Summary of Contents for Elmec EVduty EVCCS
- Page 1 User Manual EVduty EVCCS SMART CURRENT SENSOR 19378-R1...
-
Page 2: Table Of Contents
Table of contents ___________________________________________________________________________ Product _____________________________________________________________ Technical specifications ________________________________________________________________________ Installation _______________________________________________________________ Current sensing type Configuration _________________________________________________ A: Configuration of the EVCCS module ___________________________________ B: Configuration of the EVduty EVC30 charging station(s) C: Fonction check _____________________________________________________________________________ ________________________________________________________________________ Operation __________________________________________________________________ Troubleshooting _______________________________________________________________________ Contact us __________________________________________________________________ Limited Warranty Figure list... -
Page 3: Product
Product The EVduty EVCCS is a smart current sensor that measures an electrical panel’s current consumption in real time. The sensor sends the measured current’s information to one or more EVduty EVC30 charging stations electrically connected to this panel. The EVC30 charging station(s) can then adjust their maximum charging current to ensure that the electrical panel ‘s total current consumption does not exceed the limit of the main circuit breaker protecting... - Page 4 Product Here is a description of the main parts of this equipment: Figure 2: Parts description Current sensors terminal blocks Power LED RJ45 Ethernet socket Network communication LED Power port Error LED Internal WiFi antenna...
-
Page 5: Technical Specifications
Technical specifications POWER Input voltage: 100 – 240 VAC 50/60Hz Cable length: 1.5 m (5') CURRENT SENSORS Clamp-on current transformer Opening diameter: 24.2 mm (0.95") Dimensions: 70 mm x 44 mm (2.75" x 1.73") Cable length: 3.05 m (10') CURRENT READING RANGE 0-200A OPERATING TEMPERATURE -15°C to 40°C (5°F to 104°F) -
Page 6: Installation
Installation 1. Locate the ideal place to install the EVCCS module. This place must meet the following requirements: • Be in a dry and temperate environment. • Be at a reasonable distance from the electrical panel, where the current sensors will be installed. •... -
Page 7: Current Sensing Type
Current sensing type Two different types of current sensing are possible. Upstream Electrical panel With this configuration, current sensors measure the total current consumed by all electrical equipment powered by the main electrical panel. Main circuit breaker EVCCS module 200 A Branch circuit breaker Charging station... -
Page 8: Configuration
Configuration After completing the physical installation of the EVCCS module, you must complete the EVCCS module’s initial configuration. Afterward, the EVduty EVC30 charging station(s) must also be configured so that they can correctly receive the information emitted by the EVCCS module. A: CONFIGURATION OF THE EVCCS MODULE 1. - Page 9 Configuration 6. A main menu will appear (see Figure 7). Click on "Configuration". Figure 7: EVCCS module configuration – Main menu...
- Page 10 Configuration 7. A configuration form will be displayed (see Figure 8). Change values according to the desired configuration. Figure 8: EVCCS module configuration – Configuration a) Channel ID Selecting the channel ID between the EVCCS module and the EVduty EVC30 charging station(s). Possible value: between 1 and 20 Default value: 1 NOTE: If multiple EVCCS modules are used on the same LAN, a different channel ID...
- Page 11 Configuration d) WiFi Network SSID (Optional) Select the WiFi network to which the EVCCS module is to connect. Possible value: list of WiFi networks Default value: disabled e) WiFi Network SSID (Optional) Manually enter the name of the WiFi network to which the EVCCS module is to connect. Fill this box only if the target WiFi network does not appear for security reasons.
-
Page 12: B: Configuration Of The Evduty Evc30 Charging Station(S)
Configuration B: CONFIGURATION OF THE EVDUTY EVC30 CHARGING STATION(S) NOTE: In order to be compatible with the EVCCS module, the EVC30 charging station’s internal software version must be equal to or higher than "1.3.0.24-X.X.X.X". 1. Make sure the EVC30 charging station is not currently charging a vehicle. Disconnect from the vehicle if necessary. 2. - Page 13 Configuration 8. A main menu will be displayed (see Figure 10). Click "Configuration". Figure 10: EVC30 charging station configuration – Main menu...
-
Page 14: C: Fonction Check
Configuration 9. A configuration form will appear (see Figure 11). Change values according to the desired configuration. Figure 11: EVC30 charging station configuration – Configuration a) WiFi Network SSID Select the WiFi network to which the EVC30 charging station is to connect. Possible value: list of WiFi networks Default value: N/A b) WiFi network SSID... -
Page 15: Operation
Operation The EVCCS module does not need any external action while it is in operation. However, the light indicators on the EVCCS module may give useful information about the equipment's operating status. Here is a description of the EVCCS light indicators’ possible states: Table 1: States of light indicators COLOUR STATE... -
Page 16: Troubleshooting
Troubleshooting Table 2 lists some of the most common problems as well as their causes and possible solutions. Table 2: Troubleshooting PROBLEM CAUSE SOLUTION Check that the power outlet in which the power supply is plugged The EVCCS module provides adequate voltage. "Power"... -
Page 17: Contact Us
Contact us POSTAL ADDRESS Service support Elmec 1141, 2 Avenue, Shawinigan (Québec) G9T 2X9 SERVICE SUPPORT 819 533-3888 819 533-3074 EMAIL info@elmec.ca WEBSITE elmec.ca... -
Page 18: Limited Warranty
WHAT ELMEC WILL DO? Elmec will repair any EVCCS module judged to have a defect or malfunction by a qualified Elmec technician. In the event repair is not possible, Elmec will replace the EVCCS module with a new one of similar specifications and price.
