30V otherwise the base board could get damaged. If the input voltage drops below 10V the system doesn’t work properly, correct operation cannot be guaranteed. -
Page 18: Lvds Interface (Tft/Pxxxxpu-A101E Only)
Not connected A. horizontal sync Not connected Pin 14 +5 V 5V Supply Analogue ground Not connected Pin 15 Ground Ground Tab. 10 DVI-D Connector Pin description DOC_PROTOUCH_M-E.docx Seite 18 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 19: Usb Interface
Turn it to the left to increase or turn it to the right to decrease the brightness of the monitor. Use the USB interface to configure the potentiometer as the source of the brightness control. DOC_PROTOUCH_M-E.docx Seite 19 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 20: Fuse
Please note that in the code above the package code for tape and reel and quantity 1000pcs is included. For further information on how to replace the battery please contact the manufacturer. DOC_PROTOUCH_M-E.docx Seite 20 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 21: Internal Connectors And Configuration
Tab. 15 External potentiometer connector (P13) 4.4.3 Programming interface P14 and P15 are internally used interface to program the onboard devices. Do not use these connectors. DOC_PROTOUCH_M-E.docx Seite 21 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 22: Shield Connection J200
When using the OnScreenKeyboard (OSK) for Tablet Computer TabTip.exe under Windows 7 you need to use the original Windows7 driver that is automatically installed instead of the separate touch driver provided by Syslogic to allow TabTip.exe to work properly. If you use TabTip.exe in Windows7 instead of OSK.exe you will benefit from some comfort features like automatic activation of the OnScreenKeyboard when you activate a text input field. -
Page 23: Cleaning The Projected Capacitive Touch Panel
For cleaning the metal housing please use a soft cloth and a metal polish. Do not use a coarse scouring cloth, scouring powder or solvent. Cleaning should only be carried out when the device is switched off! DOC_PROTOUCH_M-E.docx Seite 23 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 24: Programming Information
ASCII Coded command with N bytes (not zero terminated) Payload Tab. 18 USB Hid write command message Example: Display disable command package looks as followed: 0x3F(dec 63), 0x03, 0x21(!), 0x44(‘D’), 0x44(‘D’) DOC_PROTOUCH_M-E.docx Seite 24 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 25: Technical Data
Parameter Length Remark Power supply Maximum working cable length depends on resolution and refresh rate USB to Host USB to peripherals Tab. 21 Maximum Cable length DOC_PROTOUCH_M-E.docx Seite 25 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 26: Emi / Emc Specification
Hardware Revision Product Remarks Revision TFT/PxxxPU-A102E 1.0 Original Release TFT/PxxxPU-A102E 1.1 New Hardware (Control electronics), New Firmware TFT/P150PU-A102E 2.0 Display changed. Tab. 23 Hardware Revision State DOC_PROTOUCH_M-E.docx Seite 26 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved... -
Page 27: Manufacturer Information
Syslogic Datentechnik AG Taefernstrasse 28 CH-5405 Baden-Daettwil/Switzerland e-mail: support@syslogic.com Web: www.syslogic.com +41 56 200 90 50 +41 56 200 90 40 DOC_PROTOUCH_M-E.docx Seite 27 von 27 © 2016 Syslogic Datentechnik AG | All rights reserved...
