- Page 1 Line Burner L - Automatic INSTALLATION AND OPERATION GUIDE Before operating Bionova burner please read and follow instructions...
- Page 2 ENGLISH Conditions of Use The BIONOVA Line Burner L – automatic bioethanol fireplace burner is designed and produced accorded to new DIN 4734-1 standard. Dangerous goods Bioethanol fuel is classified as a flammable liquid Class 3, PG II and is regulated by various standards.
- Page 3 ENGLISH Contents Conditions of use …………………………………………………… Warnings …………………………………………………… Standard equipment received …………………………………………………… Installation …………………………………………………… Connecting, ventilation …………………………………………………… Ventilation, thermal efficiency, …………………………………………………… burning time How to operate BIONOVA burner …………………………………………………… Maintenance …………………………………………………… Warranty …………………………………………………… Burner data …………………………………………………… Technology …………………………………………………… How to install the IoT environment ……………………………………………………...
- Page 4 ENGLISH Conditions of Use NOVA VIZANTIJA is safety conscious company. We have taken a great care in designing, manufacturing and assembling your BIONOVA burner to be sure that it operates safely, efficiently and visually effectively. To insure that you can enjoy our product for a long time, in comfort, please operate the product with care and follow these instructions: 1.
- Page 5 ENGLISH Warnings Please honor following warnings: 1. Risk of explosion: a) NEVER use any other fuel then specified for use with bioethanol fireplaces ; b) NEVER fill the fuel when burner operating or still hot ; c) NEVER fill the fuel in burner reservoir in areas where flammable vapors or gas may be present ;...
- Page 6 12. Do not try to start BIONOVA burner if you suspect fault or any damage to the housing or mechanism of the burner. 13. The NOVA VIZANTIJA Company does not accept any responsibility for any damage or injury which accrues if the BIONOVA burner is used for purposes other than intended;...
- Page 7 ENGLISH Standard Equipment Received The BIONOVA burner is supplied with following standard equipment: 1. BIONOVA Line Burner L Automatic - 1pc. 2. Installation and operation guide - 1pc. 3. Electronic control unit - 1pc. 4. Remote control - 1pc. Line Burner L Automatic – Installation and Operation Guide...
- Page 8 ENGLISH Installation Please find following installation instructions: BIONOVA burner is primarily intended for indoor use. For outdoor use please contact manufacturer or sales personal for specific terms of services. There are many different variations available for installing BIONOVA burner but in every case BIONOVA burner must: Be installed in non-combustible material only (stainless steel, concrete, brick, stone) ;...
- Page 9 ENGLISH Installation Plate on which burner is positioned must be rigid enough to withstand load of at least 20 Kg. Be installed in fixed, leveled and secure position before filling, lighting and operating ; Be installed in position that limits relocation – it is not suitable for frequent relocation ;...
- Page 10 ENGLISH Installation Please find required installation dimensions: Line Burner L Automatic – Installation and Operation Guide...
- Page 11 ENGLISH Installation Connecting, ventilation Connecting: BIONOVA Line burner L must be connected to the 220V/230V grounded power supply. How to connect: 1. Connect cables (1) and (2) from electronic driver unit to burner terminals (1) and (2) 2. Connect power cable (3) from electronic driver unit to the grounded power supply (220V/230V).
- Page 12 ENGLISH Ventilation, thermal efficiency, burning time Minimum room volume Air exchange (1/h) Explanation Air exchange due to 280m leakage in the building Normal air exchange 140m rate in the leak proof buildings Complete air exchange in installation room during one hour Air exchange *(n/h) Comments 0 –...
- Page 13 ENGLISH How to operate BIONOVA burner It is important to follow the procedure described to ensure that you are operating and using BIONOVA burner safely: Only fuel to be used in BIONOVA burner is bioethanol fuel – no other fuel is allowed.
- Page 14 ENGLISH How to operate BIONOVA burner Filling the burner: Before filling the burner with bioethanol fuel please insure following: 1. That the burner is standing in leveled position fixed from moving and properly installed ; 2. That the burner is not hot from previous use ; 3.
- Page 15 ENGLISH How to operate BIONOVA burner Igniting BIONOVA burner: Keep your hands and face away from BIONOVA burner at all-time especially when igniting. Before igniting, make sure that the burner is clear and ready for use. 1. Put slider in full open position, to have enough ventilation for ignition, by pressing push button (A) on a remote control.
- Page 16 ENGLISH How to operate BIONOVA burner Turing BIONOVA burner off and restarting: 1. If fuel in the burner tank is not entirely used up it can be used again. In order to supply more fuel, please wait until burner cools down to room temperature and then, only then, it is safe to fill burner tank ;...
- Page 17 ENGLISH Maintenance Maintenance: Should be performed when BIONOVA burner is off, completely empty of fuel, dry and at a room temperature. The surface of the burner will change color on very hot spots over time. This is normal “hot stainless steel” ageing process. 1.
- Page 18 ENGLISH Warranty Warranty terms: 1. Your BIONOVA burner is covered by 2 years warranty from moment of purchase. 2. Please note - in order to warranty be applied, instructions for installing, use and maintenance must be followed. 3. Do not try to fix burner by yourself or by unprofessional service and persons –...
- Page 19 ENGLISH Burner data Burner data and dimensions: Main Stainless material: Steel ( 1.4301) Evaporator: Ceramic fibers Tank Size: 2,95 l Weight : 1 kg Thermal Up to 3 Kw * output : Req. room volume: Burning Continuously Time: Up to 6 h * * The efficiency data has approximate value depending on the model purchased, weather...
- Page 20 ENGLISH Technology EECT – Evaporated Ethanol Combustion Technology BIONOVA bioethanol fireplace burners are bringing to you unique technology of ethanol combustion - EECT. Our burner’s combusting only ethanol vapors distributed from ceramic evaporator (no loose fuel) trough burning pit calibrated grill providing precise and odorless process of burning.
- Page 21 Note: A NOVA VIZANTIJA COMPANY shall not be responsible for any damage caused by the management of BIONOVA burners by unauthorized persons who have come into possession of a QR code or in a manner not covered by the recommendations on the safe use.
- Page 22 ENGLISH How to install the IoT environment properly How to connect to the Internet via WiFi: In order to be able to function, your BIONOVA burner must be connected via a WiFi network, providing an access point with the following parameters: SSID BioNova burner Password...
- Page 23 ENGLISH How to install the IoT environment properly 2. Start the installed application. From the Home screen, select the QR code reading option: 3. Read the QR code that you received from the BIONOVA info system on your secure e-mail address. 4.
- Page 24 Nova Vizantija ▪ Svetogorska 12 ▪ Belgrade ▪ Serbia T/F: +381 11 406 43 78 ▪ E: info@bionova.com www.bionova.com...
