- Page 1 HOSCH SPRUNG BLADE SCRAPERS TYPE C1 ® Installation and Operation Manual...
-
Page 2: Range Of Application
The C1 ® can be installed on the return belt after the discharging drum or on the discharging drum of the conveyor system (see extra sheets). The C1 ® is designed for use with smooth belts and true running drums only. -
Page 3: Functional Description
Functional Description Design The HOSCH Sprung Blade Scraper Type C1 ® is a so-called main scraper. Characteristic features are the double row, overlapping and equally spaced spring-bearing cleaning modules. 1. Assembly carrier endsection 2. Assembly carrier flange 3. Assembly carrier midsection 4. - Page 4 In the case of special operating conditions (reversing operation, runback, highly damaged belt surface, vibrations, etc.), the scraper must be equipped with the corresponding accessories. Please contact HOSCH. Installation and Operation Manual Type C1 ® Page 4 of 12...
- Page 5 General Danger Notice • Before carrying out installation or maintenance work on HOSCH Sprung Blade Scrapers, ensure that the conveyor belt has been stopped and “locked-off”. Do not begin any work that has not been previously authorised by a responsible works manager and co-ordinated with all the departments involved (such as electrical engineering, safety departments, production department, operation department).
-
Page 6: Determining The Installation Position
Starting from point (PB), the center point of the assembly carrier (PC) is to be determined at the frame construc- tion using measures A and B. The measures are always to be marked parallel and vertically to the belt direc- tion. Installation and Operation Manual Type C1 ® Page 6 of 12... -
Page 7: Installation Opening
(see illustration in dimension table). The position of the mounting stirrup is to be selected in such a way that it can be fixed to stable, twist-resistant components of the supporting structure such as sectional steel beams. This document is subject to technical modifications Page 7 of 12 Installation and Operation Manual Type C1 ®... - Page 8 Assemble the modules as shown in detail "X": Insert the sprung elements in the sleeves of the assembly carrier midsection and tighten the plug. Next align all cleaning blades to a uniform, average height level. Installation and Operation Manual Type C1 ®...
- Page 9 PM = center of module slewing axle. Alternatively, you can use the measure (S - R) = 27 mm. Then tighten the spindle nuts. This document is subject to technical modifications Page 9 of 12 Installation and Operation Manual Type C1 ®...
-
Page 10: Checking The Installation
Check if the scraper works smoothly and without vibrations. Check if the loading width of the belt corresponds to the cleaning width of the scraper. Belt junctions, patches or other defects must pass the scraper without caus- ing any problems. Check system for mistracking and runback. Installation and Operation Manual Type C1 ® Page 10 of 12... -
Page 11: Maintenance And Service
The required inspection and service intervals can be coordinated with HOSCH's Service Department if requested. HOSCH service staff is available world-wide to carry out the work. Additionally, HOSCH offers its customers training seminars on the selection, installation, inspection and service of its belt conveyor cleaning systems. - Page 12 HOSCH-Fördertechnik GmbH. Contravention of the owner's copyright may also reduce the ability of HOSCH-Fördertechnik GmbH to provide effective support for its equipment. HOSCH-Fördertechnik GmbH reserves the right to make changes without notice to both this document and to its products described within this document.
