WHAT'S INCLUDED
• USB 2.0 cable
• DC cable
• CD recording software—Nero 16 essentials
• User guide
• DVD/CD drive
FRONT DISPLAY
LED indicator
EJECT button
Manual ejection opening
REAR DISPLAY
USB 2.0 port
CABLE IDENTIFICATION
DC Plug
USB 2.0 cable
FEATURES
• Supports both 8cm and 12cm discs
• Supports all of the popular CD and DVD formats
• Multi-recorder for DVD±R/DVD±RW/CD-RW
• Supports hot swapping and plug-and-play functions
• Buffer underrun technology to prevent errors
• High-speed USB 2.0
EXTERNAL SLIM DVD/CD DRIVE
Instruction Manual
DC power jack
OPERATING INSTRUCTIONS
INSTALLING THE DRIVE
1. Plug the USB 2.0 connector into the device's rear USB 2.0 port.
2. Plug the DC plug into the device's rear DC power jack.
USB 2.0 plug
DC plug
TRAY OPERATION
Press the EJECTION button and the tray will automatically eject, allowing
you access to take or put in a disc.
TROUBLESHOOTING
Why is my USB 2.0 device reading, boot failure?
• Please make sure your disc is not scratched or bent
• Please make sure the version of BIOS supports booting from external
CD-ROM, if not, please upgrade your BIOS version
• The device does not support pure DOS mode
NOTE: Any improper procedures will affect the function of the com-
puter. Please read the user manual, or contact your computer provider
before use.
SYSTEM REQUIREMENTS
Windows 7/8/10
Interface: USB 2.0
NERO 16—SUPPORT
Windows 7 (32/64-bit)
Windows 8 (32-64-bit)
Windows 10 (32/64-bit)
NOTE: Nero software is for Windows based PC systems only.
READ SPEEDS:
8x DVD+R
8x DVD+RW
6x DVD+R Dual Layer
24x CD-R
24x CD-RW
8x DVD-ROM
24x CD-ROM
NOTE: LED light will blink when the device is reading and writing data.
sku 8014508
WRITE SPEEDS:
8x DVD+R
8x DVD+RW
6x DVD+R Dual Layer
24x CD-R
24x CD-RW
Advertisement
Table of Contents
Related Manuals for Vital 8014508
Summary of Contents for Vital 8014508
- Page 1 EXTERNAL SLIM DVD/CD DRIVE sku 8014508 Instruction Manual WHAT’S INCLUDED OPERATING INSTRUCTIONS • USB 2.0 cable INSTALLING THE DRIVE • DC cable 1. Plug the USB 2.0 connector into the device’s rear USB 2.0 port. • CD recording software—Nero 16 essentials 2.
- Page 2 SPECIFICATIONS Disc diameter 8cm/12cm OS compatibility Windows 7/8/10 Software Nero 16 Essentials Dimensions 135mm x 137mm x 18mm Weight 281g Temperature Operating 0-50˚C Temperature Storage -40-65˚C Humidity Operating 10-90 (%HR) Humidity Storage 5-95 (%HR) CAUTION Some computers may not provide enough power supply via the USB port alone.
