Summary of Contents for Merchant Link COM BOX
- Page 1 COM BOX INSTALLATION & CONFIGURATION GUIDE INGENICO DEVICES...
- Page 2 47 CFR Section 15.203 the Ingenico Com Box with Merchant Link’s TransactionLink product line. This document is This device, Com Box, complies with part 15 of the not intended to be site-specific or all inclusive. FCC Rules. Operation is subject to the following...
- Page 3 (Umbilical) Cable ALSO INCLUDED: 1X Cable Tie; 1X Piece Dual Lock Tape (For optional device mounting) Additional AC power cable included only in IWL 252 Com Box kits. Note: Other devices require only one power cable (included with Payment Terminal).
- Page 4 Eth LANE th ECR The Com Box may be fixed to a tabletop or table leg using the dual lock tape provided. It can also be affixed to a table leg using the provided cable tie. The cable tie should pass through each of the four holes at the rear of the device to ensure a secure mount.
- Page 5 Locate AC power cable provided with IWL terminal. Plug one end of cable into iWL Bluetooth base then plug device into a power outlet. Locate AC power cable provided with Com Box. Plug one end of cable into Com Box via the ‘Power’ port, then plug device into a power outlet.
- Page 6 Terminal Important: Use ONLY the power supply cable(s) supplied with the Com Box and/or Payment terminal. Use of cables intended for other devices may cause risk of personal injury, fire, electrical shock and/or permanent device malfunction. Uninterrupted Power Supply (UPS) recommended.
- Page 7 8401 Colesville Rd, Ste. 750 | Silver Spring, MD 20910 | Visit merchantlink.com to learn more. Copyright© Merchant-Link, LLC. All rights reserved.
