Form: SOL-AA23GC-617
Page 1
Assembly Instructions for Cart for use with
Solaire AllAbout Double Burner Infrared Grill
+
=
Item #SOL-AA23GC
Item #SOL-AA23A-LP
Complete Grill on Cart
(sold separately)
Read This Manual Thoroughly Before Assembling Cart
or Using Grill
Rasmussen Gas Logs & Grills
Manufactured by:
12028 Philadelphia Street, Whittier, CA 90601 USA
562-696-8718 fax: 562-698-3510 Info@Rasmussen.biz www.SolaireGrills.com
Quality Products Since 1907
Advertisement
Summary of Contents for Solaire AllAbout SOL-AA23GC
- Page 1 Form: SOL-AA23GC-617 Page 1 Assembly Instructions for Cart for use with Solaire AllAbout Double Burner Infrared Grill Item #SOL-AA23GC Item #SOL-AA23A-LP Complete Grill on Cart (sold separately) Read This Manual Thoroughly Before Assembling Cart or Using Grill Rasmussen Gas Logs & Grills...
-
Page 2: Outdoor Use Only
Form: SOL-AA23GC-617 Page 2 OUTDOOR USE ONLY Your SOLAIRE INFRARED Grill is designed for outdoor use only and must not be installed in or on recreational vehicles and/or boats. Tools Needed - Mallet or Hammer - Screwdriver, Phillips Head - 7/16” End Wrench - 8”... - Page 3 Form: SOL-AA23GC-617 Page 3...
- Page 4 Form: SOL-AA23GC-617 Page 4 Step 1 - Assemble Legs A (#6) and D (#5) to Right Side of Bottom Shelf (#7) using 3-Screw (#14) and 3-Lock Washer (#13) per leg. LEG D LEG A FRONT Step 2 - Assemble Wheels (#11) to Axle (#12) through Bottom Shelf (#7). Axle comes with one Axle Cap (#19) installed.
- Page 5 Form: SOL-AA23GC-617 Page 5 Step 3 - Assemble Axle Cap (#19) to secure Wheel Assembly to Cart Place assembly as shown onto cardboard or other slick surface to prevent scratching of parts. Using a mallet, or hammer with piece of cardboard between hammer face and Axle Cap (to prevent marring the Cap’s finish), strike Axle Cap strongly to secure Cap to Axle.
- Page 6 Form: SOL-AA23GC-617 Page 6 Step 5 - Assemble Middle Shelf (#8) to four Legs using 2-Screw (#14) and 2-Lock Washer (#13) per leg. FRONT Step 6 - Assemble Top Shelf (#1) to four Legs using 1-Screw (#14) and 1-Lock Washer (#13) per leg. FRONT...
- Page 7 Form: SOL-AA23GC-617 Page 7 STEP 7 - Assemble Side Shelf (#2) to right side of cart using 1-Right Bracket (#16b) and 1-Left Bracket (#16a); 2-Hex Bolt (#17), 1-Flat Washer (#15) on the top Hex Bolt, and 2-Lock Washer (#13) per bracket. Repeat for left side. Tip: Assemble front bracket first, then just the top Hex Bolt of the...
- Page 8 Form: SOL-AA23GC-617 Page 8 STEP 9 - Assemble Grill (Solaire AllAbout Double Burner) to Cart STEP 9A - Thread Hex Nut (#21) and Flat Washer (#22) onto each of the four Adjustable Legs of the Grill (which allows for Grill to securely attach to Cart.
- Page 9 Form: SOL-AA23GC-617 Page 9 STEP 10 - Connect Hose to Grill, then Hose to Propane Tank From underneath the Middle Shelf (#8), pass the small end of the Hose (supplied with the Grill) through the hole, then though the hole in the Front Right Leg “A” (#6). Assemble the fitting onto the Hose Fitting on the Grill (Note: Do Not use Teflon tape or pipe thread compound on these threads, as doing so could result in a gas leak).
-
Page 10: Duration Of Warranty
Care of Your Cart Please refer to the Care/Use Manual provided with your AllAbout Grill for Care of Stainless Steel, or visit our Knowledge Base at www.RasBox.com Solaire Infrared Grills Limited Warranty This warranty covers Item #SOL-AA23GC DURATION OF WARRANTY Rasmussen Iron Works, Inc.
