Akse Electrex FEMTO D4 70A PFA6431-02 Installation Manual

FEMTO D4 70A
INSTALLATION MANUAL
COPYRIGHT
Akse S.r.l. Electrex is a trademark of Akse S.r.l. All rights reserved.
It is forbidden to duplicate, adapt, transcript this document without Akse written
authorization, except when regulated accordingly by the Copyright Laws.
WARRANTY
This product is covered by a warranty against material and manufacturing defects
for a period of 24 months period from the manufacturing date.
The warranty does not cover the defects that are due to:
• Negligent and improper use
• Failures caused by atmospheric hazards
• Acts of vandalism
• Wear out of materials
• Firmware upgrades
Akse reserves the right, at its discretion, to repair or substitute the faulty products
The warranty is not applicable to the products that will result defective in consequence
of a negligent and improper use or an operating procedure not contemplated in this
manual.
RETURN AND REPAIR FORMALITIES
Akse accepts the return of instruments for repair only when authorized in advance.
The transport costs are at customer charge.
RE-SHIPPING OF REPAIRED PRODUCT
The terms for re-shipment of repaired products are ex-works, i.e. the transport costs
are at customer charge.
Products returned as detective but found to be perfectly working by our laboratories,
will be charged a fl at fee to account for checking and testing time irrespective of the
warranty terms.
SAFETY
This instrument was manufactured and tested in compliance with IEC 61010 class 2
standards for operating voltages up to 250 VAC rms phase to neutral.
In order to maintain this condition and to ensure safe operation, the user must
comply with the indications and markings contained in the following instructions:
• When the instrument is received, before starting its installation, check that
it is intact and no damage occurred during transport.
• Before mounting, ensure that the instrument operating voltages and the
mains voltage are compatible then proceed with the installation.
• The instrument power supply needs no earth connection.
• The instrument is not equipped with a power supply fuse; a suitable external
!
protection fuse must be foreseen by the contractor.
• Maintenance and/or repair must be carried out only by qualifi ed, authorized
personnel
• If there is ever the suspicion that safe operation is no longer possible, the
instrument must be taken out of service and precautions taken againstits
accidental use.
• Operation is no longer safe when:
1) There is clearly visible damage.
2) The instrument no longer functions.
3) After lengthy storage in unfavorable conditions.
4) After serious damage occurred during transport
The instruments must be installed in respect of all the local regulations.
OPERATOR SAFETY
Warning: Failure to observe the following instructions may lead to a serious danger
of death.
• During normal operation dangerous voltages can occur on instrument terminals
and on voltage and current transformers. Energized voltage and current
transformers may generate lethal voltages. Follow carefully the standard safety
precautions while carrying out any installation or service operation.
• The terminals of the instrument must not be accessible by the user after the
installation. The user should only be allowed to access the instrument front
panel where the display is located.
• Do not use the digital outputs for protection functions nor for power limitation
functions. The instrument is suitable only for secondary protection functions.
• The instrument must be protected by a breaking device capable of interrupting
both the power supply and the measurement terminals. It must be easily
reachable by the operator and well identifi ed as instrument cut-off device.
• The instrument and its connections must be carefully protected against short-
circuit.
Precautions: Failure to respect the following instructions may irreversibly damage
to the instrument.
• The instrument is equipped with PTC current limiting device but a suitable
external protection fuse should be foreseen by the contractor.
• The outputs and the options operate at low voltage level; they cannot be
powered by any unspecifi ed external voltage.
• The application of currents not compatible with the current inputs levels will
damage to the instrument. supply with extended operating range. The power
supply terminals are numbered (10) and (11). Use cables with max cross-
section of 4 mm2.
akse srl Via Aldo Moro, 39 42100 Reggio Emilia Italy
Tel. +39 0522 924 244 Fax +39 0522 924 245 info@akse.it www.akse.it
VAT IT 01544980350 R.E.A. 194296 Cap. Soc. Euro 85.800,00 i.v.
VIEWS
TABLE LIST MEASURES MAIN SCREEN
(The measures available vary according to confi guration)
EA ER ES V
Ea Imp Er Ind Es Imp L-N
Imp
Ea Exp Er Cap Es Exp L-L
Imp
Ea x Er Ind THD
Fase Exp L-N
Er Cap THD
Exp L-L
Er Ind x Min L-N Min L-N
Fase
Min L-L Max L-N
Max
L-N
Max
L-L
TABLE BELOW LISTS MEASURES WALLPAPERS
(The measures available vary according to confi guration)
Press to measure change
Ea ∑+ Er L ∑+
Ea ∑- Er L ∑-
Ea P+ Er L P+
Ea P- Er L P-
CNT1 ∑ CNT2 ∑
CNT1 P CNT2 P
TIME ∑ TIME P
TEMP °C TEMP °F
LEGEND MEASURES
L-N Reference Phase Neutral
L-L Reference Phase Phase
THD Total Harmonic Distortion
Avg Average value
MD Peak Value
Imp (+) Value imported
Exp (-) Export Value
IND Inductive
CAP Capacitive
Min Minimum Values (Time base 10 Cycles) Es
Max Maximum values (Time base 10 Cycles) f
TIME ∑ Life Time (total)
TIME P Life Time (partial)
CNT ∑ Counting pulses (total)
CNT P Counting pulses (partial)
* Temperature inside the microprocessor
MECHANICAL CHARACTERISTICS
Enclosure Self-extinguishing plastic material class V0
Protection degree: IP40 on the front panel
Dimensions: 70 x 90 x 58 mm (4 modules DIN)
VOLTAGE INPUT
Direct: Up to 300 Vrms phase-neutral
or 519 Vrms phase-phase
Overload: 900 Vrms phase-phase for 1 sec
Power Supply: 230/240Vac +/- 10% 50/60Hz
Self consumption: < 3VA
MODELS
PFA6431-02 FEMTO D4 RS485 230-240V 70A
ENERGY ANALYSER
PFA6431-12 FEMTO D4 RS485 230-240V 70A 1DI 2DO
ENERGY ANALYSER
PFTE000-00 TA external 70A for FEMTO D4
A TA already included with the instrument
*Order additional 2 TA for the three-phase
Further documentation may be downloaded from our web site www.electrex.it.
This document is owned by the company AKSE that it reserves all rights.
DECLARATION OF CONFORMITY
Akse hereby declares that its range of products complies with the following directives
EMC 89/336/EEC 73/23CE 93/68 CE and complies with the following product's
standard CEI EN 61326 – IEC 61326
The product has been tested in the typical wiring confi guration and with peripherals
conforming to the EMC directive and the LV directive.
Subject to modifi cation without notice. Edition 9 November 2007.
V I P Q S
L-N I P Q S
f
L-L In P Avg Q Avg S Avg
f Imp Imp Imp
THD L-N THD P Avg Q Avg S Avg
f Exp Exp Exp
THD L-L I Max P MD Q MD S MD
f Imp Imp Imp
I Avg P MD Q MD S MD
f Exp Exp Exp
I MD
f
Min L-N
f
Max L-L
f
Er C ∑+ Es ∑+
Er C ∑- Es ∑-
Er C P+ Es P+
Er C P- Es P-
CNT3 ∑ CNT4 ∑
CNT3 P CNT4 P
V Voltage
I Current
In Current neutral
P Active Power
Q Reactive Power
S Apparent Power
PF Power Factor
Ea Enable Energy
Er Reactive Energy
Apparent Energy
Frequency
TEMP °C Temperature in Celsius (*)
TEMP °F Temperature in Fahrenheit (*)
CEI EN 61010 – IEC 1010.
PF
PF
