JA SOLAR INSTALLATION MANUAL
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions for the Solar Photovoltaic Modules (hereafter referred to as "Modules") of
Shanghai JA Solar Technology Co., Ltd. (hereafter referred to as "JA Solar"). Installers should follow all safety precautions
described in this guide as well as local codes when installing a Module.
Installing solar photovoltaic systems requires specialized skills and knowledge. Installation should only be performed by qualified
personnel. Before installing a solar photovoltaic system, installers should familiarize themselves with its mechanical and electrical
requirements. Keep this guide in a safe place for future reference and in case of sale or disposal of the Modules.
For any questions, please contact our Global Quality and Customer Service department for further information.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JAM5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JA SOLAR JAM5 Series

  • Page 1 This manual contains important safety instructions for the Solar Photovoltaic Modules (hereafter referred to as “Modules”) of Shanghai JA Solar Technology Co., Ltd. (hereafter referred to as “JA Solar”). Installers should follow all safety precautions Hefei JA Solar Technology Co., Ltd.
  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION ------------------------------------------------------- 2 CODES AND REGULATIONS ---------------------------------------- 2 GENERAL -------------------------------------------------------------- 3 3.1 Product Identification --------------------------------------------------------------- 4 3.2 Conventional Safety ----------------------------------------------------------------- 4 3.3 Electrical Performance Safety ------------------------------------------------------ 5 3.4 Operating Safety --------------------------------------------------------------------- 6 3.5 Fire Safety ---------------------------------------------------------------------------- 7 INSTALLATION CONDITION ------------------------------------------ 8 4.1 Installation Position and Working Environment ----------------------------------- 8 4.2 Tilt Angle Selection ------------------------------------------------------------------ 9 MECHANICAL INSTALLATION --------------------------------------- 10...
  • Page 3: Introduction

    Modules. No responsibility is assumed by JA Solar for any infringement of patents or other rights of third parties that may result from use of Modules.
  • Page 4: Product Identification

    Faulty connections can also result in arcs and electrical shock. So please keep JA Solar Modules are designed to meet the requirements of IEC 61215 and IEC 61730, connectors dry and clean, and ensure that they are in proper working condition. Never application class A.
  • Page 5: Operating Safety

    Work only under dry conditions, and use only dry tools. Do not handle Modules when they are wet unless wearing appropriate protective equipment. Do not open packages of JA Solar Modules during transportation and storing until they are When storing uninstalled Modules outdoor for any period of time, always cover the Modules ready to be installed.
  • Page 6: Installation Condition

    JA Solar Modules have passed salt mist corrosion resistance test according to IEC 61701, JA Solar Modules are intended for use in terrestrial applications only—no for outer space use. but galvanic corrosion can occur between the aluminum frame of the Modules and Modules must not be installed nor operated in areas where, salt, hail, snow, sand, dust, air mounting or grounding hardware if such hardware is comprised of dissimilar metals.
  • Page 7: Mechanical Installation

    5.1 Conventional Requirement mechanical load. JA Solar Modules have been certified for a maximum static load on the back side of 2400 Ensure the installation method and supporting system of Modules is strong enough Pa (i.e. wind load) and a maximum static load on the front side of either 2400 Pa or 5400 to make the Modules to able to withstand all the load conditions.
  • Page 8 JA SOLAR INSTALLATION MANUAL JA SOLAR INSTALLATION MANUAL MECHANICAL INSTALLATION MECHANICAL INSTALLATION Figure 2 Size: No less than 38mm) width Mounting Details Thickness: No less than 3mm Material: Aluminum Alloy Bolt: M8 B) Recommended bolt torque range: 18N.m to 24N.m.
  • Page 9 JA SOLAR INSTALLATION MANUAL JA SOLAR INSTALLATION MANUAL MECHANICAL INSTALLATION MECHANICAL INSTALLATION 5.2.3 Description of the installation position Figure 4: Installation Methods The following low/normal level of load conditions is applicable to the installation in most environment: the maximum static load on the back of the Modules is 2400 Pa (i.e. wind load), and the maximum static load on the front of the Modules is 2400 Pa (i.e.
  • Page 10: Electrical Installation

    (The maximum system voltage of JA Solar Modules is DC 1000V Rated electrical characteristics such as Isc, Voc and Pmax are measured within +/- 3% of according to the safety appraisal of the IEC61730) of the Modules and all other electrical measurement uncertainty at Standard Test Conditions.
  • Page 11: Connectors

    JA Solar Modules use an anodic oxidized aluminum frame to resist corrosion. So the frame of Modules must be connected to specifically designed to attach to the Modules frame. While the cables are sunlight resistant the equipment grounding conductor to prevent thunder and static injury.
  • Page 12: Grounding By Using Unused Grounding Hole

    7.3 Additional Third-party Grounding Devices 7.2 Grounding by Using Unused Grounding Hole JA Solar Modules can be grounded using third party grounding devices so long as they are certified for grounding Modules and the devices are installed according to the manufacturer’...
  • Page 13: Operation And Maintenance

    Modules, such as other Modules, system support, bird drops and a lot of dust, clay or plant and so on, these may distinctly reduce the power output. JA Solar advises that there should be no obstructed object over the Modules surface at any time.
  • Page 14: Product Supplement

    JA SOLAR INSTALLATION MANUAL JA SOLAR INSTALLATION MANUAL PRODUCT SUPPLEMENT PRODUCT SUPPLEMENT PRODUCT SUPPLEMENT Remarks: 1 Electrical Characteristics “***”shows the Peak power of the Modules,It is equal to "Max Power at STC". “(BK)” means black Modules. For example, "JAM5(L)-72-215/SI" means the Modules made with 72 pieces of 5-inch mono cells, and the modules' peak power are 215W.
  • Page 15 JA SOLAR INSTALLATION MANUAL JA SOLAR INSTALLATION MANUAL PRODUCT SUPPLEMENT PRODUCT SUPPLEMENT Temperature Temperature Temperature Max Power at STC Open Circuit Voltage Max Power Voltage Short Circuit Current Max Power Current Max Series fuse Module Efficiency Max System Voltage Coefficient of Isc...
  • Page 16 JA SOLAR INSTALLATION MANUAL JA SOLAR INSTALLATION MANUAL PRODUCT SUPPLEMENT PRODUCT SUPPLEMENT Temperature Temperature Temperature Max Power at STC Open Circuit Voltage Max Power Voltage Short Circuit Current Max Power Current Max Series fuse Module Efficiency Max System Voltage Coefficient of Isc...
  • Page 17: Design Size Of Modules

    JA SOLAR INSTALLATION MANUAL JA SOLAR INSTALLATION MANUAL PRODUCT SUPPLEMENT PRODUCT SUPPLEMENT 2 Design Size of Modules Overall Dimension:1482×991×40×30mm Overall Dimension:1580×808×40×30mm Overall Dimension:1650×991×40×30mm Overall Dimension:1956×991×45×35mm Overall Dimension:1580×1062×40×30mm Overall Dimension:1630×980×35×28mm...
