P2P Wireless Bridge User Guide

Overview:

Thank you for purchasing a Point-to-Point (P2P) Wireless Bridge from Venco Business Solutions.
The P2P Wireless Bridge allows you to wirelessly transmit an existing Internet connection (DSL,
cable modem, etc) to your ATM or Jukebox. Simply plug in the included Transmitter to the
Internet connec- tion, and the included Receiver to your ATM or Jukebox and wirelessly transmit
the signal up to 300 feet though walls, floors, etc.
All components come pre-configured from our factory, and require no changes in configuration for
any of your existing Internet connectivity. The P2P Wireless Bridge is ready to use right out of the
box, making it a true plug-and-play solution!
This guide will help you install and deploy your new P2P Wireless Bridge. Should you have ques-
tions, please call our technical support line at (800) 762-9962, or visit us online at
www.vencosolutions.com.
** Note, the P2P Wireless Bridge is compatible with TCP/IP capable ATMs.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ubiquiti NanoStation Loco M2 and is the answer not in the manual?

Questions and answers

Summary of Contents for VENCO Ubiquiti NanoStation Loco M2

  • Page 1 P2P Wireless Bridge User Guide Overview: Thank you for purchasing a Point-to-Point (P2P) Wireless Bridge from Venco Business Solutions. The P2P Wireless Bridge allows you to wirelessly transmit an existing Internet connection (DSL, cable modem, etc) to your ATM or Jukebox. Simply plug in the included Transmitter to the Internet connec- tion, and the included Receiver to your ATM or Jukebox and wirelessly transmit the signal up to 300 feet though walls, floors, etc.
  • Page 2 pg. 2 of 6 Package Contents:  The P2P Wireless Bridge is comprised of: one (1) Transmitter, one (1) Receiver, and four (4) Ethernet cables.  The Transmitter and Receiver boxes each contain: Power adapter Transmitter or Receiver (2) CAT-5 Cables...
  • Page 3 pg. 3 of 6 Setup Instructions: ** Please refer to the System Diagram (in the Appendix), in conjunction with the instructions below to set up your PTP Wireless Bridge. 1. Power off the networked device (ATM, kiosk, etc). 2. Connect the Transmitter to your existing Internet connection (see diagram in the Appendix) A.
  • Page 4 pg. 4 of 6 P2P Wireless Bridge System Diagram:...
  • Page 5 pg. 5 of 6 Troubleshooting: Do NOT press the reset but at anytime Each P2P Wireless Bridge is thoroughly tested in our factory prior to shipping. Should you experi- ence problems with your P2P Wireless Bridge, please verify that all setup instructions in this guide were followed appropriately, and refer to the following Troubleshooting steps.
  • Page 6 pg. 6 of 6 Mounting/Aiming: Transmitter/Receiver can be either mounted on existing brackets/walls/etc, or laid on its side. Users should experiment with both methods to maximize signal quality. Option 1: Position Transmitter or Receiver on its side, aiming in the general direction of the other. other.
