fos4Strain patch
fos4Strain patch
(2m, 1553nm, E-2000
(2m, 1553nm, E-2000
green)
green)
SEN1374
SEN1374
Follow these instructions for safe and proper use. Keep instructions for future use.
Follow these instructions for safe and proper use. Keep instructions for future use.
INSTRUCTIONS FOR USE
INSTRUCTIONS FOR USE
Product Type
Product Type
Product Version
Product Version
Document Version
Document Version
Issue Date
Issue Date
Language
Language
Sensor
Sensor
1.2.x
1.2.x
2.1
2.1
2020-02-24
2020-02-24
en-us
en-us
Advertisement
Table of Contents
Related Manuals for fos4X fos4Strain patch
Summary of Contents for fos4X fos4Strain patch
- Page 1 INSTRUCTIONS FOR USE INSTRUCTIONS FOR USE fos4Strain patch fos4Strain patch Product Type Product Type Sensor Sensor Product Version Product Version 1.2.x 1.2.x (2m, 1553nm, E-2000 (2m, 1553nm, E-2000 Document Version Document Version green) green) Issue Date Issue Date 2020-02-24 2020-02-24...
- Page 2 Brand names and protected trademarks are the property of their respective owners. The naming of brand names and protected trademarks has only descriptive character. Named trademarks are not part of any partnership or cooperation with fos4X. SEN1374_4-10_1.2.x_2.1_fos4Strain 2 / 35 ©...
-
Page 3: Table Of Contents
Function....................... 11 3.1.2 Overview......................11 3.1.3 Operation....................12 3.1.4 Calculation of strain................13 3.2 Technical Data.......................13 3.2.1 Sensor Data....................13 3.2.2 Optical Data....................14 3.2.3 Cable Data....................14 3.2.4 Mechanical Data..................14 SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 3 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... - Page 4 Commissioning and Operation............... 29 Troubleshooting....................30 Maintenance....................... 31 8.1 Preventive Maintenance..................31 8.2 Corrective Maintenance..................31 8.2.1 Cleaning E-2000/APC Connections..........31 8.3 fos4X Support.......................32 Taking out of Service and Disposal............... 33 9.1 Taking out of Service..................33 9.2 Disassembly......................34 9.3 Disposal........................34 SEN1374_4-10_1.2.x_2.1_fos4Strain 4 / 35 ©...
-
Page 5: About This Document
The safety notes with the signal words Caution and Notice have the following meanings: CAUTION Risk which, if not avoided, could result in minor injury. NOTICE Risk which, if not avoided, will result in damage to property. SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 5 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 6: Non-Safety-Related Information
5 Bold Text Highlighting of particularly important information Abbreviations Glass-fibre reinforced plastic GTIN Global Trade Item Number International Protection Maximum Minimum OECD Opto-Electronic Converter Device Single Mode Fiber SEN1374_4-10_1.2.x_2.1_fos4Strain 6 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 7: Safety
2. Safety 2 Safety Changes to the Product Changes to the product may only be carried out by fos4X. 2.2 Qualification of Personnel Definitions Instructed personnel: Personnel instructed in the tasks assigned to them. Trained personnel: Personnel trained in the operation and safe use of the product. -
Page 8: Intended Use
2. Safety 2.3 Intended Use The fos4Strain patch is a fiber-optical strain sensor based on a fiber Bragg grating. The sensor is designed for strain monitoring of various structures, for example GRP, metal and concrete. Any use other than described in these operating instructions is considered improper use. -
Page 9: Adhesives
For all tasks where surfaces are heated: Wear protective gloves with the following characteristics: – General requirements according to DIN EN 420 – Protection against contact heat: Performance level 2 according to DIN EN 407 SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 9 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... - Page 10 Wear respiratory protection with protection level A2 P2 according to DIN EN 140. For all tasks with ergo. 1665: In case of insufficient ventilation: Wear respiratory protection with protection level A P2 according to DIN EN 140. SEN1374_4-10_1.2.x_2.1_fos4Strain 10 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us...
