TLD ASU-600-270-SCP Installation, Assembly And Operating Instructions

Screw compressor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Screw Compressor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASU-600-270-SCP and is the answer not in the manual?

Questions and answers

Summary of Contents for TLD ASU-600-270-SCP

  • Page 1 Screw Compressor...

  • Page 2: Front Page

    Jet-Starter Stage Installation, assembly and operating instructions for VML screw compressor stage A E R Z E N E R M A S C H I N E N F A B R I K G M B H V4-007 J EN 168 405 001 07-2010 V4-007 J EN...

  • Page 3: Note On Information Sheet

    Die INFO-Seite ist vor der Inbetriebnahme durchzulesen. Dort evtl. vermerkte Hinweise und Änderungen sind durchzuführen. Read the INFORMATION sheet prior to commissioning. Possible notes and changes indicated herein are to be effected. La page INFO est à lire avant la mise en route. Y apporter éventuellement des annotations et modifications.

  • Page 4: Overview Of Contents

    Einbauerkärung Declaration of incorporation L e i s t u n g s d a t e n Performance data ENGLISH 1 - 37 Originalbetriebsanleitung INFO - Seite Information sheet zulässige Drehmomente Admissible torques 4TV-1905 V4-007 J EN Originalbetriebsanleitung...
  • Page 5 Einbauerklärung für unvollständige Maschinen gemäß Maschinenrichtlinie 2006/42/EG Declaration of incorporation for partly completed machineries in accordance with Machine Directive 2006/42/EC Déclaration d‘incorporation de quasi-machines selon la directive Machines 2006/42/CE Die Einbauerklärung für diese Drehkolbenmaschine wird von den technischen Angaben im Kapitel „Leistungsdaten“ ergänzt. Die dort erwähnten Angaben identifizieren das Produkt und sind in Verbindung mit dieser Einbauerklärung zu verwenden.
  • Page 6 Inbouwverklaring voor incomplete machines conform machinerichtlijn 2006/42/EG Declaración de incorporación para cuasi máquinas, de conformidad con la Directiva de Máquinas 2006/42/CE Dichiarazione di incorporazione per macchine incomplete secondo la Direttiva macchine 2006/42/CE De inbouwverklaring voor deze roterende zuigercompressor wordt aangevuld door de technische informatie in het hoofdstuk „Specificaties“. Aan de hand van de daar vermelde informatie wordt het product geïdentificeerd en de informatie moet in combinatie met deze inbouwverklaring toegepast worden.

  • Page 7: Note On Spare Parts

    Ersatzteile spare parts, pièces dé tachée, onderdelen, repuestos, pezzi di ricambio - AERZENER MASCHINENFABRIK - Ersatz- und Zubehörteile Es wird darauf hingewiesen, dass nicht von uns gelieferte Originalteile und Zubehör auch nicht von uns geprüft und freigegeben sind. Der Einbau oder Anbau sowie die Verwendung solcher Produkte kann daher unter Umständen konstruktive vorgegebene Eigenschaften der Anlagen beeinflussen.

  • Page 8: Performance Data

    Aerzener Maschinenfabrik Leistungsdaten Performance data V4-007 J EN Originalbetriebsanleitung...

  • Page 9: Table Of Contents

    Table of contents Front page ..................1 Note on information sheet ............2 Overview of contents ..............3 Declaration of incorporation..........4 - 5 Note on spare parts ..............6 Performance data ...............8 Contents ..................9 Suitability/General information ........9 Construction, function ........10 - 11 Precautions prior to and during operation ..12 - 16 Inadmissible operating methods ......17 Transport/Installation ........

  • Page 10: Contents

    Suitability/General information The German version of these instructions is the “Original instructions”. Any version in a language other than German is a “Translation of the original instruc- tions”. Aerzener rotary piston machines are suitable for the oil-free conveying and compression of air and, if specially modified versions are used, various other types of gas.

  • Page 11: Construction, Function

    Construction, function Jet starter: Jet starter are supplied as machines to be installed. Completed with adequate accessory the screw compressor is ready for use. The screw compressors are suitable for steady operation as well as for installation in mobile compressor units. Operation in mobile units may be effected only when the running gear is in idle position.
  • Page 12 Function: Aerzener screw compressors are rotary piston machines whose rotors turn uniformly against each other. Timing gear wheels guarantee contact-free running of the rotors. A drive shaft including the gear ratio ensures that the rotors run at the required speed. During operation, the material to be conveyed flows through the intake flange to the housing and inlet for the rotors.

