Summary of Contents for Homedoor.uk Standard Barlock
- Page 1 Fitting and operating instructions The Standard Barlock by Homedoor.uk ® For 800mm, 850mm, 880mm, 900mm, 950mm and custom made versions March 2020 www.homedoor.uk...
- Page 2 II. General information III. Field of application of the Barlock , including special accessories ® IV. Fitting tools V. Fitting instructions for doors that open inwards VI. Operating instructions VII. Useful information and solutions www.homedoor.uk...
-
Page 3: Package Contents
I. Package contents 1pc Standard Barlock ® 1pc ABUS D10 PS lock cylinder with set of 5 unique keys 2 sets of locking case / strike plates matching your door type 1 pair of protection shields ... -
Page 4: General Information
The supplier/manufacturer disclaims all liability for any injury or damage caused during fitting and/or by improper handling! We recommend allowing a trained specialist installer to execute the fitting if you are not confident how to install the Barlock ® www.homedoor.uk... - Page 5 The second one is then fitted above the door handle (Page 8 - Fig. 4). The closing direction can be adjusted accordingly to set the gear-tracks position (Page 12). For more information and advice please contact us on our website www.homedoor.uk or email to info@homedoor.uk www.homedoor.uk...
-
Page 6: Fitting Tools
Ø 16,0 mm, for a wall locking plates Milling cutter/hole saw: Ø 38mm Spanners (size 8-13mm) Metal saw and file Fittings for additional work are not included in this standard contents (screws, wall plugs, special accessories or replacement lock cylinder) www.homedoor.uk... - Page 7 Please complete the fittings as described below. (Do not skip steps or instructions). The Barlock ® can be used for one/two-turn locking, the key removal position must be set before fitting the ABUS cylinder inside the Barlock body. ® (Chapter V - Page 10 - Step 3) www.homedoor.uk...
- Page 8 (Fig. 3 or 4). Mark a hole (Ø 38mm) in the middle of the door accordingly Fig. 5 (check correct diameter of hole saw) and drill with a milling cutter/hole saw from both sides. www.homedoor.uk...
- Page 9 Please note, there are additional pre-drilled holes on both sides of the Barlock body. ® These are optional fittings only, recommended to use if you would like to increase the safety level. Otherwise cover with the supplied white covers. www.homedoor.uk...
- Page 10 Make sure the ® locking bars in the unlocked position are at least 10mm from the door panel on both sides. If necessary remove lock cylinder and adjust the position of the bars. www.homedoor.uk...
- Page 11 These should be secured with the mounting bolts from the outside of the door, with the nuts on the inside. Tighten all the screws. Caution! Do not over-wind Test locking and unlocking operation of the Barlock® . www.homedoor.uk...
- Page 12 PS88 is suitable for the lock cylinder, this product is available to order from our web shop. If you have any problem or difficulty fitting or using our product, please do not hesitate to contact us. For more information and advice please contact us on our website www.homedoor.uk email to info@homedoor.uk www.homedoor.uk...
- Page 13 When hinge thickness is above 14 mm, use locking plate/case with screw-on plate and, if necessary, plastic/wooden under-lays. Avoid a collision between the lock body and the lock case on the hinge side, install a separate door stopper if possible. www.homedoor.uk...
- Page 14 Fitting solutions with under lays: www.homedoor.uk...
