Police Law-enforcement Video and Audio Recorder
Thanks for choosing our Police Law-enforcement Video and Audio Recorder—EH05,
Hope we can help you in your work of law enforcement.
Product Overview
Police law-enforcement video and audio recorder developed by us have many
process technologies such as GPS, video and audio record, Integrate function, stable
quality. It can help you collect evidence, standardize law-enforcing conduct, playback
the picture of scene and assure the accuracy and fairness of law enforcement.
Product Features
Item
Max Pixel
Video Resolution
Display Screen
EH05 Manual
Shenzhen Eeyelog Technology Co.,Ltd
Foreword
Parameter
Over 21 Mega Pixels
2304x1296 30p/ 1920x1080 30p /1280x720 60p
/1280x720 30p /848x480 60p 16:9
2 inch TFT-LCD HD Clear color display screen
Advertisement
Summary of Contents for Eeyelog EH05
- Page 1 Police Law-enforcement Video and Audio Recorder Shenzhen Eeyelog Technology Co.,Ltd Foreword Thanks for choosing our Police Law-enforcement Video and Audio Recorder—EH05, Hope we can help you in your work of law enforcement. Product Overview Police law-enforcement video and audio recorder developed by us have many process technologies such as GPS, video and audio record, Integrate function, stable quality.
- Page 2 Wide Angle 140° wide-angle lens, Image without deformity Memory Capacity Build-in 16G/32G/64G Data Interface HDMI1.3 Support 1080p TV Output：NTSC Continuous Recording Time 10 hours Shoulder Microphone Support all kinds of walkie-talkie Positioning System（Optional） GPS、Beidou Positioning Car Mount（optional） Support External Power Supply(optional) Support Quick Operation Press power on/off key...
- Page 6 Display screen Description Basic operation description Boot Press power on/off key 2 seconds, beep on, Green LCD lamp on, display screen lighted and turn to standby situation.
- Page 7 Audio recording Short press Audio recording key , camera shake, yellow LCD instruction light flash, then start recording. Press key again to stop, also the camera shake, the yellow instruction LCD light off and the recording stored. One key audio recording. Long press key 4 seconds to start one key recording when the camera is off.
- Page 8 Long press key to adjust the focus.(Note: Focus can ‘ t adjusted under HD 1920*1080 video resolution) Auxiliary location Light 4 seconds Long press key to open auxiliary location light. Do it again to turn off. Snapshot under video recording Short press key one time to get one photo under video recording.
- Page 9 Resolution: 5 modes can be chosen to adjust video resolution. 2304x1296 30p/ 1920x1080 30p /1280x720 60p /1280x720 30p /848x480 60p. Short press up browse key or down browse key to select. Video section: 5min, 10min, 15min, 30 min that 4 modes for selection. Short press ...
- Page 10 record ≥10 seconds video information. IR switch: Manual or automatic GPS(optional):open or close Vehicle-Mounted: open Vehicle-Mounted mode. Assemble camera to base, one side of data cable connect to mini USB port on the base, the other side connect to USB port of the car.
- Page 11 Video recording indicator light Turn red and flashing under video recording Audio indicator light Turn yellow and flashing under audio recording Reset key Reset it when running wrong or hang. One key play/ up browse key Combination key, function as below: Press this key to playback the last audio and video file under standby.
- Page 12 Short press this key can put a * mark to the top left angle of the screen for the important file. Traffic control, criminal investigation, public security that 3 mode can be selected when 4 seconds long press this key. short press up browse key or down browse key to select,...
- Page 13 browse the files. This key also has focus adjust function. Long press this key can adjust 8X focus change under standby or video recording status. Press this can fast reverse by 2X, 4X, 8X, 16X, 32X, 64X under video recording.(Note: Cannot adjust focus under HD 2304*1296 resolution ) ...
- Page 14 Abnormal alarm Two abnormal alarms: Battery life shows on the screen flash, at the same time, camera body shake and Alert tone alarm when the battery life is not enough. Screen will alert “storage full”， camera body shake and Alert tone alarm when the battery life is full.
- Page 15 upload path change, setting of camera ID and policeman ID. All above details change in the software can be seen in file” Driver install and computer connection instruction”. Attention Cannot adjust focus under resolution 2304*1296. Reopen red IR night vision light to return color to normal when the screen has ...