  • Page 13: Precautions Prior To And During Operation

    Due Care to Be Taken Before and During Operation CAUTION! Identifies all hazardous situations WARNING! Indicates direct risk to personnel Upon arrival/receipt, the rotary piston machine must be checked against the delivery and order documentation to make sure it has not been damaged during transit and is complete.
  • Page 14 Any operation that impairs machine safety is prohibited. The supplier documentation provided with the accessories and the general safety regulations must also be observed. The unit contains rotating components. If their protective equipment, according to the version of the unit, e.g. the acoustic hood, belt guard, coupling guard etc., are not observed or are not used appropriately, there is a Risk of injury! Protective equipment such as the belt guard/coupling guard, blower guard, hood...
  • Page 15 unit must have read and understood the operating instructions. The unit must only be operated by trained and authorised personnel. Personnel must be trained according to the operating instructions. Responsibility for operation must be precisely defined in order to prevent any unclear designation of responsibilities.
  • Page 16 before disassembly. Note the oil temperature when changing the oil. The oil temperature must rise above 60°C. If it is above 60°C, there is a risk of burns! Personal protective measures Conveying ducts or components on the discharge side must not be touched without adequate protection.
  • Page 17 of glowing embers! Depending on the size and increased fire protection regulations, a flame retardant foam would be applied according to the order. Information about the event of damage If the unit produces an abnormal and/or unusual sound, the machine must be shut down immediately using the EMERGENCY BREAK function.

  • Page 18: Inadmissible Operating Methods

    Inadmissible operating methods • Installation on uneven and / slanting foundations. • Securing transport devices to the acoustic hood, e.g. using eye bolts in the accou- stic hood element, winding ropes without expansion braces etc. • Non-observance of operating data. •...

  • Page 19: Transport/Installation

    Transport / Installation When transporting the machine, the following key points must be observed: • Do not expose the compressor to impact loads. • Transport the compressor using a crane, fork-lift truck, lift trolley or similar. • Use suitable hoisting gear that is appropriate for the load concerned. Failure to observe this point could result in damage or injury! •...
  • Page 20 During installation the following points must be observed: • Prior to delivery, rotary piston machines are treated and packaged to allow for a 12-month storage period. If they are to remain in storage following this 12-month period, they will need to be retreated; see storage and mothballing guidelines TN0 1175.
  • Page 21 VML compressor: -10°C ≤ ≤ +50°C -10°C ≤ ≤ +50°C ) ≤ 20 K delta t ≤ 180 K ≤ 230°C = Ambient temperature/compressor housing temperature = Intake temperature = Discharge temperature delta (t) = t ≤ less than, equal to Rel. air humidity : 0% •...

  • Page 22: Commissioning

    Commissioning Install and assemble the compressor stage in accordance with these instructions. Assemble the driving elements correctly. CAUTION! Do not establish any connection with the driving motor yet. On first commissioning: Fill up lubricating oil on empty machines. Check lubricating oil level and correct if necessary. Check that the oil filling plug and the drain valve are seated securely and do not leak.

  • Page 23: Shutting Down/Taking Out Of Operation

    Switch off / shutdown • Switch off is carried out using the motor power switch. • If the drive motor is shut down in an operating position with back pressure, the pressure decelerates the compressor and brings it to a standstill more quickly. The non-return valve installed at the discharge side closes, which prevents the com- pressor from decompressing the compressed material and running in reverse.

  • Page 24: Maintenance

    Maintenance Maintenance is to ensure that all functions are maintained or that they can be restored after a breakdown. Maintenance includes specifications about inspection, service and repairs. Maintenance includes instructions for trained and qualified personnel. If anything is unclear consult Aerzener customer service. During inquiries please state: •...

  • Page 25: Inspection/Inspection Schedule

    Inspections / inspection schedule A general inspection should be carried out by a service technician from Aerzener after 3 years or 20,000 operating hours. This includes the preventive maintenance of wearing and replacement parts such as bea- rings, seal, etc. We recommend maintaining a stock of replacement and wearing parts to avoid or reduce waiting times and downtimes.

  • Page 26: Maintenance Schedule

    Maintenance schedule Whenever work is carried out on the rotary piston machine, it must be switched off and isolated from the electrical mains supply. Failure to observe this point could result in injury or damage. To ensure a long service life and optimum operating conditions, various steps should be taken. These include observ- ance of the maintenance operations and intervals specified in this table.