-
Page 11: Product Description
Functional Description 3.1.1 Function The fos4Strain patch is a fiber-optical strain sensor based on a fiber Bragg grating. The sensor is designed for strain monitoring of various structures, for example GRP, metal and concrete. The sensor is suitable for measurements under difficult conditions as the functional principle makes the sensor immune to electromagnetic interference and lightning. -
Page 12: Operation
The sensor is connected to a compatible measuring device. The wavelength of the sensor can then be used to determine the strain of the structure. See Calculation of strain, page 13. SEN1374_4-10_1.2.x_2.1_fos4Strain 12 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 13: Calculation Of Strain
Blackbird OECD, nSens fos4X Required channels 0.79 ±0.05 k-factor ±3000 Measuring range µm/m Required optical measuring range 1557 … 1549 Length of the measuring range ±4000 Max. non-destructive strain µm/m SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 13 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 14: Optical Data
°C Min. Bending radius Cable exchangeable Connector type E-2000/APC 1 Length from sensor end to connector. 3.2.4 Mechanical Data Table 6: Mechanical Data Property Value Unit Length Height Width SEN1374_4-10_1.2.x_2.1_fos4Strain 14 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 15: Environmental Conditions
3. Product Description Property Value Unit Total weight 0.01 * fos4Strain patch without cable and packaging Table 7: Sensor step protection Property Value Unit Lexan 3414R 40% GF Step protection material Black Step protection * Step protection for the sensor... -
Page 16: Dimensions
(Non-condensing) 5 … 90 (Operation) * The specified protection class only applies if the cable connections have the same or a higher protection class. 3.2.6 Dimensions Figure 4: Dimensions SEN1374_4-10_1.2.x_2.1_fos4Strain 16 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 17: Markings On The Product
Contents of the type plate (example data from graphic): Symbol of the sensor type Product category and number: ABC1234 Serial number: 1234-5678 Product version: v1.2.3 QR-code of the serial number Product name: fos4Strain patch SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 17 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 18: Packaging And Transport
Open the packaging. Take the fos4Strain patch out of the packaging. Check the scope of delivery. See Scope of Delivery, page 18. If parts of the scope of delivery are missing: Contact fos4X Support. See fos4X Support, page 32. 4.3 Packing... -
Page 19: Transport
Transporting the fos4Strain patch: Handle the fos4Strain patch with care during transport. Observe the transport conditions. See Environmental Conditions, page 15. Pack the fos4Strain patch in a transport packaging. See Packing, page 18. 4.5 Storage Storing the fos4Strain patch: Store the fos4Strain patch in a dry and clean place. -
Page 20: Installation
Observe the safety data sheet of the adhesive. CAUTION Health damage and allergic reactions caused by inhalation of adhesive fumes. Do not inhale fumes. Ensure adequate ventilation. Observe the safety data sheet of the adhesive. SEN1374_4-10_1.2.x_2.1_fos4Strain 20 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 21: Preparing The Installation Position
DIN EN 140. Ensure adequate ventilation. Material and equipment Table 10: Material and equipment Name Type Quantity Cleaning cloth Dry, lint-free Angle grinder Grinding wheel for angle Grit 80 grinder SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 21 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... - Page 22 Remove the peel-ply. Continue with step 7.. Preparing the installation position with the angle grinder: Grind a surface of min. 87 x 22 mm with a grinding disk (grit 80). fos4X recommends: Grind for 2 minutes. Ensure that the surface is even.
-
Page 23: Attaching The Sensor
Helix-mixer, B-System / 4:1 & 10:1 / 50ml 4472105 Mixing gun Manual mixing gun / 10:1 / 50ml Caulking gun Adhesive tape Kapton As required Optional: MSY0961 Measuring Case (dyn4) Measuring Case SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 23 / 35 patch_(2m, 1553nm, E-2000 green)-en-us... - Page 24 Press adhesive with the mixing gun into a suitable container until the mixing tube has been flushed once. Clean the underside of the sensor with a dry, lint-free cleaning cloth and isopropanol. Wait 3 minutes for the isopropanol to evaporate completely. SEN1374_4-10_1.2.x_2.1_fos4Strain 24 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us...
- Page 25 Moisture reduces the long-term stability of the adhesive. Protect ergo. 1665 from moisture. 15. Seal the edge of the sensor with ergo 6305 or Sikaflex-521UV to protect the adhesive ergo. 1665 from humidity. Sensor is attached. SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020 25 / 35 patch_(2m, 1553nm, E-2000 green)-en-us...
-
Page 26: Attaching The Cable
Cleaning cloth Dry, lint-free Caulking gun Adhesive tape Kapton As required Consumables Table 15: Consumables Name Type Quantity 300 ml per Adhesive ergo.® 6305 or Sikaflex-521UV 8 m cable SEN1374_4-10_1.2.x_2.1_fos4Strain 26 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us... -
Page 27: Connecting E-2000/Apc Connections
Remove the Kapton adhesive tape. Cable attached. 5.5 Connecting E-2000/APC Connections The assignment of channels and sensors depends on the application of the fos4Strain patch. If available: Observe the color coding of the sensors and channels. SEN1374_4-10_1.2.x_2.1_fos4Strain © fos4X 2020... - Page 28 Connect the connector (2) to the socket (4). The connector (2) snaps into the socket (4) with a clicking sound. The sensor is connected. Repeat the procedure for all connections. SEN1374_4-10_1.2.x_2.1_fos4Strain 28 / 35 © fos4X 2020 patch_(2m, 1553nm, E-2000 green)-en-us...
-
Page 29: Commissioning And Operation
Enter the serial number of the sensor into the system via the web-interface. See manual of the web-interface. Operation In normal operation of the fos4Strain patch no operating actions are necessary. Monitor the operation status with the measuring device. See instructions for use of the measuring device. -
Page 30: Troubleshooting
Observe the safety instructions. See Safety, page 7. Tasks that are not described in these operating instructions may only be done by fos4X. If the described options do not help to fix the problem: Contact fos4X Support. See fos4X Support, page 32. Troubleshooting Table 17: Troubleshooting Problem... -
Page 31: Maintenance
Tasks that are not described in these operating instructions may only be done by fos4X. 8.1 Preventive Maintenance The product fos4Strain patch does not require preventive maintenance. 8.2 Corrective Maintenance 8.2.1 Cleaning E-2000/APC Connections Figure 8: E-2000/APC connector and socket... -
Page 32: Fos4X Support
Answers will be sent within one working day. +49 89 999542-02 Phone Monday-Friday 9:00-17:00 CET. The support of fos4X is available in German and English. Please include the following information in your support request: Product name Product type Serial number Nature of the problem SEN1374_4-10_1.2.x_2.1_fos4Strain... -
Page 33: Taking Out Of Service And Disposal
Attach a dust cap (5) on the socket (4). The fos4Strain patch is permanently bonded to the substrate and cannot be removed. Attach or cut off the cable of the fos4Strain patch. If the cable is cut off: Remove the cable from the substrate. -
Page 34: Disassembly
9. Taking out of Service and Disposal 9.2 Disassembly The product may only be disassembled by fos4X or a specialized disposal company. 9.3 Disposal NOTICE Risk to the environment due to incorrect disposal of the product. Improper disposal of the product may cause damage to the environment.
