MANUAL
TMA FREEDOM 200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TMA Freedom 200 and is the answer not in the manual?

Questions and answers

Related Manuals for Taramps TMA Freedom 200

Summary of Contents for Taramps TMA Freedom 200

  • Page 1 MANUAL TMA FREEDOM 200...

  • Page 2: Before You Begin

    ATTENTION: We recommend reading this manual before installation! This product aims to prevent or inhibit the theft of the motorcycle. • Before contacting the TARAMPS technical support, read this manual, it contains all • information necessary for installation and use.

  • Page 3: Remote Control Functions

    4) Remote Control Functions FUNCTION ACTION IN CONTROL ALARM RESPONSE 4.1 Arm the Alarm Turn lights flash once beep siren. Press Turn lights flash twice siren beeps twice. Note: If you hear four fast siren chirps Press 4.2 Disarm the Alarm and turn lights blinks 4 times, it indicates that was a triggering when the alarm was armed...
  • Page 4 INSTALLER: You can only use one Anti Carjacking type at a time, by presence, or by Secret Button. Inform the user to use the ignition key item 12 Only It can disable the alarm when the remote control is lost. 5) Types of Anti Carjacking (enable the secret button) 5.1 ANTI CARJACKING by SECRET BUTTON: With the function enabled in the...
  • Page 5 6) Presence function -TR2-P control ACTIVATE DISABLE TRANSMISSION: TRANSMISSION: PRESS SIMULTANEOUSLY: PRESS SIMULTANEOUSLY: Until the LED Until the LED turns off and blinks 1x. turns off and blinks 2x. 6.1 ENABLING PRESENCE MODE IN THE TR2-P CONTROL: Press the buttons simultaneously until the LED turns off...

  • Page 6: Alarm Functions

    2 beeps - Auxiliary sensor 3 beeps - Ignition 7.3 SLEEP FUNCTION (motorcycle battery saving) Exclusive for the TARAMPS Alarm. Function enabled by defaut. item 11.10 When the alarm is turned on by the remote control, after 24 hours, the system enters Sleep mode.

  • Page 7: Tilt Sensor

    Presence control. 9) Tilt Sensor The TARAMPS TMA Freedom alarm has an accelerometer in the control unit, which check and store the tilt of the motorcycle when turned on by the remote control when it is changed, triggers the alarm.
  • Page 8 11) Programming Turn the ignition on, and then connect the Programming wire (Orange / Black) to the + 12V of the motorcycle battery. Wait for the beep of the desired function, as shown in the table below. Disconnect the Orange / Black wire to confirm the programming change.
  • Page 9 Ignition Password - Disable Alarm Without Control 1 2 ) In case of problems with the remote control (low battery, malfunction or loss), it is possible to disable the alarm by the ignition password even when triggered. With the alarm is disabled, it won’t work until it is enabled again by the ignition password.
