Summary of Contents for Acepen AP2151
- Page 1 Interactive Pen Display AP2151 MANUAL Windows 2000/XP/Vista/7/8/10;Mac OS X 10.68 or above WWW.ACE-PEN.COM...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Please read these instructions carefully before using the product and keep the user’s manual for later reference. This product should be operated from the type of power indicated on the marking label. If you are not sure of the type of power available, consult your dealer or local power company. Unplug this product from the wall outlet before cleaning.
-
Page 3: Table Of Contents
Catalog Introduction ..........................1 Installation ..........................2 Component Description ....................... 7 Display Control ........................9 Specifications(21.5”) ......................10 Trouble shooting ........................12... -
Page 5: Introduction
1. Introduction 1-1. About the product This product is an integrated LED tablet designed for direct drawing on screen interface with your computer. 1-2. System Requirements Operation System (Windows 2000 /XP/vista/7/8/10) Pentium 233MHz (or equivalent) processor or higher 64MB of Ram (128MB recommended) 128 MB setup Hard disk space 4X speed CD ROM or higher An available USB port... -
Page 6: Installation
2. Installation 2-1. Power & Signal connections (Figure-1) Power: Be sure both of your computer and the Tablet monitor are power off. Power cable connection: Connect the power cord to the AC outlet, and connect the power with the tablet monitor through the AC/DC (12V) adapter. - Page 7 2-3. Using the Tablet driving software Click on the tablet icon at the bottom right of the tool bar^to enter the tablet screen (The tablet icon appears when the cable is plugged in.) Info...
- Page 8 Button...
- Page 9 Pressure...
- Page 10 Calibration...
-
Page 11: Component Description
3. Component Description 3-1. Rear View “Adjusting Stand lever” : To adjust the Tablet monitor in an optimum tilt position for different applications. - Page 12 The monitor OSD control keys are located on the back/left Rear side of the panel. They are shown in the figure below and described in the following paragraphs. “Power”: Push power switch to turn power ON or OFF. "Cancel”: Push cancel switch to cancel the menu windows. “+”...
-
Page 13: Display Control
4. Display Control 4-1. Menu Description Picture sub-menu 【Backlight】 ：Adjust the backlight brightness. 【Brightness】 ：Adjust the screen brightness. 【Contrast】 ：Adjust the screen contrast. 【Sharpness】 ：Adjust the screen sharpness. Color sub-menu 【Gamma】 ：Adjust the color gamma. 【Temperature】 ：Adjust the color temperature. 【Color Effect】... -
Page 14: Specifications(21.5")
5. Specifications(21.5”) 5-1. LED Monitor Display item Specification Dimensions 528 mm x 332 mm x 14 mm Weight 6.7 (kg) Display Area 475.2 mm x 267.3 mm (WxH) Resolution 1920x1080 Response Time Pixel Pitch 0.2475 x 0.2475 mm Maximum Induction Angle 50°(angle between the normal display) Support Color 16.7 M... - Page 15 5-2. Tablet Item Specification Technology Electromagnetic Item 475.2 mm x 267.3 mm (WxH) Pressure Sensitivity 2048 levels Resolution 5080 LPI (lines/inch) Accuracy Center±0.5mm，the maximum deviation ±3mm Reading Height Not less than 5mm(Above the surface the glass) Power line 1.5m AC power line Power adapter External power adapter (input 100-240VAC, 50 / 60Hz, output 12VDC5A) Data Interface...
-
Page 16: Trouble Shooting
6. Trouble shooting If your tablet monitor fails to operate correctly, consult the following table for possible solution before calling for repairs: Condition Check Point Check to make sure the signal cable is firmly seated in the socket The picture does not Check that the Power is ON at the computer appear Check that the brightness or contrast control is at the appropriate... - Page 17 If your tablet monitor fails to operate correctly, consult the following table for possible solution before calling for repairs: No scene picture. Check the power and weather the signal line is connected. Check if the switch for the display is on. Adjust the brightness and contrast.
- Page 18 Thank you for purchasing Acepen pen display, if you want to know more Acepen products, please check our website: www.ace-pen.com...
