Summary of Contents for MCH M1000i
-
Page 3: Table Of Contents
CONTENT Maintenance 01.Safety information 02.Safety label locations 1)Change oil 03.Components identification 2)Air cleaner service 3)Spark plug service 1)Control Panel 2)ECON 4)Spark arrester maintenance 3)RESET 09.Transporting/Storing 04.Pre-operation check 10.Technical specifications 1)Check oil level 11.Wiring diagrams 2)Check fuel level 12.Appendix 3)Check air cleaner 05.Starting the engine 06.Generator use 1)DC application... -
Page 4: Safety Information
● The running generator must keep one meter distance with constructions and other 1.SAFETY INFORMATION electrical appliances at least. ● Place the generator on the leveled surface, in To ensure personal and property safety, please order to avoid overturning or spilling fuel. carefully read the following information. - Page 5 SAFETY LABEL: <<05>>...
-
Page 6: Safety Label Locations
2. SAFETY LABLE LOCATIONS <<06>>... -
Page 7: Components Identification
3. C OMPONENTS IDENTIFICATION CHOKE LEVER FUEL CAP VENT LEVER SPARK PLUG MAINTENANCE COVER FUEL CAP MUFFLER LEFT SIDE MAINTENANCE COVER STARTER GRIP ENGINE SWITCH CONTROL PANEL <<07>>... -
Page 8: Control Panel
3.1) Control Panel 3.2) ECON. SW (Economy control switch): • When the Engine ECON switch is turned to the "ON" position, the economy control unit automatically determines the generator's proper engine speed based on the connected electronic load. This results in superior fuel economy and reduces noise. -
Page 9: Reset
● NOTE Under the non-overloading condition, the ■ When a high load electrical appliance is "RESET" is supposed to be ineffective. connected instantaneously, in order to reduce voltage change, turn the economy control switch to the ( )position. “OFF” ■ operation, turn the economy control NOTE switch to the... -
Page 10: Pre-Operation Check
NOTE 4. PRE- OPERATION CHECK ■ Using non-detergent or 2-stroke oil could shorten the engine’s working life. WARNING ■ Using the high quality engine oil with strong detergents Be sure the generator is on the leveled surface and the generator is stopped. ■... -
Page 11: Check Fuel Level
NOTE FUEL CAP ■ Before the engine oil reduces below the safety OPEN UPPER LIMIT MARK margin, low oil alert system will close the engine automatically The oil alert indicator light will be on. ■ To avoid the inconvenience caused by unexpected stopping, it is still advisable to Fuel capacity: 2.2L check the engine oil level regularly. -
Page 12: Check Air Cleaner
LATCH TAB 4.3)Check Air Cleaner LATCH TAB Check the air cleaner element to be sure it is clean and in good condition. AIR CLEANER BODY a. Loosen the air cleaner maintenance cover screw, and remove the cover. AIR CLEANER ELEMENT AIR CLEANER COVER LOWER TAB... -
Page 13: Starting The Engine
NOTE 5. STARTING THE ENGINE ■ When transporting generator, turn the fuel cap vent lever to the position. “OFF” NOTE 5.2) Turn engine witch to the position. “ON” ■ Before starting engine, disconnect load with receptacle. ■ Fueling at the first time, refueling, or storing for a long time, the engine switch should firstly be opened for ten or twenty seconds and then require additional pull 10-20 times, in order to... - Page 14 5.5) After starting and warming up the engine, NOTE turn the choke lever to position. “OPEN” ■ Do not move the choke lever to “CLOSED” position, when engine is hot or ambient CHOKE LEVER temperature is high. 5.4) Pull the starter grip lightly until you feel resistance, then pull quickly toward arrow as shown below.
-
Page 15: Generator Use
If the generator always operates at altitude 6. GENERATOR USE above 1,000 meters, contact with an authorized dealer servicing to modify the carburetor. Generator output power should be modified WARNING according to the altitude and ambient temperature.The correction factor refers to ●... -
Page 16: Dc Application
WARNING 6.1) DC Application ● For continuous operation, do not exceed the The DC receptacle, 15-30V under no-load condition, may be used for charging 12V battery only. rated out-put power of generator. ● Do not make parallel connection with other NOTE generators. - Page 17 WARNING WARNING ● ● In order to avoid producing the spark at the The battery can release the explosive gases. terminals of battery, connect the charging Keep the battery away from spark/fire. cable firstly to the battery terminals, and then Charge the battery in ventilated condition.
