Accessories
Table 9: Controller accessories (order separately)
Product code number
IOM Series Controllers
NS Series Sensors
Mobile Access Portal (MAP) Gateway
TL-CCT-0
MS-FCP-0
WRZ Series Sensors
MS-DIS1710-0
Y64T15-0
Y65A13-0
Y65T42-0
Y65T31-0
AP-TBK1002-0
AP-TBK1003-0
AP-TBK4SA-0
AP-TBK2PW-0
MS-VMAACT-701
AS-CBLTSTAT-0
F-1000-325
F-1000-326
TL-BRTRP-0
18 VMA1930 VAV Controller Installation Guide
Description
Refer to the Metasys System Field Equipment Controllers and Related Products Product Bulletin
®
(LIT-12011042) for a complete list of available IOM Series Controllers.
Refer to the NS Series Network Sensors Product Bulletin (LIT-12011574) for a complete list of
available NS Series Sensors.
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT, which is no longer
available for purchase, but continues to be supported.
Metasys Controller Configuration Tool
Metasys Equipment Controller Firmware Package Files for CCT
Refer to the WRZ Series Wireless Room Sensors Product Bulletin (LIT-12011653) for a complete
list of available WRZ Series Sensors.
Local Controller Display
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount, 72.2 cm (30
in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS), 20.32 cm (8
in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount (Y65SP+),
20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AR+),
20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
2-position Screw Terminal that plugs onto VMA Output Point Spade Lugs
3-position Screw Terminal that plugs onto VMA Output Point Spade Lugs
Replacement MS/TP SA Bus Terminal, 4-Position Connector, Brown, Bulk Pack of 10
Replacement Power Terminal, 2-Position Connector, Gray, Bulk Pack of 10
VMA Actuator Assembly Gearbox Replacement Kit
Cable adapter for connection to 8-pin TE-6700 Series sensors
Replacement Barbed Fitting for use on VMA1930 for Connecting Tubing, Bulk Pack of 10
Flexible Tubing Extension with Barbed Fitting for VMA1930, 35.56 cm (14 in.) Length, Bulk
Pack of 20
Portable BACnet/IP to MS/TP Router
