Summary of Contents for CLEAN ROOM DEVICES CRD 410
- Page 1 CRD 410 MANUAL FITTING INSERTER OPERATIONS MANUAL VERSION 1.2 LAST EDITED 05.01.2018 cleanroomdevices.com...
- Page 2 Table of Contents Title Page…………………………………………………………………………1 Table of Contents…………………………………………………………………2 1.0 General Product & Safety Information……………………………………...3 Product Information Safety Information 2.0 Installation……………………………………………………………….….3 Jaw Installation Nest Installation 3.0 Operation……………………………………………………………………5 4.0 Maintenance……………………………………………………………...…7 5.0 Product Specifications……………………………………………………..7 6.0 Durometer Scale…………………………………………………………….7 7.0 Warranty…………………………………………………………………..8 Warranty Warranty Period...
- Page 3 1.0 General Product & Safety Information Product Information The Fitting Inserter is designed to hold and locate soft tubing and push it onto fittings. The minimum/maximum outside tube diameter is 1/16” to 3/8” Safety Information This product uses a geared lever action to insert fitting into tubing. Avoid placing hands or fingers between jaws and nest.
- Page 4 Slightly squeeze jaws together and place on the 2 dowel pins extending from thrust plate. (Figure 3) Attach jaws using 2 10-24 x 1-3/8” socket head cap screws. (Figure 4) Figure 3 Figure 4 2.2 Nest Installation Select the nest set that corresponds to the fitting being used. ...
- Page 5 3.0 Operation Setting the Stop Gate The stop gate allows for repeatable insertion of the tubing onto the fitting to a desired position on that fitting. (halfway on, fully on up to shoulder, etc.) The stop gate is adjusted via the thumb wheel. (Figure 6) Figure 6 Loading Nest and Jaws ...
- Page 6 Open jaws to the semi open position by rotating cam until the flat is resting on the jaw (Figure 7) With jaws in the semi open position, insert tubing into jaws up to the stop gate and lock in position with locking lever.
- Page 7 4.0 Maintenance Wipe down outer surfaces with alcohol, septihol or mild detergents as required. Once every three months check screws for tightness. 5.0 Product Specifications Unit Weight 11 LBS / 4.99 KG Overall Dimensions 14 in. lg. x 9 in. w. x 8.5 in. ht. 6.0 Durometer Scale...
- Page 8 For additional information contact: www.cleanroomdevices.com Clean Room Devices, Inc. 10855 Dover Street, Suite 100 Westminster, CO 80021...