  • Page 27: Lubricating Oil Specification

    Lubricating oil specifications for VM / VML screw compressors Additives and viscosity class are the defining factors in selecting types of lubricating oil. The following oils, which are of the correct viscosity and contain appropriate additives, are to be used in accordance with the relevant operating conditions. General requirements for lubricating oil properties Kinematic viscosity at oil operating temperature : 10 - 13 cSt (mm...
  • Page 28 4. Lubricating oils in the foodstuffs and pharmaceutical industry Usage as per point 2, 3, 5 Lubricant to be used : ISO VG 46 Klüber oil Hy Syn FG 46 ISO VG 68 Klüber oil Hy Syn FG 68 Lubricating oils for VM screw compressors Continuous operation with differential pressure <...

  • Page 29: Lubricating Oil Quantities

    Lubricating oil quantities Total oil fill volume (approx.) in litres/oil level in centre of upper sight glass on compressor stage approx. litres approx. USG 12 l VML 35 VML 210 28 l VML 60 VML 310 30 l VML 95 VML 410 50 l 13,2...
  • Page 30 VM ... / VML ... VML 150 / VML 250 Beispiel / example a) Draining oil The waste oil is to be collected in a container in the proper manner and disposed of in an environmentally friendly way at an appropriate collecting station. Please note the capacity of the container.

  • Page 31: Oil Filter

    Oil filter • You must replace or clean the oil filter every time the lubricating oil is changed. • The fineness of the filter is 7 µm and its resistance, when clean, is around 0.2 bar. • The maximum resistance must NOT exceed 2.0 bar.

  • Page 32: Oil Pressure Regulating Valve

    Oil pressure regulating valve • The oil pressure is determined by the setting range of the oil pressure regulating valve and the prevailing operating parameters. • The oil pressure is factory-set and must be within a limiting value range of 1.8 bar (o) and 5.0 bar (o).

  • Page 33: Intake Filter

    8.10 Intake filter Before replacing the filter element, take the compressor unit out of operation and prevent it from being started up inadvertently. Please observe the instructions of the unit manufacturer too! • Check degree of filter soiling and replace filter cartridge if necessary, max.

  • Page 34: High-Lift Spring Safety Relief Valve

    8.12 High-lift spring safety relief valve Please observe the instructions of the unit manufacturer! • If the equipment downstream of this point does not feature protection to the same standard, you must install another safety relief valve after the non-return valve. •...

  • Page 35: Drive Coupling

    8.13 Drive coupling Please observe the instructions of the unit manufacturer! Whenever work is carried out on the drive coupling, the machine must be taken out of operation and correctly isolated from the mains supply. The machine must be prevented from starting up/being operated. Caution: The coupling is potentially dangerous and can sever and/or crush body parts.
  • Page 36 8.13 driving side compressor connection flange V4-007 J EN Originalbetriebsanleitung...

  • Page 37: Repairs

    Error diagnostics/Troubleshooting/Maintenance Repairs to rotary piston machines may only be performed by authorised and trained personnel. Improper repairs may present considerable risks to the user/ personnel. Error messages/ Faults Possible Remedy . . What do I do causes . . if .
  • Page 38 Error messages/ Faults Possible Remedy . . What do I do causes . . if . . ? ...if damage to the • Motor and electr. control • Connect motor and machine occurs as have been connected to control voltage to a single a result of a faulty two different networks.

  • Page 39: Recycling

    Recycling / Disposal • All waste products are to be disposed of or treated not harmful to the environment. • Used lubricants are to be disposed of properly. • Contaminated components and auxiliary material are to be packed and decontaminated. V4-007 J EN Originalbetriebsanleitung...

  • Page 40: Information Sheet

    INFO - SEITE Information sheet Page infos Info - bladzijde PaginaInformativa Gegenüber Darstellungen und Angaben dieser Betriebsanleitung sind technische Änderungen, die zur Verbesserung der Drehkolbenmaschinen notwendig werden, vorbehalten. This operating- and installation manual is subject to engineering changes necessary for the compressor advancement. Nous nous réservons le droit dans les instructions de service procéder à...
  • Page 41 V4-007 J EN Originalbetriebsanleitung...
  • Page 42 Zulässige Drehmomente in Nm in der Antriebswelle bei VM / VML-Verdichtern mit Getriebe i 10 i 11 i 12 i 13 i 14 VML 35 (VML 210) VG 12.5 VML 60 1420 1420 1420 1420 1420 1420 1420 1420 1420 1420 1420 1420...
  • Page 43 Aerzener Maschinenfabrik GmbH Reherweg 28 31855 Aerzen Postfach 1163 31849 Aerzen Telefax 0 51 54 / 81-191 e-mail info@aerzener.de After Sales Ser-  vice 0 51 54 / 81-529 erzener nternational ental B.V. www.airental.nl phone +31 (0) 26 44 64 723 Telefax +31 (0) 26 44 63 570 e-mail...
