Seiko SVAZ015 Instructions

取 扱 説 明 書
NFCリーダー SVAZ015
この度は弊社製品をお買い上げいただき、
誠にありがとうございました。
ご使用の前にこの説明書をよくお読みの上、
正しくご愛用くださいますよう、 お願い申し上げます。
電気製品は注意事項を守らないと火災や人身事故などになること
があります。
なお、 この説明書はお手元に保管し、 必要に応じてご覧ください。
  ■ Donotusewhenanabnormalityoccurs
  W hen"thisproductemitssmoke,abnormalsoundorodor,"orif"foreignmatterorwaterhasenteredinside,"or"astrongimpactor
vibrationwasappliedtothisproduct,"immediatelystopusingthisproductandconsultyourdistributororourcustomerservicecenter.
  ■ Handlingcautions
To indicate the risks of serious consequences such as severe injuries unless the following safety regulations are strictly observed.
・Do not use this product in humid or dusty places.
・Do not spill liquid or put foreign matter into this product.
・Do not dismantle or modify the product.
To indicate the risks of light injuries or material damages unless the following safety regulations are strictly observed.
・ Do not place this product in a hot place exceeding temperature specifications or around objects that generate heat such as heaters.
・Do not place this product in a place with extreme vibrations and do not apply a strong impact.
・Do not strongly pull or bend the cable or use the cable bundled.
3．Preparationforuse
 ■PCoperatingenvironment
 ・ T his product is an NFC reader exclusively for the NFC data communication stopwatch [SVAJ701] (caliber
No.:S064)manufacturedbySeikoWatchCorporation.
 ・ T hisproductiscompatiblewithWindows® 7,Windows® 8,andWindows® 10.
 ・ T ousethisproduct,anInternetconnectionenvironmentisrequired.
 ・ O peration of this product in all PC type operating environments cannot be guaranteed. Depending on the
combinationofhardwareandsoftware,thisproductmaynotnormallyoperate.
 ■Installationofdedicatedapplication
 ・ T o transfer data to a PC via this product, the dedicated application is required. Download from the Seiko
WatchCorporationwebsiteforuse.
 (JapaneseOSversion) "S06application(Japanese)"
 (EnglishOSversion)
  h ttp://www.seiko-watch.co.jp/stopwatch/linktopc/
4．Operation
  T imedatastoredintheNFCdatacommunicationsolarstopwatch[SVAJ701]manufacturedbySeikoWatchCorporationcanbetransferred.
  ■ ConnectPC
 ・ C onnecttheUSBportofaPCforuse.Ifthisproductisconnectednormally,agreenlightflashesonthebodyuppersurface.
 ・Toresettheconnection,followtheOSinstructions.
 ■Startthededicatedapplication
 ・ S tartthededicatedapplicationfromtheicononthedesktoporstartmenu.
 ■Transferdata
 ・ T hestopwatchmainbodystoringdatatobetransferredmustbemadetocontactthisproductforuse.

 ※ Forhowtousethestopwatchmainbody,refertothemainbodyinstructionmanual.

 ※ Forhowtousetheapplication,refertotheapplicationinstructionmanual.
5．Ifdataisnotnormallytransferred
 ■Checkthefollowingpoints
 ・Isthisproductplacedonametallicdesk,etc.?
 Communicationsfailuremayoccur,somovethisproductawayfrommetalsourcesbeforeuse.
 ・IsthisproductconnectedcorrectlytotheUSBport?
 CorrectlyconnectthisproducttotheUSBport.WhenthisproductisconnectedtotheUSBhub,makesuretouseaself-poweredhub.
 ・IsthededicatedapplicationinstalledcorrectlyinthePC?
 DownloadfromtheSeikoWatchCorporationwebsite.
■ SPECIFICATIONS
Externaldimensions················98mm×65mm×12.8mm
Weight·······································70g
Cablelength·····························30cm
Externalinterface····················USB(fullspeed)
Operatingtemperature············0℃〜50℃
Operatinghumidity··················0%〜90%(Nocondensation)
Storagetemperature · ···············−10℃〜60℃
Power········································USBbuspowerused

Supplypower · ···························Maximum200mA
ThisproductcomplieswithPart15SubpartCoftheFCCRules.
FCCID:V5MACR122U
FCCNOTICE
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1)Thisdevicemaynotcauseharmfulinterference.
(2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
FCCCAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authoritytooperatetheequipment.
Thistransmittermustnotbeco-locatedoroperatedinconjunctionwithanyotherantennaortransmitter.
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolledenvironmentandmeets
the FCC radio frequency (RF) Exposure Guidelines. This equipment has very low levels of RF energy that are
deemedcomplywithouttestingofspecificabsorptionratio(SAR).
KSJRWT1-A1705
警告
"S06application(English)"
5VDC
FCCRules(FederalCommunicationsCommission)
■NFC READER
 T hisproductisaUSB-compatibleNFCreaderexclusively
f o r N F C d a t a c o m m u n i c a t i o n s s o l a r s t o p w a t c h
[SVAJ701]manufacturedbySeikoWatchCorporation.
1．Introduction
 ■Precautionsforuse:Makesuretoread
This product is format-designated guidance type reader/writer
equipmentbasedontheJapanRadioLaw.Theworkingfrequency
range is 13.56MHz. Peeling off of the label on the rear surface,
removal of the indication, or dismantling or modification of this
productmaybepunishablebylaw.Beforeuse,confirmthatthereis
no reader/writer or wireless equipment in the vicinity using the
sameworkingfrequencyrange.(FormatdesignationNo:AC-13008)
 ・ I fthisproductisusedonametallicdesk,itmaynotworknormally
duetocommunicationsfailure.Ifthisproductdoesnotworknormally,
moveitawayfrommetalsourcessuchasametallicdeskbeforeuse.
 ・ W eshallnotassumeresponsibilityfordatalossormonetary
losscausedbyuseofthisproductandrelatedapplications.
2． Warning:Forsafety
  T hisproducthasbeendesignedwithsafetyinmind,however,mishandling
mayresultinseriousbodilyinjury.Makesuretoobservethefollowing.
  ■ Observeprecautionstatements
  Carefullyreadtheinstructionmanualbeforeuse.
WARNING
CAUTION
■ AFTER-SALE SERVICE
●Notesonguaranteeandrepair
・ F or repair, ask your distributor or the Seiko Sports
ProductServiceCenterlistedbelow.
・ W ithin the guarantee period, present the certificate of
guaranteetoreceiverepairservices.
・ G uaranteecoverageisprovidedinthecertificateofguarantee.
 R eadcarefullyandretainit.
・ F orrepairservicesaftertheguaranteeperiodhasexpired,if
thefunctionsofthisproductcanberestoredbyrepairwork,
wewillundertakerepairservicesuponrequestandpayment.
・ W e do not provide warranties covering data loss or
monetarylosscausedbyuseofthisproduct.