-
Page 18: Ac Application
circuit protector, remove load firstly, then OVERLOAD reset the protector after a few minutes. INDICATOR LIGHT(RED) AC PILOT INDICATOR LIGHT (GREEN) PLUG NOTE ■ Confirm all electrical appliances are in good DC CIRCUIT PROTECTOR working condition before connecting them to the generator. -
Page 19: Oil Warning System
If the overload indicator light (red) is on, disconnect 6.4) Oil Warning system the electrical appliances firstly, press and hold the rest button 1s. If the overload indicator light (red) is OFF and the AC Pilot indicator light (green) is on, The oil arning system is designed to prevent reconnect the electrical appliances. -
Page 20: Stopping The Engine
7.3) Turn the fuel cap vent lever to the“OFF” position. 7. STOPPING THE ENGINE FUEL CAP VENT LEVER To stop the engine in an emergency, turn the engine switch to the position. “OFF” 7.1) Switch off the connected electrical appliances, and pull out their plugs. -
Page 21: Maintenance
Spark plug ⊙ Replace 8. MAINTENANCE Spark arrester ⊙ Valve Clearance Check-adjust ⊙+( The purpose of the maintenance and After every 300 hrs(2) Combustion Chamber Clean adjustment schedule is to keep the generator in Fuel tank& filter Clean Every year(2) the beset operating condition. -
Page 22: Air Cleaner Service
8.1.3) Drain dirty oil into a container thoroughly. Oil Capacity:0.25L 8.1.4) Refill the recommended oil and check the oil level. DIPSTICK 8.1.5) Reinstall the oil filler cap. UPPER LEVEL 8.1.6) Reinstall the maintenance cover and tighten the cover screw. OIL FILLER Oil Capacity: 0.25L After oil change, wash your hands with soap. - Page 23 WARNING LATCH TAB Do not use gasoline or low ignition point solvents for cleaning. They are flammable and explosive LATCH TAB under certain conditions. AIR CLEANER BODY NOTE Never run the generator without air cleaner, otherwise that result in engine abrasion rapidly. AIR CLEANER ELEMENT 8.2.1) Loosen the air cleaner maintenance cover screws, and remove the cover.
-
Page 24: Spark Plug Service
HANDLE BAR 8.2.5)Reinstall the air cleaner element and cover. SPARK PLUG 8.2.6)Reinstall the maintenance cover, and tighten the screws. 8.3) Spark Plug Service Recommendation spark plug: CR7HSA Check the spark plug gap and clean the carbon deposition at the bottom of the spark plug. 8.3.1) Remove the spark plug maintenance cover. -
Page 25: Spark Arrester Maintenance
8.3.6) Measure the spark plug gap with a feeler 8.4) Spark Arrester Maintenance gauge. The normal value:0.70-0.80mm(0.028- 0.031in). Adjust the gap by bend one of the electrode carefully. WARNING 8.3.7) Reinstall the spark plug carefully, by hand, to The spark arrester must be maintained every 100h service. - Page 26 8.4.2)Take off the spark arrester from the muffle 8.4.4)Reinstall the spark arrester and muffle guard. after the engine cool down. 8.4.3)Remove carbon deposits of the spark arrester using a brush. If the spark arrester is wear, replace it. <<26>>...
-
Page 27: Transporting/Storing
Storing for a long period: 9.TRANSPORTING/STORING 9.1) Make sure the storage area without excessive humidity and dust. Avoid fuel spilling during transporting or temporary 9.2) Drain off the fuel. storing, both the engine switch and the fuel cap WARNING vent lever should turn to “OFF’ position, and the generator should place in normal operating ●... - Page 28 b. Turn the engine switch to “ON” position, and loosen the carburetor drain screw to discharge gasoline inside of carburetor. STARTER GRIP SCREW DRIVER 9.3) Change the engine oil. 9.4) Remove the spark plug, and pour a tablespoon of clean engine oil(10~20ml)into the cylinder.
-
Page 29: Technical Specifications
10. TECHNICAL SPECIFICATIONS Specifications Parameters DC Output 12V/5A Fuel Tank Volume 3.0L Model 4-stroke, overhead valve, 4.5h (rated power) Continuous Running Time Type single cylinder, forced-air cooling Fuel Consumption 550g / kW.h Engine Displacement 54сс Working Ambient Temperature -5~40℃ Bore*Stroke 43.5 *35.8 Max. -
Page 30: Wiring Diagrams
<<30>>... -
Page 31: Appendix
13. APPENDIX Environment Correction NOTE : Relative humidity 60% correction factorC- 0.01; The standard condition of rated power output: Relative humidity 80% correction Altitude:0m factorC -0.02; Relative humidity 90% correction factorC- Ambient temperature:25 C 0.03; Relative humidity 100% correctionfactorC- 0.04; Factor of environment correction: Example：...
