- Page 1 WATER TRAILER MWT-0510-2MHD OPERATOR'S MANUAL CAUTION RISK OF INJURY! READ ENTIRE MANUAL BEFORE OPERATING! THIS MANUAL IS AN IMPORTANT PART OF THE WATER TRAILER AND MUST REMAIN WITH THIS UNIT! ©Copyright 2010, Mi-T-M Corporation® Water Trailer Manual 37-1103-091218...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ......................3 WARNING ........................4 PREPARATION ........................5 BEFORE TOWING WATER TRAILER ................5 SAFETY PRECAUTIONS DURING USE ..............5 OPERATING INSTRUCTIONS ..................6 WATER FLOW ......................6 FILLING THE TANK .....................7 AFTER USE .........................7 OPERATING INSTRUCTIONS FOR THE HARD SUCTION OPTION ......8 OPTION - HARD SUCTION ..................8 WATER FLOW: ......................8 FILLING THE TANK: ....................10... -
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your new Mi-T-M® Water Trailer! You can be assured your Mi-T-M® Water Trailer was constructed with the highest level of precision and accuracy. Each component has been rigorously tested by technicians to ensure the quality, endurance and performance of this Water Trailer. -
Page 4: Warning
WARNING THE FOLLOWING PAGES CONTAIN OPERATING INSTRUCTIONS. DO NOT ATTEMPT TO TOW YOUR WATER TRAILER UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MANNER! Water Trailer Manual... -
Page 5: Preparation
PREPARATION BEFORE TOWING WATER TRAILER WARNING: DO NOT OPERATE TRAILER UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD. 1. Thoroughly read and understand all instructions before operating this trailer. 2. Make sure that the trailer is properly attached to the tow vehicle, including lights, safety chains, hitch and breakaway brake cable. -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS WATER FLOW The Mi-T-M Water Trailer features an easy to use discharge manifold that allows the operator three methods of controlling water flow. Water can be discharged through the spray nozzle valve (A), fire hose valve (B), or garden hose valve (C). -
Page 7: Filling The Tank
OPERATING INSTRUCTIONS FILLING THE TANK To fill the tank through the anti-siphon fill (G) (figure 5), remove the tank lid (figure 6), couple the fill hose (D) (figure 3) to the anti-siphon coupler and the other end of the hose to a fire hydrant. Open the water source and begin filling. -
Page 8: Operating Instructions For The Hard Suction Option
WATER FLOW: The Hard Suction Option for the Mi-T-M Water Trailer features an easy to use discharge Manifold that allows for four methods of controlling water flow (figure 8), and an easy to use inlet manifold allowing for two meth- ods of supplying water (figure 9). - Page 9 OPERATING INSTRUCTIONS FOR THE HARD SUCTION OPTION Refer to the pump manual for instructions on pump operation. Turning the corresponding valve to the open or closed position will allow the flow of water through each valve. When using the Spray Bar, open valve (M) with valves (K), (L) and (N) closed (figure 10). To use the fire hose, quick couple the fire hose (E) (figure 3) to valve (K), open valve (K) with valves (L), (M) and (N) closed (figure 11).
-
Page 10: Filling The Tank
OPERATING INSTRUCTIONS FOR THE HARD SUCTION OPTION Figure 14 Figure 15 FILLING THE TANK: To fill the tank through the anti-siphon (G) (figure 5), follow the instructions above in the trailer manual. To fill the tank using an external body of water, attach the strainer (P) to the hard suction hose (O) (figure 14), attach hose (O) to valve (I), put the strainer (P) into the body of water, open valve (I) with valve (J) closed (figure 15) and open valve (L) with valves (K), (M) and (N) closed (figure 16). - Page 11 EFFECTIVE DATE: MAY 1, 2010 LIMITED WARRANTY The Mi-T-M Corporation will repair or replace any part or parts of the water trailer manufactured by Mi-T-M Corporation that are found to be defective in material or workmanship or both, under normal use and main- tenance, free of charge for the period specified below.
- Page 12 Manufactured by Mi-T-M 50 Mi-T-M Drive, Peosta IA 52068 563-556-7484/ Fax 563-556-1235 Water Trailer Manual...
