Parts List for Product #100 – 4 Seat Round Patio Table
(1) Table top
(4) Curved seats
(2) Legs
(10) 7 inch x 3/8" bolts
(10) 3/8" nuts
(40) 1 and ½ inch fender washers (THIN)
(40) 1 and ½ inch fender washers (THIN)
(20) Rubber washers
(20) 1 ¼ inch x 3/8" bolts
(1) Table bracket
(8) Seat brackets
Tools Required:
(2) people
(1) Pallet jack
(1) 2 wheeled hand cart
(1) 9/16 wrench
(1) 9/16 ratchet wrench
(1) portable drill with 9/15 socket
(1) Work gloves
(1) Broom handle
**** Highly recommended to apply a fresh coat of sealer,
40" diameter x 2 ¼" thick -- 255 pounds
40" x 10 ¼" x 2" thick --80 pounds each
60" x 28 ¼"H x 6" thick -- 300 pounds
each
For use on seats and top
For use on metal brackets
Approximately 1 hour per table
Optional
Minimum weight capacity of 300 pounds
Optional
Optional
before each winter. ****
Advertisement
Summary of Contents for DOMINION PRECAST 100
- Page 1 Parts List for Product #100 – 4 Seat Round Patio Table (1) Table top 40” diameter x 2 ¼” thick -- 255 pounds (4) Curved seats 40” x 10 ¼” x 2” thick --80 pounds each (2) Legs 60” x 28 ¼”H x 6” thick -- 300 pounds each (10) 7 inch x 3/8”...
- Page 2 (Bumping pieces together will cause chips and cracks.) Step First, determine the area where your table(s) are going to be installed. Each table is 67 inches in diameter. We recommend that you place tables no closer than 100 inches on center. Step Using a two wheeled moving dolly, move the bottom leg (leg with a rectangle notch on the top) into position.
