- Page 1 User Manual Temperature Controller PCE-RE21R, PCE-RE21S, PCE-RE21T User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 1 October 2019 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
“At”PID parameter auto-tuning..................5 Parameter list and function ..............5 Field parameters ......................5 Field parameter ........................ 6 Default settings ..................7 Wiring diagram ..................8 10 Note ......................8 11 Warranty ....................9 12 Disposal ....................9 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Main Features
IEC61000-4-4 (Electrical Fast Transient Burst) ±4KV / 5KHz; compatibility (EMC) IEC61000-4-5 (Surge), 4KV Between power relay contact or signal terminals ≥ 2300V DC; Isolation between isolated electroweak terminals ≥ 600V withstanding voltage Temperature: 0~60 °C; Humidity ≤ 90% RH Operating Ambient © PCE Instruments... -
Page 5: Front Panel Descrition
5. Setup key: For accessing parameter table and conforming parameter modification 6. Enter key: For confirm and change to another Parameter 7. Data shift key 8. Data decrease key 9. Data decrease key Size Multiple install cutouts Single install cutout © PCE Instruments... -
Page 6: Display The Status And Basic Operation
(cursor), the operation is more efficient. key can be stored to modify parameter values and display the next parameter, press and hold key 2 seconds, and can return to the previous parameter; can immediately exit the parameter setting state. © PCE Instruments... -
Page 7: Set Value Setting
LOC<9000, will automatically for 0, allowed to modify the SV Set Value. LOC≥9000, are not allowed to Parameter modify the SV Set Value. Set the LOC = 800, then 0~9999 lock press key to confirm, can enter the following system parameters. © PCE Instruments... -
Page 8: Field Parameter
PV > SV, output turns off; when PV<SV-HYS, output turns on. For a direct acting (cooling) system, when PV<SV, output turns off; when PV>SV+HYS, output turns on. Input Signal Input spec: K、E、J、N、Pt（Pt100） Decimal 0 (no decimal), 0.0 (one decimal place). point © PCE Instruments... -
Page 9: Default Settings
Temperature °C °C：celsius equals Unit select. °F °F：fahenheit equals Low limit Minimum value that SV is allowed to be. -999~ of SV +3200 Upper limit Maximum value that SV is allowed to be. of SV Default settings © PCE Instruments... -
Page 10: Wiring Diagram
Resistance of the lead, you should use the minimal resistance of the wire and cable away from power lines and load connection, in order to avoid signal interference. © PCE Instruments... -
Page 11: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 12 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
