----------------------------------------- 2 - 4 User interface ----------------------------------------- 5 Accessories ----------------------------------------- 6 Opening Butter y Latches ------------------------------ 7 Opening the DRN-STN ----------------------------------------- 8 System integration ----------------------------------------- 9 - 17 Cable Outlet ----------------------------------------- 15 Power on / Reset ----------------------------------------- 18 Monitor adjustment...
Page 3: Warnings
Warnings The height of the CPU cooler may be maximum 140 mm. The length of the expansion cards in position 1, 2, 3 may be maximum 425 mm. The length of the expansion cards in position 4, 5, 6, 7 may be maximum 285 mm.
Page 4 The total power consumption of the 6 Housing Fans together may be maximum 30 watt. Housing air ow Do NOT block the air inlet at the left side of the DRN-STN. Do NOT block the air outlet at the top side of the DRN-STN.
Page 5 Warnings PSU air ow The air inlet of the Power Supply Unit (PSU) must NOT face the chassis wall. The air inlet of the Power Supply Unit (PSU) must face the inside of the chassis. The air inlet of the Power Supply Unit (PSU) must be free from obstructions, to ensure proper cooling of the PSU.
Page 6: User Interface
User Interface Top Grip Left 24 inch Monitor Power Button Monitor Buttons Reset Button Bottom Grip Left 5.25 inch Bays USB3.0 USB2.0 Microphone Socket (3.5 mm) Fan Speed Switches Headphone Socket (3.5 mm) Top Grip Right Main Power In Bottom Grip Right Socket (C14) Local Area Network Socket (RJ45)
Page 7: Accessories
Accessories Inside the Accessory Box you will nd the following parts: Screw 6-32 Hex 12 x Screw M3 Fine thread ! 14 x Screw 6-32 Motherboard Mounting Stando MB Mounting Stando Tool 5.25” Device Mounting Part L 5.25” Device Mounting Part R 16 x 3.5”...
Page 8: Opening Butter Y Latches
Opening Butter y Latches To open a Butter y Latch 1) Lift the grip 2) Rotate the grip 180 degrees counter clockwise 3) Lift the latch by pulling the grip To close a Butter y Latch 4) Push down the latch. Make sure the latch overlaps the hook on the back cover ! 5) Rotate the grip 180 degrees clockwise.
Page 9: Opening The Drn-Stn
Opening the DRN-STN To open the DRN-STN Place the DRN-STN on a clean and smooth surface with its front side facing down. 1) Release the Belt Buckle (BB) 2) Open the 4 Butter y Latches (BL) 3) Lift and remove the back cover...
Page 10: System Integration
System integration Installing the motherboard 1) Please read the manual of your motherboard for the location of the motherboard mounting holes. 2) Use the Motherboard Mounting Stando Tool (T1) to screw the Motherboard Mounting Stando s (M1) accordingly to the chassis motherboard plate. 3) Place the motherboard in the chassis and mount it with screws (S3) to the Motherboard Mounting Stando s.
Page 11 System integration Installing a 3.5” device 1) Place one 3.5” Device Mounting Strip (P3) on each side of the 3.5” device. 2) Slide the 3.5” device with the mounting strips into the 3.5” mounting bracket until it snaps rmly in place. 3) Please read the manual of your motherboard / 3.5”...
Page 12 In case your motherboard only o ers one fan connector, check the motherboard manual if you can use a separate splitter to connect both Chassis Fans. Note: the fan speed of the two Chassis Fans inside the chassis can only be controlled by the motherboard (BIOS). The DRN-STN has no switches for Chassis Fan speed adjustment.
Page 13 System integration Installing add-on cards 1) Lift the handle of the add-on card clamp in the direction of the Chassis Fans (just a few millimeters is enough). 2) Rotate the handle 90 degrees upward. 3) Carefully select the slot(s) in which the add-on cards will be installed. 4) Use a at screw driver to break out the strip(s) to create openings for the add-on card(s).
Page 14 Please read the manual of your motherboard / 5.25“ device to connect the power and data cables. Guide the power and data cables through the oval-shaped holes at the bottom side of the chassis. 4) Remove the corresponding 5.25” blank shield from the front of the DRN-STN housing.
