HUBBARDTON FORGE DESIGN 272865D Installation Instructions

Glass Installation Instructions

Disq Table Lamp 272865D
To Install Shade & Diffusers

Component Parts

A Top Diffuser
B Shade
C Bottom Diffuser
D Threaded Nipple
E Fixture
F Finial
1. Carefully unpack the lamp from the carton.
2. Place top diffuser (A) on a flat surface.
Note: An additional person will greatly aid in
assembling the shade/diffuser assembly.
3. Fit shade (B) over diffuser in one spot. Hold
shade in place while a second person
grasps the shade, slides their hands around
the diffuser, fitting shade in place. (Figure 2).
4. Install bottom diffuser (C) in similar manner.
Fit diffuser (C) inside the shade (B) in one
spot. Hold diffuser (C) in place while a
second person reaches inside the
diffuser (C) and slides their hands
around the inside of the shade (B),
allowing the rest of the diffuser (C) to set
down in the shade (B).
5. Remove finial (F) from fixture. (Figure
3).
6. Flip over shade/diffuser assembly
(A,B,C). Slide assembly over threaded
nipple (D) until bottom diffuser (C) rest
on fixture (F). (Figure 3).
7. Secure shade/diffuser assembly (A,B,C)
in place by attaching finial(F). Be sure
not to over tighten.
(Figures 1 thru 3)
Figure 2
Hand-Forged, Vermont-Made Lighting and Accessories
154 Route 30 South, Castleton, Vermont 05735
C73
Page 1 of 2
Figure 1
(continued)
32775
