Side Panel Diagram
Default Settings for the Rugged Vision DVR
• All Cameras are enabled and recording continuously 24/7
• Date and Time info (can be changed under Setup/System/Date/Time)
* Date – internal time clock will bring up the correct date when system is powered
* Time – set to central time zone (GMT-6)
• Network Settings (Statically assigned through the Rugged CCTV test network)
- IP Address – 192.168.001.012
- Subnet Mask – 255.255.255.000
- Default Gateway – 192.168.001.001
- DNS completely left as 0's
- These will more than likely need to be changed to be able to communicate with the customers network
• User names and Passwords (these can be changed under setup/Admin/system/user)
* At the DVR
- Admin and 5678
- User5 and 5555
- User1 and 1111
- User6 and 6666
- User2 and 2222
- User7 and 7777
- User3 and 3333
- User8 and 8888
- User4 and 4444
- User9 and 9999
* On the remote software – admin and password
* Through web browser - Admin and 5678
RUGGED CCTV
201 North Elm Street, Kemp, Texas 75143
1-866-301-CCTV
Phone: 903-498-3240 • Fax: 903-498-8989
www.rugged-cctv.com
techsupport@rugged-cctv.com
Mode
MODE
UP
DOWN
RIGHT
LEFT
SELECT
BACK
RUGGED
Quick
Reference
Guide