Page 15 System integration Connecting the Chassis Molex cable 1) Plug the 4 pin male connector of the Chassis Molex cable (C2) to one of the female connectors of the Power Supply Unit. 2) Plug the 4 pin female connector of the Chassis Molex cable to the Chassis PCB (CP), inside (!) the chassis. Connecting the Chassis User Interface cable 1) Plug the 10 pin connector of the Chassis User Interface cable (C3) to the Chassis PCB (CP), inside (!) the chassis.
Page 16: Cable Outlet
System integration Placing the chassis inside the housing Before you place the chassis inside the DRN-STN housing, make sure you keep all cables to the side ! This is to prevent the cables from being trapped under the chassis. Cable Outlet...
Page 17 PSU manual). Please read the manual of your motherboard/add-on cards before you connect the cables of the DRN-STN to the motherboard/add-on card(s). 4) Plug the USB2.0 connectors (H4, round cables ) to the motherboard. 5) Plug the USB3.0 connectors (H5, at cables ) to the motherboard.
Page 18 Place the back cover on the DRN-STN, and lock the 4 Butter y Latches. Connect the power cord connector (C13) to the Main Power In Socket (C14) of the DRN-STN. In case you have a wired LAN connection, connect the LAN (RJ45) connector to the...
Page 19: Power On / Reset
Power on / Reset Power on To switch on the DRN-STN, press the PWR button for 1 second. The LED’s behind all the buttons will light up to their maximum intensity for 20 seconds. After 20 seconds the light intensity will dim down to 50 % of the maximum.
Page 20: Monitor Adjustment
Monitor adjustment To adjust the monitor settings 1) Press the MENU button, the On-Screen Display (OSD) will appear. 2) Press the MENU button repeatedly to scroll through the menu and select the item you want to adjust (the selected item will be highlighted). 3) Use the Up (^) or Down ( ) buttons to adjust the value of the selected item (change settings).
Page 21: Fan Speed Adjustment
Fan speed adjustment 1) Air intake adjustment To adjust the speed of the Intake Fans (left side of the DRN-STN) slide the L switch to the required position: 3 means the fan speed is 100% 2 means the fan speed is 66% 1 means the fan speed is 38%.
Page 22: Dust Filter Removing
Dust lter removing To remove the Dust Filter 1) Switch o the PC and unplug the power cord, remove the back cover of the DRN-STN, unplug all connectors between the housing and the chassis, and remove the chassis from the housing.
Page 23: Dust Filter Placement
2) Place the 3 Metal Wires, that hold the Dust Filter, back in their original position. 3) Place the 3 Intake Fans back in their original position. 4) Mount the fans with their original 6 screws. See page 15 for placing the chassis inside the DRN-STN housing.
Page 24: Security
Slide the padlock loop from the inside through the opening in the back of the chassis, and add the screw. Kensington lock hole The chassis is equiped with a hole where a Kensington lock can be mounted. The cable of the Kensington lock can go out of the DRN-STN through the Cable Outlet at the bottom of the chassis.
Page 25: Product Specs
Product Specs Housing + Chassis Motherboard form factor: ATX, ATX Add-on cards: 7 x Full size (upper 3 slots up to 425mm long, lower 4 slots up to 285mm long) Power supply unit: ATX / PS2 (at bottom position of chassis) Bays: 8 x 3.5”...
Page 26 Product Specs Monitor Model A Brand: Optical Response Time: 5 ms (black/white, Typ., on/o ) Vertical Refresh Rate: 120 Hz LCD Type: LCD Backlight: Diagonal: 609.7 mm / 24 inch Maximum resolution: 1920 x 1080 (Full HD) Aspect ratio: 16 : 9 Colors: 16.7 Million (RGB 6-bit) Contrast ratio:...
Page 27: Warranty
The limited warranty covers only those defects that arise as a result of normal use of the DRN-STN. Defects or damages that result from improper operation, storage, misuse or abuse, accident or negligence, which are not the manufacturing defects from AIO Corporation, are excluded from warranty coverage.
Page 28 2013 © AIO Corporation AIO Technology Inc. No. 40, Tung-Long St., Tainan, Taiwan e-mail: sales@aio-group.com AIO Europe BV Kiotoweg 70E, 3047BG Rotterdam, The Netherlands Tel: +31-10-7528150 e-mail: sales@aioeurope.nl AIO China 2, 6TH Floor, NO. 603, Sanzheng Shiji Haoting Qing Hu Tou TangXia Town,...
