Chelino REVO Instructions For Use Manual

From 9 to 36 kg child, child car seat group i/ii/iii
Hide thumbs

Advertisement

Table of Contents

Stores: ChelinoBaby - Ormonde - JHB
ChelinoBaby - Fourways - JHB
ChelinoBaby - Menlyn - Pretoria
ChelinoBaby - Gateway- Durban
ChelinoBaby - Online - www.chelinobaby.co.za
Importer:
Anchor lnternational
Add: 12 Kimberlite Road , Theta Ext 5 Booysens
Reserve , JHB 2091 South Africa.
Tel:
+2711 835 2520
SUITABLE FROM
9 TO 36 KG Child
1.This is a "Universal" child restraint; it is approved to Regulation No.44,04 series
amendments, for general use in vehicles and it will fit most,but not all,car seats.
2.A correct fit is likely if the vehicle manufacturer has declared in the vehicle
handbook that the vehicle is capable of accepting a "Universal" child restraint for
this age group.
3.This child restraint has been classified as "Universal" under more stringent
conditions than those which applied to earlier designs which do not carry this
notice.
4.If in doubt, consult either the child restraint manufacturer or the retailer.
Only suitable if the approved vehicles are fitted with 3-pointsafety-belts,
approved to UN/ECE Regulation No.16 or other equivalent standards.
Do not use in passenger seats equipped with airbags(SRS).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REVO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chelino REVO

Summary of Contents for Chelino REVO

  • Page 1 SUITABLE FROM 9 TO 36 KG Child Stores: ChelinoBaby - Ormonde - JHB ChelinoBaby - Fourways - JHB ChelinoBaby - Menlyn - Pretoria ChelinoBaby - Gateway- Durban ChelinoBaby - Online - www.chelinobaby.co.za 1.This is a “Universal” child restraint; it is approved to Regulation No.44,04 series amendments, for general use in vehicles and it will fit most,but not all,car seats.

  • Page 2: Safety Warnings

    SAFETY WARNINGS NOTES Please read this user guide carefully before install the child seat and for future reference. DO NOT USE THIS CHILD SEAT IN PASSENGER SEATS EQUIPPED WITH AIRBAGS. • This child seat can be used with the harness for children of 9 to 18kg in weight (group I). •...

  • Page 3: Vehicle Application

    Vehicle application Features This child seat is suitable for conventional use in all cars equipped with 3-point seat belts that are fitted in accordance with European standard (ECE44 or equivalent standard) Important: This child seat must only be installed using a lap and diagonal seat belt. Forward facing on the rear seat .
  • Page 4 USAGE FOR THE AGE GROUP I Use of the harness system is only permitted for children of age group I ,which means If the height of your shoulder belts in child car seat is not fit for your child, adjust from 9kg to 18kg.
  • Page 5 Securing the child car seat(group I ） Step4.Press your knee on the child car seat and pull Step1.Place the child safety seat on the vehicle’s seat the diagonal belt along the direction as the picture which is fitted with 3-point safety belts, ensuring it is shows.
  • Page 6 Step1. The shoulder straps are slackened by pressing the lever (under the car seat cover) Step1.Put the two metal sections of the buckle on the front of the car seat. connectors together. Step2.Press down on the label marked“Press” as you grip the two should straps with your other hand.

  • Page 7: Removal Of The Harness

    USAGE FOR THE AGE GROUP II /III Install and adjust the belt lock system The harness system must be removed from the seat when used for these age group II,III, which means from 15kg to 36kg. Only the 3-point vehicle belt system can be used to buckle up the child car seat.
  • Page 8 Securing the child car seat with vehicle’s belt with belt lock for group II from 3 to 7years (15-25kg) IMPORTANT: Before fitting the seat, remove the shoulder straps, crotch strap and then The car seat must be used vehicle’s 3-point belt system for children of the age groups II fit the seat belt lock only in upper 2 row slots as shown.
  • Page 9 Securing the child car seat with vechile’s belt with belt lock for group III from 7 to 11 years (22-36kg) Step1. Place the child safety seat on the vehicle’s seat ensuring it is firmly pressed IMPORTANT: Before fitting the seat, remove the shoulder straps, crotch strap and against the car seat’s backrest.

  • Page 10: Care Instructions

    CARE INSTRUCTIONS Cleaning the car seat and cover The seat cover, harness and plastic parts can be washed with very mild detergent and Warm water. Do not use chemical cleansers, bleach or corrosives to wash any part of the car seat. Do not wash by machine,Spin-dry are not recommended.
