Summary of Contents for SMARTPONG Table Tennis Robot
- Page 1 SMARTPONG SMARTest ping PONG robot in the world INSTALLATION AND TROUBLESHOOTING BRIEF INSTRUCTION GUIDE...
- Page 2 SMARTPONG We appreciate very much for your purchase of the SMARTPONG The microcomputer fully automatic table tennis robot. For detailed information, please refer to the USER’S MANUAL. Cautions: 100 pieces of 40mm balls has been enclosed in packing carton. When the balls are squished, please do not put it into machine to avoid damage.
- Page 3 Steps to Install the Ball Blender Device to Prevent Balls from Obstructing Operation ILLUSTRATE instructions 1.Load motor (A) on the center trough of undercarriage. 2.Put 2 screws (B) into the hole, then fasten them. 3.Put plug (C) into outlet (D).
- Page 4 Table Tennis Robot Assembly and Disassembly (1) Left/Right Pipe (2) Transparent Cap (3) Ball Separator (4) Base (Undercarriage or ball service tray) (5) Right Pipe (6) Left Pipe (7) Left/Right Ball collecting tray (ball track) (8) Server Head (9) Infrared Sensor...
- Page 5 Disassembly Cleaning and Maintenance It takes only 2 minutes to disassemble this system. How to Clean the Shell 1.Unplug the AC power cord. A soft piece of cloth is sufficient for moderate 2.Place your hands beside the base, lift the whole soiling.
- Page 6 Solutions for the Balls are Obstructed Step1: Pull out the AC power plug and the power wire of the ball blender device. The AC Power plug The power wire of the ball blender device Step4: Step2: Loosen the butterfly shape nut. Install the ball separation board Into undercarriage.(As figure shown below)
- Page 7 Brief Instructions for Troubleshooting Remarks: 1.This device does not require any modification. If 3.If your problem is not found in the list, please any breakdown occurs, check the following to contact the dealer. Never try to reassemble it by yourself. solve problems.
